ABB YB161102-AD/1 Resolver Excitation Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• Product Description

  The ABB YB161102-AD/1 Resolver Excitation Board is a dedicated module for providing excitation signals to resolvers in industrial automation and motor control systems. It delivers high-precision AC excitation signals to the resolver and transmits feedback signals to the controller or drive, enabling accurate angle and position detection. The YB161102-AD/1 is suitable for servo drives, motor controllers, and industrial automation systems, ensuring high-precision and reliable motion control.

  ---

  Technical Specifications

  • Model: YB161102-AD/1

  • Product Type: Resolver Excitation Board

  • Input Voltage: 24 VDC

  • Output Signal: AC excitation signal (typically 5–10 kHz, amplitude depends on application)

  • Supported Resolution: High-precision resolver

  • Interface Type: Modular bus interface, compatible with controller/drive

  • Operating Temperature: 0°C – +55°C

  • Storage Temperature: -25°C – +70°C

  • Protection Class: IP20

  • Mounting: DIN rail or control cabinet board mount

  • Functions:

    • Provides precise AC excitation signal for resolver

    • Supports high-speed angle and position acquisition

    • Modular design for easy installation and maintenance

    • LED indicators for status and fault diagnostics

    • Industrial-grade, high-reliability design

  ---

  Features & Advantages

  1. High-precision control: Provides stable resolver excitation for accurate angle and position measurement.

  2. Modular design: Easy installation and maintenance, supports system expansion.

  3. High reliability: Industrial-grade design suitable for harsh environments and long-term operation.

  4. Status visualization: LED indicators show operational status and faults for easy troubleshooting.

  5. Strong compatibility: Compatible with ABB drives, controllers, and modular I/O systems.

  6. Safe and stable: Optimized circuit design with overvoltage protection and electrical interference suppression.

  ---

  Application Areas

  • Industrial servo drive systems

  • Servo motors and motion control systems

  • Precision mechanical position and angle detection

  • Automated production lines and robotic control systems

  • Factory automation and smart manufacturing systems

  • Motor controllers and drive systems

  ---

  Precautions

  • Disconnect power before installation.

  • Ensure the resolver type matches the board parameters.

  • Avoid use in high humidity, corrosive, or high-vibration environments.

  • Regularly check terminals and wiring to ensure reliable excitation signal transmission.

  • Installation and commissioning must be performed by trained personnel.

  • Do not exceed rated voltage and environmental temperature to ensure module longevity.

•
