ABB SDCS-IOB-21 Input/Output Board

Product Description

Key Specs

• System Compatibility: Exclusive to ABB ACS800 series inverters; connects to the inverter’s main control board (SDCS-CON-11/12) via a dedicated 26-pin ribbon cable; compatible with inverter firmware v4.0+.
• I/O Configuration:
  • Analog Inputs (AI): 4 channels (AI1-AI4)
    • Signal types: 0-10V DC (input impedance 100kΩ) / 4-20mA DC (input impedance 250Ω), software-configurable per channel.
    • Resolution: 12-bit (±0.1% full-scale accuracy); sampling rate: 100Hz.
  • Analog Outputs (AO): 2 channels (AO1-AO2)
    • Signal types: 0-10V DC (max load 1kΩ) / 4-20mA DC (max load 500Ω), software-configurable.
    • Resolution: 12-bit; update rate: 50Hz.
  • Digital Inputs (DI): 8 channels (DI1-DI8)
    • Signal type: 24V DC sinking (NPN); input voltage range: 18-30V DC.
    • Response time: ≤1ms (for critical control signals like emergency stop).
  • Digital Outputs (DO): 4 channels (DO1-DO4)
    • Signal type: 24V DC transistor output (sourcing, PNP); max current per channel: 0.5A.
    • Protection: Short-circuit protection (self-resetting after fault removal).
• Power Supply: Takes 24V DC from the inverter’s auxiliary power port; power consumption ≤3W (no external power required).
• Mechanical & Environmental:
  • Dimensions (W×H×D): 150mm×100mm×30mm (PCB with plastic mounting bracket); weight ~150g.
  • Protection Degree: IP20 (mounted inside the inverter cabinet, isolated from high-voltage components).
  • Operating Conditions: -10°C~+50°C, 5%-95% RH (non-condensing); EMC compliance: EN 61000-6-2 (industrial immunity).
• Mounting: Secured to the ACS800 inverter’s internal chassis via 4 M3 screws (tool-mounted); no DIN rail required.

Core Functions

1. I/O Signal Expansion:
   • Adds 4 AI/2 AO/8 DI/4 DO to the ACS800 inverter, addressing the limitation of the inverter’s native I/O (typically 2 AI/1 AO/6 DI/2 DO) for complex applications (e.g., multi-sensor process control).
   • Supports mixed signal types (analog for process variables, digital for discrete commands) to connect diverse devices (e.g., pressure transmitters, limit switches, indicator lamps).
2. Signal Conditioning & Isolation:
   • Filters analog input signals (via built-in RC filters) to reduce noise from industrial environments (e.g., nearby motors, inverters), ensuring stable feedback for closed-loop control (e.g., precise pressure regulation in pumps).
   • Provides channel-to-channel isolation for analog signals (500V AC, 1min) to prevent ground loops and cross-interference between I/O circuits.
3. Fault Monitoring & Indication:
   • Built-in LED indicators for each I/O channel:
     • AI/AO: Green LED (ON = valid signal); DI: Green LED (ON = input active); DO: Green LED (ON = output active).
     • Red "Fault" LED (ON = short-circuit in DO, overvoltage in AI, or power failure) for quick troubleshooting.
   • Transmits I/O fault status to the inverter’s main control board, triggering alarm messages on the inverter’s HMI (e.g., "DO2 Short Circuit").
4. Seamless Inverter Integration:
   • I/O signals are directly mapped to the ACS800’s control software (configurable via ABB DriveComposer or Control Panel); no external gateways or protocol conversion needed.
   • Supports inverter control logic (e.g., "start inverter only if DI1 (pressure OK) and DI2 (temperature OK) are active") using the expanded I/O.

Core Advantages

1. Inverter-Specific Optimization: Tailored for ACS800 series—plug-and-play with the main control board, eliminating compatibility issues (e.g., signal latency, protocol mismatches) common with third-party I/O boards.
2. High Signal Accuracy: 12-bit resolution for analog I/O ensures precise measurement and control (e.g., ±0.01bar pressure regulation in water treatment pumps), improving process quality.
3. Cost-Effective Expansion: Avoids the need for external I/O modules or PLCs to expand the inverter’s control capability, reducing system complexity and overall costs.
4. Reliable Protection: Short-circuit protection for DO and noise filtering for AI minimize I/O board damage and inverter downtime in harsh industrial conditions.

Applications

1. Mining Conveyor Systems:
   • Uses 4 AI to monitor conveyor belt tension (via load cells) and bearing temperature (via PT100 transmitters); 8 DI to read limit switches (belt misalignment, emergency stop); 4 DO to trigger alarm lamps and brake actuators—all integrated into the ACS800 inverter controlling the conveyor motor.
2. Metallurgical Fan Control:
   • Connects 2 AI (duct pressure, airflow) to the ACS800 inverter for closed-loop fan speed control; 2 AO output fan speed and current to the plant SCADA; 4 DI to receive remote start/stop commands—ensuring stable airflow in blast furnaces.
3. Water Treatment Pumps:
   • Adds 2 AI (water level, discharge pressure) for PID-based pump speed regulation; 4 DO to control valve actuation and pump status indicators; 8 DI to monitor pump seal failure and tank level switches—optimizing energy use and preventing pump dry-run.
4. Plastic Extrusion Machines:
   • Uses 4 AI to measure extruder barrel temperature (via thermocouple transmitters) and melt pressure; 8 DI to read machine interlocks (door closure, material feed); 4 DO to activate heaters and feed motors—enabling the ACS800 inverter to synchronize motor speed with process conditions.

Precautions

1. Compatibility Check:
   • Confirm the ACS800 inverter’s frame size (R5-R11) and firmware version (v4.0+); incompatible with smaller frames (R1-R4) or older firmware (v3.x), which lack the ribbon cable interface for I/O expansion.
2. Wiring Guidelines:
   • Use shielded twisted-pair cables (0.5-1mm²) for analog I/O; ground the cable shield at the sensor end to reduce EMI.
   • For digital I/O, use 0.5-1.5mm² copper cables; torque terminal screws to 0.5-0.8N·m—loose connections cause intermittent signal loss.
3. Load Limitations:
   • Do not exceed 0.5A per DO channel (e.g., avoid connecting high-current devices like contactor coils directly); use an intermediate relay for loads >0.5A to prevent DO transistor burnout.
   • Ensure analog input signals stay within 0-10V DC/4-20mA DC (overvoltage >12V DC damages AI circuits).
4. Installation Safety:
   • Disconnect the inverter’s main power and auxiliary power before installing the board—high-voltage residual charge in the inverter can damage the I/O board’s low-voltage circuits.
   • Avoid touching the PCB traces during installation; use anti-static gloves to prevent ESD damage to sensitive components (e.g., analog-to-digital converters).
5. Configuration:
   • Use ABB DriveComposer software to assign I/O functions (e.g., set AI1 to "pressure feedback", DO1 to "pump running"); incorrect configuration (e.g., mapping AI to a digital function) renders the channel unusable.
6. Maintenance:
   • Periodically inspect the board’s terminals for corrosion (common in humid environments); clean with a dry brush—corrosion causes increased contact resistance and signal distortion.
7.
8.
9.
10. The structure and details of the product：
