ABB YB161102-AE/7 Circuit Board Analyzer Digital Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Description

The ABB YB161102-AE/7 is a digital circuit analyzer board used in ABB industrial automation systems. It collects, processes, and analyzes digital signals for controlling and monitoring industrial equipment and robotic systems. This digital board provides high-speed data acquisition, signal processing, and fault diagnostics, seamlessly integrating with ABB controllers and I/O modules, enhancing system reliability and automation precision.

Technical Specifications

• Model: YB161102-AE/7

• Product Type: Circuit Board Analyzer Digital Board

• Input Type: Digital signal input (TTL/logic level)

• Output Type: Digital signal output (TTL/logic level)

• Channels: 16 inputs / 16 outputs (system configurable)

• Interface Type: Modular bus interface

• Operating Voltage: 24 VDC

• Operating Temperature: 0°C – +50°C

• Storage Temperature: -25°C – +70°C

• Protection Class: IP20

• Mounting: Control cabinet board mount

• Functions:

  • High-speed digital signal acquisition and output

  • Real-time data processing and monitoring

  • LED indicators for channel operation and faults

  • Built-in short-circuit and overcurrent protection

  • Modular design for easy installation, expansion, and maintenance

Features & Advantages

1. High-speed digital processing: Rapid digital signal acquisition and output ensures real-time industrial control.

2. Status visualization: LED indicators for each channel facilitate debugging and fault diagnostics.

3. Modular design: Supports hot-swappable installation and system expansion for easy maintenance.

4. Strong compatibility: Seamlessly integrates with ABB controllers and PSQC/DSQC I/O modules.

5. Industrial-grade reliability: Suitable for long-term continuous operation in complex industrial environments.

6. Safety protection: Built-in short-circuit and overcurrent protection ensures safe and stable operation.

Application Areas

• ABB industrial robot digital signal control and monitoring

• Automated production line digital I/O expansion

• PLC and industrial control system digital signal processing

• High-speed data acquisition and equipment status monitoring

• SCADA systems and smart factory digital control

• Industrial measurement, control, and remote diagnostics

Precautions

• Disconnect power before installation.

• Ensure digital input/output signals match module specifications.

• Avoid high humidity, corrosive, or high-vibration environments.

• Regularly inspect terminals and cooling to ensure safe operation.

• Installation and commissioning must be performed by qualified personnel.

• Do not exceed rated voltage, current, or environmental limits to ensure board longevity.
