ABB VD86-SCAN Video Controller Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Overview

The ABB VD86‑SCAN Video Control Board is an industrial-grade video control module, part of ABB / Stromberg’s controller module family. It is designed for processing, synchronizing, and outputting video signals in automation systems, monitoring systems, or control cabinets, working together with display devices such as monitors.

2. Technical Specifications

Based on available public sources:

• Model / Part Number: VD86-SCAN, ABB Part No. 57088478. artisantg.com

• Interfaces / Connections:

  • Three BNC connectors for video signal input/output. artisantg.com

  • One 15-pin connector for connecting to a main chassis, controller, or other module. artisantg.com

  • Latching-style connection to ensure secure physical attachment. artisantg.com

• Processing Capability: Built-in processor for signal conversion and scan synchronization, which reduces image latency and distortion. artisantg.com

• Environment / Robustness: Suitable for industrial environments; has some resistance to electromagnetic interference (EMI). artisantg.com

• Physical / Weight: Approximate weight is several hundred grams, depending on version. artisantg.com+1

• Status: This part is often found as used or refurbished; OEM may consider it end-of-life, but there are vendors providing repair and replacement support. yorkcontrols.com

3. Advantages & Features

• Real-time Video Control: Capable of synchronizing and processing video signals to deliver stable and low-latency output.

• Standardized Interfaces: The BNC connectors and 15-pin port make integration with industrial systems straightforward.

• Modular Design: Functions as a standalone board that can be inserted or replaced easily in existing systems.

• Robust Construction: Latching connector provides reliable physical mounting; board is suited for industrial environments.

• Maintenance & Longevity: Even though it's an older module, there is still support via refurbished boards and repairs. yorkcontrols.com

• Compact Form Factor: As a board module, it takes up relatively little space — ideal for control cabinets or rack systems.

4. Application Areas

• Industrial Automation Monitoring: For real-time video feedback on production lines, process points, or quality checks.

• Control Rooms / Monitoring Centers: Integrated into DCS or SCADA setups to display camera feeds or system data visuals.

• Marine / Offshore Systems: Suitable for shipboard monitoring or onboard video systems (e.g., via ABB-Autronica integration).

• Infrastructure Monitoring: Used in critical facilities such as power plants or water treatment plants for video surveillance.

• Legacy System Maintenance / Upgrades: Ideal for replacing or maintaining older ABB / Stromberg control systems that originally used this module.

5. Precautions / Considerations

• Since many units are used or refurbished, confirm operational status and source reliability before purchase.

• Ensure proper wiring: BNC video cables and 15-pin connectors should be well managed to avoid interference or poor contact.

• Use a stable, clean power supply to avoid signal degradation or module instability.

• Avoid installation in areas with high vibration or extreme temperature swings to protect solder joints and components.

• For critical systems, keep a spare VD86-SCAN board on hand to minimize downtime in case of failure.

• Follow ESD protection practices during maintenance — the board is sensitive to static damage.

• When pairing with other video equipment (cameras, monitors), verify compatibility in terms of signal levels, impedance, and connector types.
