ABB TGM5-Ex 14436-0-1072510 Angle Transmitter

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Model

ABB TGM5-Ex (Order number 14436-0-1072510) Angle Transmitter

Technical Specifications

• Series: TGM5 / TGM5-Ex (Ex version for explosion-protected use)

• Function: Converts angular position of a mechanical shaft into a load-independent DC signal.

• Accuracy: Non-linearity < 1%; for range <90° versions: < 0.5%.

• Response time: < 50 ms (for a 0→100% jump).

• Ambient temperature: –25 °C … +80 °C (storage/transport: –40 °C … +80 °C).

• Wiring: 2, 3 or 4-wire circuits available (Ex version: typically 2-wire).

• Housing: Salt-water proof cast aluminium, anodised surface.

• Mechanical stress capability: Tested to DIN IEC 68-2-27/68-2-6 (impact 50 g/11ms, vibration 5 g ±10mm/5-150Hz).

• Protection rating: Up to IP66 in bearings + sealing ring version; ball bearing version approx IP56 (depending on variant).

• Explosion protection (Ex version): Intrinsic safety i, EEx ib IIC T4/T6, suitable for hazardous area Zone 1/2.

• Output signal / measuring range: Customisable outputs (e.g., 4-20 mA), measuring ranges (e.g., 0-30°, 0-50°, 0-90°) as ordered.

Advantages & Key Features

• High-precision angular measurement: Very low non-linearity and fast response make it ideal for dynamic shaft position monitoring.

• Robust mechanical design: Aluminium housing, corrosion resistance, high vibration/impact endurance suit harsh industrial environments.

• Explosion-proof model available: The Ex version allows safe use in combustible gas or vapour environments.

• Flexible installation: Shaft-mounted type suitable for heavy machinery, marine, offshore; customisable range and output signal.

• Universal wiring options: Supports 2, 3, 4-wire wiring making integration with various control systems easier.

• Long-term stability: Long-term drift less than 0.2% per year, reducing recalibration needs.

Application Areas

• Marine & offshore engineering: Shaft angle feedback on ships, offshore platforms where environment is demanding.

• Heavy machinery: Monitoring of fan, pump, valve, turret, or other rotating equipment shaft angle.

• Industrial automation & process control: Converting mechanical shaft position to electrical signal for PLC/DCS feedback.

• Petrochemical / oil & gas / hazardous area applications: Ex version for installation in combustible atmospheres.

• Maintenance / retrofit: Replacement or upgrade component for shaft position transducers in existing systems.

Precautions

• Prior to installation verify that the correct version is selected (Ex vs non-Ex), correct measuring range, correct output signal and compatibility with your system.

• Ensure the mechanical connection to the shaft is correct, and that radial/axial loads do not exceed specification for that version.

• In high vibration or corrosive environments ensure proper sealing, mounting and fasteners are correctly installed.

• For Ex versions require intrinsically safe power supply and comply with explosion-protection installation standards.

• Perform periodic checks of zero offset, span output, and signal accuracy to maintain measurement integrity.

• Although robust, avoid using beyond specified temperature/humidity limits to maximise service life.

The structure and details of the product：
