ABB SDCS-PIN-205 Pulse Interface Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

 1. Product Overview

The ABB SDCS-PIN-205 Pulse Interface Board is a key signal interface module in industrial automation and robot control systems. It receives and sends pulse signals to enable precise position and speed control of servo or stepper motors. The board supports high-speed pulse processing, multiple pulse input types, and provides multiple protection features, ensuring stable and reliable operation. SDCS-PIN-205 integrates seamlessly with ABB automation controllers and drives, supporting modular installation and system expansion.

2. Main Technical Parameters (Typical)

Electrical Data

• Model: SDCS-PIN-205

• Power supply: 24 V DC

• Pulse input types: TTL, HTL, differential pulse

• Pulse output types: TTL or drive-compatible pulse output

• Max input frequency: 1 MHz (system dependent)

• Control interface: High-speed pulse interface, compatible with incremental or absolute encoders

• Communication interfaces: Industrial bus (CAN, EtherCAT, or ABB dedicated bus)

• Protection features: Overvoltage, short-circuit, and ESD protection

• Response time: <1 µs (typical)

Mechanical & Installation

• Mounting: DIN rail or control cabinet modular installation

• Dimensions: Compact PCB module

• Weight: approx. 0.5–0.8 kg

Environmental & Operating Conditions

• Operating temperature: 0°C to +50°C

• Storage temperature: ‑20°C to +70°C

• Relative humidity: 5%–95% (non-condensing)

• Industrial EMI/RFI protection design

• Protection level: Suitable for control cabinet internal use

Standards & Certifications

• Compliant with IEC/EN 61131 series standards

• CE, RoHS certified

3. Advantages and Features

• High-speed pulse processing: Supports up to 1 MHz pulse input for high-dynamic motion control

• Multiple pulse type compatibility: TTL, HTL, differential pulses for flexible sensor and drive adaptation

• Closed-loop control support: Works with servo and stepper drives for precise motion

• Modular design: Easy installation, maintenance, and system expansion

• Industrial reliability: ESD and overvoltage protection, suitable for industrial environments

• Strong compatibility: Seamless integration with ABB controllers and drives

4. Typical Applications

• Servo/stepper control for ABB industrial robots

• High-precision motion control in automated production lines

• CNC and high-precision machinery control

• Automated assembly and material handling equipment

• Pulse signal interface for industrial process control systems

5. Application Notes

• Ensure pulse type matches the drive/encoder specifications

• Power supply must be stable 24 V DC

• Install in ventilated areas, away from strong interference sources

• Avoid exceeding max pulse input frequency to prevent signal loss

• Regularly check terminals and signal integrity

•

The structure and details of the product：
