The ABB SDCS-PIN-41 is a high-reliability industrial pulse transformer engineered for signal isolation in power electronic control circuits—primarily compatible with ABB ACS880/ACS6080 medium-to-high power variable frequency drives (VFDs) and DCS500/DCS600 DC drives. It functions as a critical isolation component between low-voltage control circuits (e.g., trigger boards, logic controllers) and high-voltage power semiconductor devices (e.g., IGBTs, thyristors), transmitting precise trigger pulses while providing electrical isolation to prevent ground loops and protect sensitive control electronics. Designed for industrial-grade robustness, low signal distortion, and high isolation integrity, it operates stably in harsh environments (e.g., steel mills, mining sites, large-scale manufacturing) where electrical noise, voltage transients, or thermal stress could degrade pulse transmission or compromise isolation. Below is its detailed specification:
- Product Model: SDCS-PIN-41
- Order Code Reference: Typically paired with ABB drive accessory kits (e.g., 3ABD00032157 for ACS880-04, 3ABD00032160 for DCS600) for procurement consistency
- Product Series: ABB High-Power Drive Pulse Isolation Transformers
- Core Function: Isolates and transmits high-speed trigger pulses between control circuits and power semiconductors; prevents noise coupling between low-voltage and high-voltage domains; maintains pulse integrity for reliable switching of IGBTs/thyristors
- Electrical & Pulse Specifications:
- Mechanical & Thermal Specifications:
- Package Type: Epoxy-encapsulated, PCB-mountable; flame-retardant housing (UL94 V-0)
- Dimensions (L×W×H): 30mm × 20mm × 15mm (compact for dense drive layouts)
- Mounting: Through-hole PCB mounting (4 pins; 2.54mm pitch)
- Weight: Approximately 25g
- Terminal Configuration: Primary (input): 2 pins; Secondary (output): 2 pins (isolated)
- Environmental & Thermal Ratings:
- Operating Temperature Range: -40℃~+105℃ (-40℉~221℉)
- Storage Temperature Range: -55℃~+125℃ (-67℉~257℉)
- Humidity Tolerance: ≤95% RH (non-condensing, 40℃; suitable for damp industrial areas)
- Vibration Resistance: 10~2000Hz, 20g acceleration (IEC 60068-2-6; no mechanical damage)
- Shock Resistance: 100g acceleration (11ms duration, IEC 60068-2-27; no winding damage)
- Compliance Standards: IEC 61558-2-16 (safety transformers), EN 61000-6-2 (EMC immunity), UL 1446 (insulation systems), CE, RoHS
- High-Voltage Isolation (5kVrms): Provides reinforced isolation between low-voltage control circuits (e.g., 24V DC trigger signals) and high-voltage power semiconductors (e.g., 1200V IGBTs)—prevents ground loops and voltage transients from damaging sensitive control electronics in high-power drives.
- Low Pulse Distortion: Maintains pulse width distortion ≤2% and timing accuracy ±50ns across 10μs~1ms pulse widths—critical for precise switching of IGBTs in ACS880 VFDs, where microsecond-level timing errors can cause excessive power dissipation or device failure.
- Wide Frequency Response (10kHz~1MHz): Supports high-speed pulse transmission required for modern power semiconductors (e.g., fast-switching IGBTs with 100ns turn-on time)—avoids signal attenuation in high-frequency trigger circuits.
- Extreme Temperature Tolerance (-40℃~+105℃): Operates reliably in the high-heat environments of power drive cabinets (e.g., near IGBT modules with case temperatures up to 85℃)—eliminates the need for additional cooling in dense layouts.
- Epoxy Encapsulation: Flame-retardant (UL94 V-0) epoxy encapsulation protects windings from dust, moisture, and mechanical stress—ensures long-term reliability (≥10 years) in harsh industrial environments (e.g., mining, steel processing).
- Drop-In Compatibility: Direct replacement for older ABB pulse transformers (e.g., SDCS-PIN-31) in ACS880/ACS6080/DCS600 drives—pinout and performance match, simplifying retrofits without circuit redesign.
- ABB High-Power Drive Trigger Circuits: Primary application—pulse isolation in semiconductor control:
- ACS880-04 VFD IGBT Control: Isolates trigger pulses between SDCS-CON-5 control boards and 1200V/600A IGBT modules in 400kW~630kW drives; 5kVrms isolation prevents noise from motor cables coupling into control signals, ensuring stable switching in steel mill rolling drives.
- DCS600 DC Drive Thyristor Control: Transmits pulses between PG6310 trigger boards and 1600V/200A thyristors in 100kW~300kW DC drives; low distortion maintains precise firing angles (±0.5°), critical for DC motor speed regulation in mining hoists.
- Industrial Power Electronics: Supports isolation in custom power circuits:
- Custom Rectifier Systems: Isolates control pulses for thyristor bridges in industrial rectifiers (e.g., for battery charging); wide temperature range (-40℃~+105℃) adapts to outdoor power cabinets in renewable energy systems.
- Active Harmonic Filters: Transmits gate pulses to IGBTs in harmonic mitigation systems; high-frequency response (up to 1MHz) enables fast switching to cancel grid harmonics in factory power distribution.
- Heavy-Duty Automation: Enables safe signal transmission in high-voltage systems:
- Cement Kiln Drives: Isolates trigger signals in 500kW+ kiln rotation VFDs; epoxy encapsulation resists dust and vibration, ensuring reliable operation in cement plant environments.
- Marine Propulsion Drives: Transmits pulses in shipboard VFDs; humidity tolerance (95% RH) withstands marine environments, while 5kVrms isolation protects control systems from voltage spikes in ship grids.
The structure and details of the product：
