ABB 3HAA3563-AGA/2 DSQC 249A Rectifier

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Description

The ABB 3HAA3563-AGA/2 DSQC 249A Rectifier is a critical module for DC power supply in ABB industrial automation and robot systems. This rectifier converts AC power into stable DC power, providing reliable energy to controllers, drives, and I/O systems. The DSQC 249A Rectifier features high efficiency, reliability, and industrial-grade durability, making it an essential power component for ABB robot control cabinets and automation systems.

Technical Specifications

• Model: 3HAA3563-AGA/2

• Product Type: DSQC 249A Rectifier

• Input Voltage: AC 380–480 V, 50/60 Hz

• Output Voltage: DC 24 V / 48 V (system dependent)

• Output Current: Up to 20–40 A (depending on specification)

• Efficiency: ≥ 90%

• Operating Temperature: 0°C – +50°C

• Storage Temperature: -25°C – +70°C

• Protection Class: IP20

• Mounting: Control cabinet board mount

• Functions:

  • High-efficiency AC/DC conversion

  • Stable output voltage to protect control systems

  • Built-in overcurrent, overvoltage, and short-circuit protection

  • LED status indicators

  • Industrial-grade design for harsh environments

Features & Advantages

1. High efficiency: ≥90% energy conversion efficiency reduces energy loss and heat.

2. High reliability: Industrial-grade design suitable for long-term continuous operation.

3. Stable output: Provides stable DC power to protect controllers and I/O modules.

4. Safety protection: Overcurrent, overvoltage, and short-circuit protection ensure system safety.

5. Easy maintenance: LED indicators and modular design facilitate quick inspection and replacement.

6. Strong compatibility: Designed for ABB robot control cabinets and automation systems, high compatibility.

Application Areas

• ABB industrial robot control cabinets

• Factory automation control systems

• PLC and I/O system DC power supply

• Smart manufacturing and automated production lines

• Motor drives and servo systems

• SCADA and automated monitoring systems

Precautions

• Disconnect power before installation.

• Ensure AC input and DC output voltage meet system requirements.

• Avoid use in high humidity, corrosive, or high-vibration environments.

• Regularly check wiring and terminal connections to maintain power stability.

• Installation and maintenance must be performed by trained personnel.

• Do not exceed rated voltage and environmental temperature to ensure module longevity.
