ABB SB522V1 3BSC760015R1 battery cell

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Model

ABB SB522V1 (Order number 3BSC760015R1) Battery Unit

Technical Specifications

• Model: SB522V1 Battery Unit for AC400 Systems.

• Battery Chemistry: Nickel-Metal Hydride (NiMH).

• Rated Voltage: 12 V DC.

• Rated Capacity: approx. 4.0 Ah (some sources list 3.6 Ah).

• Internal Fuse: 3.4 A.

• Net Weight: approx. 1.205 kg.

• Dimensions (reference for replacement type): length approx. 340.5 mm × width 71.2 mm × height 18.3–19 mm.

• Application System: Intended for use in ABB AC400 series control systems as a backup battery unit.

• Regulatory/Environmental Note: NiMH battery type; manufacturer notes indicate compliance or consideration of RoHS directives.

Advantages & Key Features

• Reliable backup power function: Provides stable 12 V backup supply in the AC400 control system when the primary power is interrupted.

• NiMH battery technology benefits: Offers good cycle life, lower memory effect, better environmental profile compared to older nickel-cadmium batteries.

• Capacity and form-factor match: With approx. 4 Ah capacity and correct physical dimensions and interfaces, the unit fits seamlessly as original or replacement.

• Built-in protection: Includes a 3.4 A internal fuse to provide basic protection against internal fault or over-current conditions.

• OEM/Replacement part: Being an ABB original battery unit or matching replacement, it helps maintain system consistency.

• Weight and installation suitability: At around 1.2 kg, the unit is manageable for installation or replacement in control cabinets.

Application Areas

• Industrial automation control systems: Used in ABB AC400 platform as backup power for control units.

• Process control and monitoring systems: In sectors like chemical, petrochemical, power generation, manufacturing, metallurgy, where control systems require backup supply.

• Instrumentation and control cabinets: Installed in distribution or control cabinets, serving as power hold-up battery units.

• Maintenance and spare replacement: Utilised as original or compatible replacement for system maintenance, upgrades, spare holdings.

Precautions

• Before installation, verify that the battery model, voltage (12 V), chemistry (NiMH) and capacity match your system requirements; mismatched capacity might result in insufficient backup time.

• During replacement, ensure the system is powered off and follow the manufacturer’s handbook or system manual instructions to avoid damaging the battery or system.

• Although NiMH batteries are more advanced than NiCd, they still require attention to conditions such as temperature, charge state and storage environment to avoid shortening service life.

• When storing spare batteries, keep in a dry, well-ventilated area, and avoid extreme temperatures (high or low) to preserve battery health.

• Periodic maintenance checks are advisable: check battery voltage, capacity retention, whether any swelling or corrosion is present at the terminals.

• While the unit provides backup power, it should be part of a complete power design and backup system; do not rely solely on this battery unit to handle all power failure scenarios.

The structure and details of the product：
