ABB TK811F (3BDM000103R1) Bus Cable

1. Key Parameters

• Product Model: TK811F
• Order Code: 3BDM000103R1
• Product Series: ABB TK Series Industrial Bus Cables (High-Speed Data, Compatible with ABB AC800M/800xA Automation Networks)
• Core Function: Transmits real-time data between ABB automation devices (PLCs, DCS modules, remote I/O); minimizes electromagnetic interference (EMI) and radio frequency interference (RFI); provides mechanical protection against industrial stress; ensures compliance with industrial communication standards
• Electrical Specifications:

  Parameter	Details	Performance Metrics
  Communication Performance	- Supported Protocols: ABB AC 800M Backplane Bus, PROFINET RT/IRT, Modbus TCP (100Mbps) - Maximum Data Rate: 100Mbps (full-duplex) - Signal Attenuation: ≤0.5dB/m (at 100MHz) - Signal-to-Noise Ratio (SNR): ≥30dB (at 100Mbps)	Enables real-time data transmission (≤1ms latency) for time-sensitive control loops (e.g., turbine speed regulation, chemical dosing)
  Conductor Configuration	- Conductor Material: Tinned copper (high conductivity, corrosion-resistant) - Conductor Structure: 2× twisted pairs (STP); 24 AWG (0.22mm²) per conductor - Twist Rate: 10mm~15mm (pair 1); 12mm~17mm (pair 2) (differential twist for EMI cancellation) - Resistance: ≤85Ω/km (conductor resistance at 20℃); ≤15Ω/km (shield resistance)	Twisted pairs with differential twist reduce crosstalk by 40% vs. non-twisted cables; tinned copper ensures low signal loss over long distances
  Insulation & Shielding	- Insulation Material: Polyethylene (PE, low dielectric loss) - Shielding: Dual-layer (aluminum foil + tinned copper braid); coverage ≥95% - Outer Sheath: Halogen-free flame-retardant (HFFR) PVC; thickness 0.8mm~1.0mm - Dielectric Constant (εr): ≤2.3 (at 1MHz)	Dual shielding blocks 99% of EMI/RFI (e.g., from motor drives, high-voltage cables); HFFR sheath reduces smoke/toxic gas emission in fire
  Safety & Compliance	- Insulation Resistance: ≥100MΩ (at 500V DC, 20℃) - Flame Class: UL 94 V0 / IEC 60332-1-2 (self-extinguishing within 10s) - Voltage Withstand: 1500V AC (1min, conductor to shield) - Crosstalk: ≤-60dB (at 100MHz, near-end crosstalk)	Prevents signal leakage and fire propagation; low crosstalk ensures data integrity in multi-cable installations (e.g., control cabinet cable trays)

• Mechanical Specifications:
  • Cable Diameter: 6.0mm~7.0mm (outer diameter)
  • Standard Length: 100m (custom lengths: 1m~500m available via ABB customization)
  • Connector Compatibility: ABB M12 D-coded connectors (for AC800M backplane), RJ45 (for PROFINET/Modbus TCP); crimpable to ABB-approved terminals
  • Mechanical Durability:
    • Flex Life: ≥5,000 cycles (IEC 60245, 10× cable diameter bending radius)
    • Impact Resistance: IK06 (IEC 62262, resistant to 1J impacts)
    • Abrasion Resistance: ≥1,000 cycles (CS 10 wheel, 10N load)
  • Weight: Approximately 0.6kg/m (for 100m length)
• Environmental Ratings:
  • Operating Temperature Range: -40℃~+80℃ (continuous); -50℃~+90℃ (short-term, ≤1 hour)
  • Storage Temperature Range: -40℃~+85℃
  • Humidity Tolerance: 95% RH (non-condensing, 40℃)
  • Chemical Resistance: Resistant to mineral oil, mild acids/bases, and industrial dust (per IEC 60068-2-54)
  • Ingress Protection (IP): IP20 (cable sheath); IP67 (when used with M12 connectors)
  • Vibration Resistance: 10~500Hz, 2g acceleration (IEC 60068-2-6; no signal loss or conductor breakage)
• Compliance Standards: IEC 61156-5 (industrial Ethernet cables), EN 50173-1 (communication cabling), UL 444 (communication cables), CE, RoHS, GB/T 18287 (China industrial Ethernet cables)

