ABB SNAT633PAC Pulse Amplifier Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB SNAT633PAC is a high-performance Pulse Amplifier Board designed for industrial automation and motor control systems. It receives pulse signals from sensors or encoders and amplifies and processes them to provide stable output to the control system, enabling precise position and speed control.

Technical Specifications

• Model / Part Number: SNAT633PAC

• Type: Pulse Amplifier Board

• Input Signal: Encoder or sensor pulse signals

• Output Signal: TTL/HTL pulses, compatible with servo drives or PLCs

• Supply Voltage: 24 V DC

• Response Time: < 1 µs

• Operating Temperature: -20°C ~ +70°C

• Storage Temperature: -40°C ~ +85°C

• Protection Rating: IP20

• Mounting: DIN rail or panel mount

• Dimensions: ~120 mm × 100 mm × 25 mm

• Weight: ~0.4 kg

• Certification: CE, IEC compliant

Advantages & Features

1. High-Speed Pulse Processing: Fast response ensures precise position and speed control.

2. Stable Signal Output: Amplifies and shapes sensor signals for reliable control system input.

3. Wide Compatibility: Supports TTL/HTL signals, compatible with various controllers and drives.

4. Modular Design: Facilitates replacement and maintenance, improving system reliability.

5. Industrial-Grade Reliability: Wide operating temperature range for harsh industrial environments.

6. Easy Installation: DIN rail or panel mounting for convenient on-site wiring.

Application Areas

• Industrial automation servo drive systems

• Motor position and speed control

• Robotics and automated production lines

• Packaging, printing, and processing equipment

• Industrial inspection and testing platforms

• PLC and control system signal interfacing

Precautions

1. Ensure pulse signal type and voltage match the amplifier board specifications.

2. Install in a dry, ventilated environment, avoiding corrosive gases.

3. Handle wiring with ESD protection.

4. Regularly check connections to ensure stable signal transmission.

5. Avoid disassembling the amplifier board while energized.

6. Follow electrical installation and safety standards.

The structure and details of the product：

 Please make an inquiry for more models
