ABB 57520001-ER/1 Industrial Component

1. Key Parameters

• Product Model: 57520001-ER/1
• Product Series: ABB 5752 Series Industrial Power Supply/Auxiliary Modules (Auxiliary Power for Automation Systems, 800xA/AC800M Compatibility)
• Core Function: Provides stabilized auxiliary power to ABB automation components (I/O modules, communication interfaces); offers overload and short-circuit protection; filters electrical noise; ensures compatible power delivery for modular control systems
• Electrical & Power Specifications:

  Parameter	Details	Performance Metrics
  Power Input	- Input Voltage Range: 100V AC~240V AC (50/60Hz, universal input) - Input Current: 1.5A (max, at 100V AC); 0.8A (max, at 240V AC) - Input Protection: Fuse (2A, slow-blow); surge protection (2kV, IEC 61000-4-5) - Power Factor: ≥0.9 (at full load, 230V AC, 50Hz)	Universal input eliminates the need for voltage selectors, simplifying global installations
  Power Output	- Output Voltage: 24V DC (regulated, ±1% accuracy) - Output Current: 5A (continuous); 7A (peak, 10s max) - Output Ripple & Noise: ≤50mVpp (at full load) - Load Regulation: ≤0.5% (from 10%~100% load)	Stabilized 24V DC output ensures consistent power for ABB S800 I/O modules (e.g., AI893, DI825) and communication interfaces (e.g., CI801)
  Protection Features	- Overload Protection: Current limiting (110%~150% of rated current, auto-recovery) - Short-Circuit Protection: Hiccup mode (prevents overheating during short circuits) - Overvoltage Protection: Clamping (30V DC max, latching) - Over-temperature Protection: Thermal shutdown (≥85℃, auto-recovery)	Protects connected ABB components from power anomalies (e.g., short circuits, voltage spikes) common in industrial grids
  Safety & Compliance	- EMI/RFI Immunity: EN 61000-6-2 (industrial immunity); EN 61000-6-4 (emission) - Safety Certification: IEC 61558-1, UL 60950-1, CSA C22.2 No. 60950-1 - Insulation Class: Class II (double insulation) - Dielectric Strength: 3kV AC (input to output, 1min)	Meets global safety standards for industrial power supplies, ensuring safe operation in control cabinets with exposed wiring

• Mechanical Specifications:
  • Dimensions: 90mm (W) × 150mm (L) × 60mm (H) (compact design for 19-inch control cabinets)
  • Mounting Type: DIN rail mount (EN 50022, 35mm top-hat rail); panel mount optional (via brackets)
  • Housing Material: Aluminum alloy (heat-dissipating) with polycarbonate front cover (UL 94 V0)
  • Weight: Approximately 450g
  • Cooling Method: Convection cooling (no fans, maintenance-free)
• Environmental Ratings:
  • Operating Temperature Range: -20℃~+70℃ (-4℉~158℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: 5%~95% RH (non-condensing, 40℃)
  • Altitude Rating: Up to 2000m (derated by 1% per 100m above 1000m)
  • Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6; no performance degradation)
  • Shock Resistance: 30g (11ms half-sine, IEC 60068-2-27; no mechanical damage)
• Compliance Standards: CE, RoHS, REACH, ABB Automation System Compatibility Standard (800xA V6.0+, AC800M V5.1+)

2. Key Features

• Universal AC Input (100V~240V): Eliminates voltage selector switches, enabling seamless installation in global industrial facilities (e.g., 110V AC in North America, 230V AC in Europe/Asia) without hardware modifications.
• Stabilized 24V DC Output: ±1% voltage accuracy and ≤50mVpp ripple ensure consistent power for ABB’s sensitive automation components—prevents data corruption in I/O modules (e.g., AI893 analog measurement errors) caused by unstable power.
• Fan-Free Convection Cooling: Maintenance-free operation with no moving parts—avoids dust accumulation (a common issue in manufacturing plants) and reduces failure points, extending service life to 10+ years.
• Comprehensive Protection Mechanisms: Overload, short-circuit, overvoltage, and over-temperature protection safeguard both the module and connected ABB devices—prevents costly damage from power grid fluctuations (e.g., voltage surges from motor startups).
• Compact DIN Rail Design: Fits standard 35mm DIN rails in 19-inch control cabinets—saves space compared to bulkier power supplies, enabling dense installation alongside S800 I/O racks and termination units (e.g., TU805K01).
• Wide Environmental Tolerance: -20℃~+70℃ operating range and 1g vibration resistance—operates reliably in extreme conditions: cold storage facilities, high-temperature process areas (e.g., refineries), and heavy machinery zones.
• Seamless ABB Compatibility: Tested for integration with ABB 800xA DCS, AC800M PLCs, and S800 I/O modules—ensures plug-and-play functionality without compatibility issues (e.g., voltage mismatches with CI801 communication interfaces).

