ABB YB-560-103-BE/2 PSQC 224 Analog Input/Output Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Description

The ABB YB-560-103-BE/2 PSQC 224 is an analog input/output (AIO) module for ABB industrial robots and automation systems. It collects and outputs voltage, current, or sensor signals, providing high-precision analog data processing. The module seamlessly integrates with ABB controllers and I/O systems, offering reliable analog signal management for robot control systems, automated production lines, and precision machinery.

Technical Specifications

• Model: YB-560-103-BE/2

• Product Type: PSQC 224 Analog I/O Board

• Input Type: Analog input (Voltage 0–10 V / Current 0–20 mA, configurable)

• Output Type: Analog output (Voltage 0–10 V / Current 0–20 mA, configurable)

• Number of Channels: 8 analog inputs / 8 analog outputs (system dependent)

• Interface Type: Modular bus interface

• Operating Voltage: 24 VDC

• Operating Temperature: 0°C – +55°C

• Storage Temperature: -25°C – +70°C

• Protection Class: IP20

• Mounting: DIN rail or control cabinet board mount

• Functions:

  • High-precision analog signal acquisition and output

  • Fast response suitable for real-time control

  • LED indicators for each channel status

  • Modular design for easy installation, expansion, and maintenance

  • Supports system fault detection and diagnostics

Features & Advantages

1. High-precision acquisition: Supports voltage, current, and sensor signals for accurate measurement.

2. Fast response: Rapid analog signal acquisition and output for real-time industrial control.

3. Modular design: Hot-swappable installation for system expansion and maintenance.

4. Status visualization: LED indicators display channel status for easy debugging and troubleshooting.

5. Strong compatibility: Seamlessly compatible with ABB controllers and PSQC series I/O bases.

6. Safe and stable: Built-in overvoltage and overcurrent protection ensures system safety.

Application Areas

• ABB industrial robot control systems

• Factory automation control systems

• PLC analog I/O expansion

• Production lines and manufacturing equipment analog signal acquisition and control

• Smart manufacturing and precision control systems

• SCADA systems and remote monitoring

• Measurement and process control applications

Precautions

• Disconnect power before installation.

• Ensure module input/output types match system signals.

• Avoid high humidity, corrosive, or high-vibration environments.

• Regularly check terminals and wiring to ensure reliable electrical connection.

• Installation and commissioning must be performed by qualified personnel.

• Do not exceed rated voltage, current, or environmental limits to ensure module longevity.
