ABB SD802F (Order Code: 3BDH000012R1) Power Module

1. Key Parameters

• Product Model: SD802F
• Order Code/Part Number: 3BDH000012R1 (unique identifier for procurement and PLC compatibility verification)
• Product Series: ABB AC 500-S/eCo Power Supply Modules
• Core Function: Converts input power (AC/DC) to regulated DC voltage for AC 500 PLC backplanes and I/O modules; ensures stable power delivery and protects against electrical faults
• Power Input Specifications:
  • Input Voltage Range: Universal 85V~264V AC (50/60Hz) or 110V~300V DC (compatible with global industrial power grids)
  • Input Current: 1.5A (max at 85V AC); 0.8A (max at 264V AC)
  • Input Power Factor (PF): ≥0.95 (at full load, 230V AC, 50Hz)
  • Efficiency: ≥90% (at full load; minimizes energy loss and heat generation)
• Power Output Specifications:
  • Output Voltage: 5V DC (regulated; ±2% tolerance for PLC backplane compatibility)
  • Output Current Capacity: 10A (continuous); 12A (peak, 10s duration; supports high-load startup of I/O modules)
  • Total Output Power: 50W (sustained)
  • Output Ripple & Noise: ≤50mVpp (ensures clean power for sensitive PLC circuitry)
  • Voltage Regulation: ±0.5% (line regulation); ±1% (load regulation)
• Protection Mechanisms:
  • Overload Protection: 120% of rated current (automatic shutdown; self-resets after fault removal)
  • Short-Circuit Protection: Instantaneous (≤10ms response; limits current to prevent damage to PLC/module)
  • Overvoltage Protection: 5.8V DC (clamps excess voltage to safeguard backplane components)
  • Overheating Protection: Activates at 85℃ (thermal shutdown; resumes operation when cooled to 70℃)
  • Input Surge Protection: IEC 61000-4-5 (±4kV contact; ±8kV air discharge)
• Mechanical Specifications:
  • Housing Type: Reinforced flame-retardant plastic (UL94 V-0; for EMI shielding and mechanical durability)
  • Dimensions (W×H×D): 86.1mm × 102mm × 58.5mm (1-module width; fits AC 500 standard DIN rail racks)
  • Mounting: DIN rail-mounted (35mm standard DIN rail per EN 60715) + backplane connector (for power distribution to PLC)
  • Weight: Approximately 280g
  • LED Indicators:
    • Power Input (IN): Green (input power present)
    • Power Output (OUT): Green (5V DC output normal); Red (output fault: overload/short-circuit/overheating)
    • Fault (ERR): Red (input surge/overvoltage; illuminates only for critical input faults)
• Environmental Ratings:
  • Operating Temperature Range: -25℃~+70℃ (-13℉~158℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: ≤95% RH (non-condensing, 40℃)
  • Vibration Resistance: 10~500Hz, 2g acceleration (IEC 60068-2-6; no electrical or mechanical failure)
  • Shock Resistance: 30g acceleration (11ms duration, IEC 60068-2-27; maintains output stability post-impact)
  • Ingress Protection: IP20 (suitable for installation in control cabinets)
• Compliance Standards: IEC 60950-1 (power supply safety), EN 61000-6-2 (EMC immunity), UL 508 (industrial control safety), CE, RoHS