3. Application Fields

• ABB Automation System Power Supply: Primary application—powering ABB control components:
  • Chemical Plant 800xA DCS Cabinets: Supplies 24V DC to S800 I/O modules (AI893, DI825) and CI801 fieldbus interfaces; stabilized output ensures accurate analog measurements (e.g., reactor pressure) and reliable fieldbus communication.
  • Automotive Factory AC800M Control Panels: Powers DI885 safety input modules and TU805K01 termination units; fan-free design avoids dust ingestion (common in paint shops), maintaining power stability for robot safety interlocks.
• Industrial Control Cabinet Auxiliary Power: Supporting low-power field devices:
  • Food Processing Line Control Cabinets: Provides 24V DC to photoelectric sensors and small actuators; wide temperature range (-20℃~+70℃) handles cold storage (dairy) and high-temperature (baking) zones, while non-condensing humidity tolerance prevents corrosion.
  • Water Treatment Plant Control Rooms: Powers flow meters, level switches, and S800 I/O modules; overload protection withstands current spikes from pump startups, ensuring uninterrupted monitoring of water purification processes.
• Critical Infrastructure Power Backup: Secondary power for essential components:
  • Oil Refinery Emergency Shutdown (ESD) Cabinets: Supplies backup power to safety I/O modules (DI885) and ESD controllers; dielectric strength (3kV AC) prevents damage from electrical transients, ensuring ESD systems remain operational during grid faults.
  • Data Center Industrial Control Systems: Powers temperature sensors and cooling unit controllers; low ripple output (≤50mVpp) avoids interference with sensitive data center equipment, maintaining stable environmental control.
• Mobile & Remote Automation: Power for portable control systems:
  • Mining Underground Control Stations: Supplies 24V DC to gas detectors and remote I/O modules; rugged design withstands vibration from mining machinery, while wide input voltage range (100V~240V) adapts to variable underground power grids.
  • Construction Site Temporary Control Panels: Powers temporary sensor networks and small PLCs; DIN rail mounting simplifies installation in portable cabinets, while universal input works with on-site generators (110V~240V).

4. Precautions

• Input Voltage Compliance (Critical): Ensure input voltage remains within 100V AC~240V AC—voltages outside this range damage the module; use a voltage stabilizer in regions with unstable grid power (e.g., remote mining sites) to avoid overvoltage/undervoltage events.
• Installation & Wiring Safety:
  • Polarity & Grounding: Follow correct output polarity (24V DC positive/negative) when connecting to ABB components—reverse polarity damages I/O modules (e.g., AI893) and voids warranties; connect the module’s ground terminal to cabinet safety ground (resistance ≤1Ω).
  • Load Capacity: Do not exceed the 5A continuous output current—overloading triggers hiccup mode, interrupting power to critical components; calculate total load (sum of I/O module, sensor, and actuator currents) before installation.
  • Wire Sizing: Use appropriate wire gauge for output connections (1.5mm² for ≤5A) — undersized wires cause voltage drops, leading to I/O module malfunctions; refer to ABB’s wiring guide for gauge recommendations.
• Operation & Maintenance:
  • Temperature Monitoring: Keep operating temperature below 70℃—install in well-ventilated cabinet areas away from heat sources (e.g., motor drives); use thermal imaging to check for hotspots (indicative of overload or poor ventilation).
  • 定期检查: Inspect quarterly for:
    • Loose input/output terminals (common after vibration)
    • Damaged housing (from mechanical impact)
    • Fuse integrity (replace with 2A slow-blow fuses only)
      Address issues immediately to prevent unexpected power loss.
  • Overload Testing: Periodically test overload protection by simulating a moderate current spike (6A, 5s)—verify the module enters hiccup mode and recovers automatically; avoid prolonged short circuits (＞10s) as they may damage internal components.
• Environmental Limitations:
  • Condensing Humidity: Do not operate in condensing humidity (>95% RH, 40℃)—condensation causes short circuits; use cabinet dehumidifiers in humid environments (e.g., water treatment plants) to maintain non-condensing conditions.
  • Altitude: Derate operation above 1000m (reduce maximum temperature by 1℃ per 100m)—high altitude reduces convection cooling efficiency, increasing the risk of thermal shutdown; install forced-air fans for altitudes >1500m (e.g., mountainous power plants).
• Replacement & Spare Parts:
  • Genuine ABB Components: Use only genuine ABB 57520001-ER/1 modules—non-genuine alternatives lack ABB’s safety certification and output stability, leading to premature component failure (e.g., damaged S800 I/O modules).
  • Spare Inventory: Maintain 1 spare module per 10 operational units—power supply failures disable entire control systems; spares reduce downtime from 2+ weeks (delivery lead time) to <1 hour for mission-critical applications (e.g., chemical plant ESD systems)
