ABB YXN 116 drive board driver

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Description

The ABB YXN116 Drive Board / Driver is a high-performance module used for motor control in industrial automation systems.
It receives control signals from a CPU control unit and converts them into drive outputs for precise speed, torque, and position control.

Designed for industrial environments, the YXN116 provides high reliability, strong noise immunity, and fast response, making it suitable for robotics, servo drives, and automated production lines.

Technical Specifications

• Model: YXN116

• Manufacturer: ABB

• Type: Drive Board / Driver

• Power Supply: 24 V DC (±10%)

• Power Consumption: Approx. 10 W

• Supported Motors: AC asynchronous motor / Servo motor / Stepper motor (system dependent)

• Input Interface: System bus / Analog input / Digital input

• Output Interface: PWM / Analog voltage / Current output

• Communication Interfaces:

  • RS-485 / RS-232

  • CAN Bus

  • System Backplane Bus

• Control Accuracy: ±0.1% (typical)

• Response Time: < 1 ms

• Signal Isolation: Optical isolation ≥ 1500 V RMS

• Operating Temperature: 0°C to +55°C

• Storage Temperature: -25°C to +70°C

• Relative Humidity: ≤ 90% (non-condensing)

• Protection Class: IP20

• Dimensions: Approx. 160 × 100 mm

• Weight: Approx. 0.35 kg

• Mounting Type: Slot / Modular Rack Mount

Features & Advantages

1. High-Performance Motor Control: Supports high-speed PWM or analog drive.

2. Fast Response: Ensures smooth and rapid system operation.

3. Strong Noise Immunity: Optical isolation and filtering for stable signals.

4. Modular Design: Easy installation, replacement, and system expansion.

5. Excellent Compatibility: Works seamlessly with ABB YXR, YXP, and YXM controllers.

6. Supports Multiple Motor Types: Servo, stepper, and AC motors.

7. Status Monitoring: LED indicators and self-diagnostics facilitate maintenance.

8. High Reliability: Industrial-grade components suitable for harsh environments.

Application Fields

• Industrial robot control systems

• Motor drives and servo systems

• Automated production lines and processing equipment

• Variable frequency drives and motion control devices

• Chemical, metallurgical, paper, and pharmaceutical production

• Electrical automation and remote monitoring systems

Precautions

1. Power off before installation or maintenance.

2. Use anti-static wrist straps or grounding mats to prevent ESD damage.

3. Ensure input and output interfaces match system configuration.

4. Use shielded, grounded cables to reduce interference.

5. Avoid high temperature, humidity, corrosive, or dusty environments.

6. Regularly inspect connectors and maintain proper ventilation.

7. Use ABB-certified tools for firmware upgrades or diagnostics.

8. Avoid long-term overload or short-circuit operation to prevent damage.

The structure and details of the product：

 Please make an inquiry for more models
