ABB 3BHE009017R0101 drive control module

Product Overview:

The ABB 3BHE009017R0101 Drive Control Module is a core control unit for ABB industrial drive systems. It provides precise motor and drive control, signal acquisition, logic processing, and communication management. Designed with an industrial-grade high-speed processor and robust circuitry, it ensures high reliability, precision, and fast response in demanding industrial environments.

This module is widely used in ABB ACS drives, industrial motor control systems, and automated production lines, serving as a key component for intelligent drive and precise control.

Technical Specifications:

• Model: 3BHE009017R0101

• Brand: ABB

• Type: Drive Control Module

• Main Function: Motor drive control, logic processing, signal acquisition, communication management

• Input Voltage: 24 V DC (typical)

• Power Consumption: ≤ 20 W

• Processor: High-speed industrial-grade microprocessor

• Communication Interfaces: RS-485 / Ethernet / CAN / Profibus (depending on configuration)

• I/O Channels: Analog input/output, digital input/output

• Operating Temperature: 0°C to +55°C

• Storage Temperature: -25°C to +70°C

• Humidity: 10%–90% (non-condensing)

• Mounting: Modular rack or DIN rail

• Compatible Systems: ABB ACS drive series, industrial motor control platforms

• Status Indicators: LED indicators for operation and communication status

Features and Advantages:

1. High-Performance Drive Control: Fast processor ensures precise and responsive motor control.

2. High Reliability: Industrial-grade components for continuous operation.

3. Modular Design: Quick installation, replacement, and maintenance reduce downtime.

4. Strong EMI Protection: Excellent electromagnetic compatibility ensures signal stability.

5. Multi-Protocol Support: Seamless integration with multiple industrial communication networks.

6. Data Security: Built-in memory safeguards operating parameters.

7. Harsh Environment Ready: Heat-resistant and vibration-proof design extends equipment lifespan.

Applications:

• Industrial motor drives and automation control

• Variable frequency drives (VFD) and power drive systems

• Steel, mining, and metallurgy industries

• Petrochemical and refinery equipment

• Water treatment and environmental control

• Pulp and paper manufacturing automation

• Industrial automation lines and machinery control

Precautions:

1. Disconnect power before installation or maintenance.

2. Ensure wiring connections are correct and secure.

3. Avoid high humidity, dusty, or strong EMI environments.

4. Use anti-static protection when handling or replacing the module.

5. Regularly check indicator lights and communication status.

6. Use ABB-certified cables and accessories for reliable system integration.