2. Key Features

• Universal Input (AC/DC): Supports 85V~264V AC and 110V~300V DC input, eliminating the need for region-specific power supplies—ideal for global industrial projects (e.g., European 230V AC, North American 120V AC, DC-powered mining sites).
• High Efficiency & Low Heat: ≥90% efficiency reduces energy consumption and heat generation, extending the lifespan of the module and surrounding PLC components (no additional cooling required for standard rack setups).
• Robust Fault Protection: Integrates overload, short-circuit, overvoltage, and overheating protection to shield the AC 500 PLC and I/O modules from electrical damage—critical for harsh industrial environments with unstable power grids.
• Clean Power Output: ≤50mVpp ripple/noise ensures stable power for sensitive PLC circuitry (e.g., CPU, communication ports), preventing data corruption or communication drops caused by power fluctuations.
• Seamless AC 500 Integration: Plug-and-play compatibility with AC 500-S/eCo PLC racks; the backplane connector directly distributes 5V DC to the PLC and connected I/O modules—no external wiring for power distribution.
• Intuitive Status Monitoring: Color-coded LEDs (input, output, fault) provide real-time visual feedback, enabling quick troubleshooting (e.g., distinguishing between input surge and output short-circuit) without specialized tools.
• Industrial-Grade Durability: UL94 V-0 flame-retardant housing, wide temperature range (-25℃~+70℃), and vibration/shock resistance ensure reliable operation in demanding environments (e.g., steel mills, oil refineries, wastewater plants).

3. Application Fields

• AC 500 PLC Power Supply: Primary application—powers AC 500-S/eCo PLCs and connected I/O modules (digital/analog inputs/outputs, fieldbus modules) in:
  • Manufacturing Automation: Automotive assembly lines, electronics production, and packaging machines—ensuring continuous power for control logic and sensor/actuator communication.
  • Mining & Metals: Crusher control systems, conveyor monitoring, and smelter automation—withstanding dust, vibration, and temperature extremes.
  • Water & Wastewater Treatment: Pump control, chemical dosing, and filtration systems—reliable in humid, corrosive cabinet environments.
• Industrial Control Panels: Supplies power to compact control panels housing AC 500 PLCs, HMIs, and small I/O modules (e.g., building automation, machine tool control).
• Remote Automation Sites: Powers AC 500-eCo PLCs in remote locations (e.g., solar farm auxiliary control, pipeline monitoring) where power sources may switch between AC grid and DC backup.
• Food & Beverage Processing: Provides stable power to AC 500-based CIP (Clean-in-Place) systems and filling machine controls—compatible with the temperature and humidity ranges of food production facilities.
• Power Generation Auxiliaries: Supports AC 500 PLCs controlling boiler feedwater pumps, turbine lubrication systems, and solar inverter monitoring—ensuring reliable power for critical auxiliary equipment.

4. Precautions

• PLC Compatibility: Use exclusively with ABB AC 500-S and AC 500-eCo PLC systems. Installation in non-AC 500 racks (e.g., Siemens S7, Rockwell ControlLogix) will cause voltage mismatches and damage the PLC backplane.
• Input Voltage Matching: Ensure the input power (AC/DC) falls within the 85V~264V AC or 110V~300V DC range. Exceeding 264V AC/300V DC triggers overvoltage protection and shuts down the module; voltages below 85V AC/110V DC cause unstable output.
• Wiring Safety:
  • Use copper conductors of sufficient gauge: 1.5mm² for input wiring (AC/DC); 2.5mm² for ground wiring.
  • Tighten terminal screws to 1.2~1.5N·m to avoid loose connections (which cause overheating or voltage drops).
  • Separate input power wiring from low-voltage signal wiring (≥15cm spacing) to minimize EMI interference.
• Heat Dissipation: Install the module in a well-ventilated control cabinet. Avoid mounting it directly above heat-generating components (e.g., VFDs, power resistors) or in enclosed spaces without airflow—overheating triggers thermal shutdown.
• Overload Management: Do not exceed the 10A continuous output current. Calculate the total current draw of connected I/O modules (e.g., 0.3A for AM801F, 0.2A for FI810F) to avoid overloads—use a second SD802F module for high-load configurations.
• Replacement Guidelines: Replace the module only with the exact SD802F model (3BDH000012R1). Third-party power supplies may have incompatible output voltage/tolerance and lack critical protection mechanisms—voiding the PLC warranty and risking damage.
• Fault Handling:
  • If the OUT LED turns red, first check for short-circuited backplane wiring or overloaded I/O modules. Reset the module by cycling input power after resolving the fault.
  • If the ERR LED illuminates, inspect the input power for surges or overvoltage—install an external surge protector if faults recur