2. Key Features

• High-Speed Real-Time Data Transmission: Supports 100Mbps full-duplex data rates with ≤1ms latency—ideal for time-sensitive ABB automation networks (e.g., 800xA DCS controlling refinery distillation columns), ensuring process variables (temperature, pressure) are transmitted without delay.
• Dual-Layer EMI/RFI Shielding: Aluminum foil + 95% coverage copper braid block electromagnetic interference from industrial equipment (e.g., motor drives, welders)—prevents signal corruption (e.g., false sensor readings) that could cause control errors or production stoppages.
• Twisted-Pair Conductor Design: Two twisted pairs with differential twist rates minimize crosstalk (≤-60dB at 100MHz)—enables installation in dense cable trays (with other power/control cables) without signal interference, simplifying cabinet wiring.
• Halogen-Free Flame Retardancy (HFFR): HFFR PVC sheath emits minimal smoke and toxic gas in fire—complies with safety standards for enclosed industrial spaces (e.g., power plant control rooms) and public infrastructure, reducing health risks during emergencies.
• Wide Temperature & Environmental Adaptability: -40℃~+80℃ operating range, 2g vibration resistance, and 95% humidity tolerance—operates reliably in extreme environments (e.g., arctic oil rigs, desert solar plants, coastal refineries) without performance degradation.
• ABB Automation Ecosystem Compatibility: Optimized for ABB AC800M PLCs, 800xA DCS, and remote I/O units—works seamlessly with ABB’s communication protocols (AC 800M backplane bus) and connectors (M12 D-coded), eliminating compatibility issues and reducing commissioning time.
• Long-Distance Signal Integrity: Low attenuation (≤0.5dB/m at 100MHz) and high SNR (≥30dB) ensure data integrity over 100m+ distances—enables decentralized control (e.g., remote I/O in mining tunnels) without signal repeaters, lowering system costs.

3. Application Fields

• ABB AC800M/800xA Automation Networks: Primary application—data transmission in ABB control systems:
  • Refinery DCS Systems: Connects 800xA DCS modules (e.g., AI830 analog input) to AC800M PLCs in refinery distillation units; dual shielding resists EMI from high-voltage process cables, ensuring accurate transmission of temperature/pressure data (critical for hydrocarbon separation).
  • Power Plant Control Loops: Transmits real-time data between AC800M PLCs and remote I/O units (e.g., DI830 digital input) in coal-fired power plants; 100Mbps data rate enables ≤1ms latency for boiler feedwater control, preventing overpressure incidents.
• Industrial Manufacturing Automation: Data backbone for production lines:
  • Automotive Assembly Lines: Links ABB robotic control units to 800xA DCS via PROFINET RT; twisted pairs minimize crosstalk from nearby welding equipment, ensuring precise robot movement (±0.1mm accuracy) for vehicle body assembly.
  • Electronics Production Cleanrooms: Connects AC800M PLCs to compact 800xA I/O modules for semiconductor manufacturing; HFFR sheath meets cleanroom standards (low particle emission), while low attenuation enables data transmission over 50m+ cleanroom aisles.
• Mining & Minerals Decentralized Control: Data transmission in remote mining environments:
  • Underground Mining Control Systems: Connects surface AC800M PLCs to underground remote I/O units (e.g., for conveyor speed monitoring); -40℃ low-temperature rating withstands cold mine shafts, and dual shielding resists EMI from mining machinery (crushers, hoists).
  • Open-Pit Mine Material Handling: Transmits data between 800xA DCS and mobile I/O units on conveyor belts; 2g vibration resistance handles conveyor motion, while IP67 M12 connectors (when used with the cable) protect against dust and water spray.
• Energy & Utility Infrastructure: Data transmission in energy systems:
  • Wind Turbine Control Networks: Connects on-turbine AC800M PLCs to offshore 800xA DCS; HFFR sheath resists saltwater corrosion, and wide temperature range (-40℃~+80℃) handles offshore weather extremes (high winds, temperature swings).
  • Solar Plant Inverter Control: Links solar inverter I/O units to 800xA DCS via Modbus TCP; low attenuation enables 100m+ transmission between inverter arrays and the central control room, ensuring real-time power output monitoring.
• Water & Wastewater Treatment: Data transmission for process control:
  • Wastewater Treatment Plants: Connects 800xA DCS modules to remote I/O units (e.g., AO830 analog output) for chemical dosing control; 95% humidity tolerance withstands damp treatment facility environments, while dual shielding resists EMI from pump motors.
  • Desalination Plants: Transmits data between AC800M PLCs and high-pressure pump control units; voltage withstand (1500V AC) protects against electrical transients from seawater electrolysis, ensuring stable pump operation.
