ABB XV C770 AE coated circuit board

Product Overview:

The ABB XV C770 AE Coated Circuit Board is a high-reliability module designed for ABB’s industrial automation and process control systems. Featuring a special protective coating, this board provides excellent resistance to moisture, dust, and corrosive gases, ensuring long-term stable operation in harsh industrial environments.

It is widely used in ABB Symphony Plus, Bailey INFI 90, and Turbine Control Systems, handling critical functions such as signal processing, logic control, communication, and equipment monitoring.

Technical Specifications:

• Model: XV C770 AE

• Brand: ABB

• Type: Coated Circuit Board / Control Module

• Main Function: Logic control, signal acquisition, and system communication

• Protective Coating: Conformal coating for moisture, dust, and corrosion protection

• Input Voltage: 24 V DC (typical)

• Power Consumption: ≤ 10 W

• Processor: High-speed industrial-grade microprocessor

• Communication Interfaces: RS-485 / Ethernet / Profibus (depending on configuration)

• I/O Channels: Multiple analog and digital inputs/outputs

• Operating Temperature: 0°C to +55°C

• Storage Temperature: -25°C to +70°C

• Humidity: 10%–95% (non-condensing)

• Design: Modular plug-in structure for rack-mounted ABB systems

• Compatible Systems: ABB Symphony Plus, Bailey INFI 90, Turbine Control Systems

• Protection Features: Overvoltage, overcurrent, and ESD protection

• PCB Material: Industrial FR-4 epoxy glass fiber board

Features and Advantages:

1. Excellent Environmental Protection: Conformal coating resists moisture, dust, and corrosion.

2. High Reliability: Designed for long-term, continuous industrial operation.

3. Signal Stability: Strong resistance to electromagnetic interference.

4. Modular Construction: Easy installation, replacement, and maintenance.

5. Strong Compatibility: Fully compatible with multiple ABB control platforms.

6. Durability: Heat-resistant and vibration-proof design ensures long service life.

7. Enhanced Safety: Built-in protection against overcurrent and static discharge.

Applications:

• Power and energy automation systems

• Petrochemical and refinery process control

• Steel and metallurgy industrial automation

• Water treatment and environmental systems

• Pulp and paper manufacturing

• Mining and industrial drive systems

• Turbine and large motor control systems

• Marine and high-humidity automation applications

Precautions:

1. Disconnect power before installation or maintenance.

2. Wear anti-static protection to avoid component damage.

3. Keep connectors and slots clean and dry.

4. Avoid operating in high humidity or corrosive gas environments.

5. Regularly check indicator lights and communication status.

6. Use only ABB-certified cables and accessories for reliable system integration.
