ABB TU805K01 Termination Unit

1. Key Parameters

• Product Model: TU805K01
• Product Series: ABB TU Series Industrial Termination Units (S800 I/O Wiring Integration, Cabinet Organization)
• Core Function: Provides secure termination of field wiring for ABB S800 I/O modules; organizes cable management; protects connections from mechanical stress; simplifies wiring modifications and troubleshooting
• Electrical & Terminal Specifications:

  Parameter	Details	Performance Metrics
  Terminal Configuration	- Terminal Type: Screw-clamp terminals (copper alloy, nickel-plated) - Number of Terminals: 48 terminals (24 pairs for signal and common) - Wire Gauge Support: 0.25mm²~2.5mm² (24~14 AWG) stranded/solid - Terminal Spacing: 5.08mm (0.2") pitch for easy access with tools	Accommodates 95% of industrial field wiring sizes, eliminating the need for adapter terminals
  Electrical Ratings	- Voltage Rating: 600V AC/DC (max) - Current Rating: 10A (per terminal) - Insulation Resistance: ≥100MΩ (at 500V DC) - Dielectric Strength: 2.5kV AC (1min between adjacent terminals)	Supports high-power field devices and ensures safe operation in industrial voltage environments
  Wiring Features	- Marking System: Pre-printed labels and blank label strips for custom identification - Cable Management: Integrated cable tie points and wire guides - Connection Type: Feed-through design (continuous path for common lines) - Grounding: Dedicated ground terminal bar (4mm²)	Reduces wiring errors by 40% through clear labeling; organized cable management simplifies troubleshooting
  Mechanical Protection	- Protection Rating: IP20 (finger protection) - Vibration Resistance: 10~500Hz, 1g acceleration (no terminal loosening) - Torque Range: 0.5~0.8Nm (terminal screws) - Material Flammability: UL 94 V0 (terminal block housing)	Prevents accidental contact with live parts; terminal screws maintain torque under vibration, ensuring reliable connections

• Mechanical Specifications:
  • Dimensions: 100mm (W) × 160mm (L) × 75mm (H) (compatible with S800 I/O racks)
  • Mounting Type: Direct attachment to ABB S800 I/O racks; compatible with EN 50022 DIN rails (35mm)
  • Housing Material: Glass-fiber reinforced polyamide (PA66+GF, impact-resistant)
  • Weight: Approximately 350g
  • Color: Light gray (RAL 7035) for high visibility in control cabinets
• Environmental Ratings:
  • Operating Temperature Range: -25℃~+70℃ (-13℉~158℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: 5%~95% RH (non-condensing, 40℃)
  • Chemical Resistance: Resistant to mineral oil, grease, and industrial detergents (per IEC 60068-2-54)
  • Altitude Rating: Up to 2000m (no derating required)
• Compliance Standards: IEC 60947-7-1 (low-voltage switchgear), UL 1059 (terminal blocks), CE, RoHS, ABB S800 I/O Compatibility Standard

2. Key Features

• S800 I/O Integration: Designed for direct attachment to ABB S800 I/O racks—creates a unified wiring system between field devices and I/O modules, reducing cabinet space requirements by 25% compared to separate terminal blocks.
• 48-Terminal Capacity: 48 high-density terminals (24 signal/common pairs) accommodate up to 24 field devices—ideal for connecting sensors/actuators to S800 I/O modules (e.g., AI893, DI825), minimizing the number of termination units needed.
• Clear Identification System: Pre-printed and customizable labels for each terminal—simplifies wiring documentation and reduces commissioning time by 30%; color-coded zones distinguish signal types (analog, digital, power).
• Robust Terminal Design: Nickel-plated copper terminals with 0.5~0.8Nm torque specification—ensure gas-tight connections that resist corrosion and maintain conductivity even in humid environments (e.g., food processing plants, wastewater facilities).
• Integrated Cable Management: Built-in wire guides and cable tie points—prevent cable strain on terminals and organize wiring in control cabinets, making troubleshooting and modifications faster (reducing maintenance time by 40%).
• Wide Environmental Range: -25℃~+70℃ operating temperature and resistance to industrial chemicals—performs reliably in extreme environments: cold storage, high-temperature process areas, and facilities with washdown requirements.
• Safety Compliance: IP20 finger protection, UL 94 V0 flammability rating, and 2.5kV dielectric strength—meets global safety standards for electrical equipment in industrial control cabinets, reducing risk of electrical accidents.

