The ABB TK812V150 is a specialized industrial-grade simplex plastic optical fiber (POF) engineered for long-range unidirectional communication in ABB automation systems—specifically optimized for ABB S800 I/O architectures, 800xA DCS, and AC800M PLCs where one-way data transmission (e.g., remote sensor-to-controller signals) over extended distances is critical. It functions as a "high-performance unidirectional optical link," leveraging a low-attenuation PMMA (polymethyl methacrylate) fiber core to transmit optical signals across longer spans, while retaining the inherent EMI immunity, flexibility, and easy installation of standard POF. Designed as the long-range variant of the TK812 series, it eliminates the need for costly glass fiber or signal repeaters in unidirectional industrial applications requiring distances up to 150m at 100Mbps. Below is its detailed specification:
- Product Model: TK812V150
- Product Series: ABB TK Series Simplex Plastic Optical Fibers (Long-Range Unidirectional Industrial Communication)
- Core Function: Enables long-distance unidirectional optical data transmission between ABB automation components (e.g., remote sensors to I/O modules, distributed terminals to central controllers); provides EMI-immune communication for extended industrial links; simplifies wiring with a single-fiber design; ensures compatibility with ABB optical interfaces (e.g., TB811, TU849)
- Optical & Transmission Specifications:
- Environmental Ratings:
- Operating Temperature Range: -20℃~+75℃ (-4℉~167℉)
- Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
- Humidity Tolerance: 5%~95% RH (non-condensing, 40℃)
- Chemical Resistance: Resistant to mineral oils, mild acids, alkalis, and industrial solvents (IEC 60068-2-54)
- Vibration Resistance: 10~500Hz, 1.5g acceleration (no fiber breakage or signal degradation)
- Compliance Standards: CE, RoHS, ABB Optical Communication Standard V2.2, UL 94 V0 (flame retardancy), IEC 61032 (electrical equipment safety), IEC 60793-2-40 (POF performance)
- Long-Range Unidirectional Transmission: Supports 150m at 100Mbps and 300m at 10Mbps—eliminates the need for signal repeaters or expensive glass fiber in extended unidirectional applications (e.g., 120m sensor links in large warehouses), reducing system costs by 35%.
- Ultra-Low Attenuation (≤8dB/km): Ultra-pure PMMA core minimizes signal loss—maintains reliable data transmission (BER ≤10⁻¹²) across long spans, critical for time-sensitive applications like process control in large chemical plants.
- Inherent EMI/RFI Immunity: Plastic optical fiber rejects electromagnetic and radio frequency interference—ideal for installation near high-noise equipment (e.g., large motor drives, transformers) in steel mills or automotive plants, where copper cables suffer from data corruption.
- Tool-Free Installation: Large 1mm core and push-pull connectors simplify termination—field technicians can achieve secure connections without specialized tools (e.g., polishers for glass fiber), cutting installation time by 50% for long-distance runs.
- Robust 4mm UV-Stabilized Jacket: Flame-retardant (UL 94 V0), oil-resistant, and UV-stabilized design—withstands harsh industrial conditions: mechanical stress during conduit routing, oil exposure in refineries, and UV radiation in indoor-outdoor transitions (e.g., warehouse loading docks).
- Dust-Sealed Connectors: Protects optical interfaces from industrial debris—ensures consistent performance in dusty environments (e.g., mining processing plants, cement factories) where unprotected connectors suffer from signal loss.
- Seamless ABB Compatibility: Integrates with ABB optical components (TB811, S800 modules)—no adapters or protocol converters required, ensuring system-wide reliability and reducing integration complexity.
- ABB Automation System Long-Distance Links: Primary use in extended unidirectional paths:
- 800xA DCS Large-Scale Process Plants: Transmits 4~20mA pressure/temperature data from remote reactor skids (150m from main control room) to S800 AI modules—ultra-low attenuation ensures accurate process measurements for batch control in large refineries.
- AC800M PLC Factory Campus Networks: Connects distributed I/O terminals (120m between factory buildings) to central AC800M PLCs—simplex design reduces wiring costs vs. duplex fibers, while EMI immunity avoids interference from campus power lines.
- Heavy Industry Extended Monitoring: Long-range communication in harsh environments:
- Steel Mill Hot Rolling Complexes: Sends roll temperature data (thermocouple signals) 100m from rolling mills to 800xA DCS—EMI immunity withstands interference from mill drives, avoiding false temperature alarms that disrupt production.
- Mining Surface Operations: Transmits conveyor belt status signals (DI) 180m from outdoor stockpiles to indoor control cabinets—UV-stabilized jacket resists sun exposure, while dust-sealed connectors prevent debris from affecting signal quality.
- Infrastructure & Large-Scale Facilities: Supporting wide-area monitoring:
- Water Treatment Plant Pipeline Networks: Links flow meters and pH sensors (200m along pipelines) to S800 I/O modules—unidirectional design reduces costs vs. duplex fibers, while EMI immunity eliminates ground loops from pump systems.
- Warehouse Automation Systems: Connects barcode scanners and inventory sensors (150m across large warehouses) to AC800M PLCs—flexible bending (30mm static radius) simplifies routing around racking, while tool-free installation speeds up warehouse expansion.
- Cost-Effective Retrofit Projects: Upgrading legacy systems with long links:
- Chemical Plant Legacy DCS Modernization: Replaces 150m copper cables with POF for sensor-to-controller links—eliminates ground loops that caused measurement drift in the old system, improving process accuracy by 25%.
- Metro Rail Maintenance Facilities: Transmits train component test data (100m from test bays to control room) to 800xA DCS—EMI immunity avoids interference from rail power systems, ensuring reliable test results.
