ABB SDCS-PIN-46 Pulse Transformer Interface Board

1. Key Parameters

• Product Model: SDCS-PIN-46
• Product Series: ABB SDCS-Series Industrial Converter Pulse Interface Boards (Isolated Pulse Management)
• Core Function: High-frequency pulse isolation/conditioning; noise filtering; control-power device signal linkage; compatible with ABB SDCS converters.

2. Core Features

• Enhanced Isolation: 3kVrms isolation blocks high-voltage feedback from power devices to control circuits, safeguarding sensitive electronics.
• Broad Frequency Support: 500Hz-200kHz range adapts to fast-switching IGBTs, ensuring pulse integrity in high-frequency converter operation.
• Noise Filtering: Integrated filtering reduces EMI-induced pulse distortion, critical for stable power device switching.
• SDCS Compatibility: Factory-matched to ABB SDCS-series converters, enabling plug-and-play integration without calibration.

3. Application Fields

• ABB SDCS Converters: Transmits conditioned pulses between control boards and IGBT/thyristor modules in ACS800/ACS880 frequency converters.
• Industrial Motor Drives: Supports isolated pulse delivery for motor drive inverters in pumps, fans, and heavy machinery.
• Power Conversion Systems: Facilitates pulse transmission in auxiliary converters for railway, marine, and renewable energy equipment.

4. Precautions

• Compatibility: Use exclusively with ABB SDCS-series converters; avoid non-ABB or incompatible models.
• Installation: Follow ESD protection (anti-static tools); ensure correct input/output wiring to prevent pulse misalignment.
• Handling: Avoid mechanical stress on pins; limit solder reflow temperature to ≤260℃ during replacement.
• Spare Parts: Use genuine ABB SDCS-PIN-46 units—non-genuine boards may have poor isolation or filtering, causing power device malfunctions.

The structure and details of the product：

 Please make an inquiry for more models