3. Application Fields

• S800 I/O System Wiring: Primary application—terminating field wiring for ABB S800 modules:
  • Chemical Plant Control Cabinets: Connects 4~20mA pressure sensors and 24V DC valve position switches to AI893 and DI825 modules; organized labeling simplifies tracing wires during troubleshooting, reducing downtime during process upsets.
  • Automotive Assembly Line Control Panels: Terminates photoelectric sensor and limit switch wiring for DI885 safety modules; secure terminals maintain connections despite conveyor vibration, ensuring reliable robot safety interlocks.
• Industrial Control Cabinet Organization: Streamlining complex wiring:
  • Food & Beverage Processing Lines: Manages wiring for temperature sensors and motor starter feedback signals; chemical resistance withstands periodic washdowns with caustic cleaners, maintaining terminal integrity in hygienic environments.
  • Water Treatment Plant Control Rooms: Organizes wiring for flow meters, level switches, and pump status signals; clear labeling enables quick identification of faulty sensors, reducing mean time to repair (MTTR) for water distribution systems.
• Machine Automation Wiring: Simplifying machinery connections:
  • Packaging Machinery Control Boxes: Terminates proximity sensor and encoder wiring; compact design fits in limited cabinet space, while cable management features prevent wire damage during machinery vibration.
  • Plastic Injection Molding Machines: Connects temperature controller outputs and hydraulic valve position sensors; high-temperature tolerance (+70℃) withstands heat from molding processes, ensuring reliable signal transmission.
• Power Generation Auxiliary Systems: Managing auxiliary equipment wiring:
  • Gas Turbine Auxiliary Cabinets: Organizes wiring for lubrication pump sensors and cooling fan status switches; robust terminals maintain connections in high-vibration environments, preventing false alarms in turbine monitoring systems.
  • Solar Farm Inverter Control: Terminates current sensor and breaker status wiring; wide temperature range (-25℃~+70℃) handles outdoor cabinet conditions, ensuring reliable monitoring of inverter performance.

4. Precautions

• Terminal Torque Application (Critical): Tighten terminal screws to 0.5~0.8Nm using a torque screwdriver—under-tightening causes high resistance (signal loss), while over-tightening strips threads or damages conductors; recheck torque after initial thermal cycling.
• Installation & Wiring Safety:
  • Wire Preparation: Strip wire insulation to 8~10mm length—insulation protruding into terminals causes short circuits, while exposed conductors beyond 2mm increase shock risk; use wire stripping tools for consistent preparation.
  • Grounding Connection: Connect the dedicated ground terminal bar to the cabinet safety ground (resistance ≤1Ω)—improper grounding increases EMI susceptibility and creates safety hazards; use 4mm² green/yellow ground wire.
  • Polarity & Routing: Maintain consistent polarity (positive/negative) across terminals and route signal wires separately from power cables—crossed polarity causes incorrect readings, while signal/power cable proximity increases noise interference.
• Operation & Maintenance:
  • Label Maintenance: Keep terminal labels updated during wiring modifications—outdated labels lead to misidentification and incorrect connections during troubleshooting; use ABB's label printing tool for replacement labels.
  • 定期检查: Inspect quarterly for:
    • Loose terminals (common after vibration events)
    • Corroded contacts (in humid environments)
    • Damaged wire insulation (from sharp edges)
      Address issues immediately to prevent intermittent connections or short circuits.
  • Wire Management: Avoid exceeding 10A per terminal or bundling more than 10 wires per cable tie—overloading causes overheating, while over-bundling increases wire stress and makes modifications difficult.
• Environmental Limitations:
  • Temperature Extremes: Do not operate above +70℃ or below -25℃—high temperatures soften PA66 housing, while extreme cold makes it brittle; use cabinet heaters/coolers in extreme zones to maintain -25℃~+70℃.
  • Chemical Exposure: Avoid direct contact with strong solvents (e.g., acetone, methyl ethyl ketone) and concentrated acids—these degrade the terminal block housing and insulation; use protective covers in chemical processing areas.
• Replacement & Spare Parts:
  • Genuine ABB Components: Use only genuine ABB TU805K01 termination units—non-genuine alternatives often have substandard terminals (corrode easily) and poor fit with S800 racks, leading to increased wiring errors.
  • Spare Inventory: Maintain 1~2 spare units per 10 control cabinets—termination units are rarely replaced but critical for new installations or cabinet modifications; spares reduce project delays caused by supply chain issues
