ABB SDCS-PIR-21 Buffer Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

 1. Product Overview

The ABB SDCS-PIR-21 Buffer Board is a key signal buffering and relay module for industrial automation, robot control systems, and drive modules. It stabilizes, isolates, and extends signals to ensure integrity and reliability during long-distance transmission or multi-module connections of high-speed pulse, analog, or digital signals. The SDCS-PIR-21 supports multiple input/output types, with industrial-grade interference resistance, making it an essential component in ABB automation modular systems.

2. Main Technical Parameters (Typical)

Electrical Data

• Model: SDCS-PIR-21

• Power supply: 24 V DC

• Signal types: Pulse, digital, analog

• Input interface: TTL, HTL, or differential signals

• Output interface: Drive-compatible signal output

• Max input frequency: 500 kHz–1 MHz (depending on configuration)

• Response time: <1 µs

• Protection features: Overvoltage, short-circuit, and ESD protection

Mechanical & Installation

• Mounting: DIN rail or modular control cabinet installation

• Dimensions: Compact PCB module

• Weight: approx. 0.4–0.7 kg

Environmental & Operating Conditions

• Operating temperature: 0°C to +50°C

• Storage temperature: ‑20°C to +70°C

• Relative humidity: 5%–95% (non-condensing)

• Industrial EMI/RFI protection

• Protection level: Suitable for control cabinet internal use

Standards & Certifications

• IEC/EN 61131 series standards

• CE, RoHS certified

3. Advantages and Features

• Signal stabilization: Effectively buffers high-speed pulse, digital, and analog signals

• Multi-interface compatibility: TTL, HTL, differential signals for various drives and sensors

• High-speed response: Microsecond-level response ensures precise control

• Modular design: Easy installation, maintenance, and system expansion

• Industrial reliability: ESD and overvoltage protection, suitable for industrial environments

• Signal isolation: Reduces interference and improves system reliability

4. Typical Applications

• ABB industrial robot control systems

• High-precision signal interfaces in automated production lines

• CNC and precision machinery control

• Automated assembly and material handling equipment

• Signal buffering and interface extension for drive modules

• Signal stabilization and isolation in industrial process control systems

5. Application Notes

• Ensure input/output signal types match the system

• Power supply must be stable 24 V DC

• Install in well-ventilated areas away from high-interference sources

• Do not exceed maximum input frequency

• Regularly check terminals and signal integrity

• Avoid long-term operation in high humidity, corrosive, or dusty environments

The structure and details of the product：
