ABB SC540 submodule carrier board

• • • • • • 1. Overview

            The ABB SC540 Submodule Carrier Board (3BSE006096R1) is an industrial-grade module for distributed control systems (DCS) and process control systems. It provides slots and bus connectivity for I/O modules, communication modules, and control submodules, enabling high-speed data exchange between modules. Integrated with a local CPU, it processes and manages submodule data, supporting modular expansion and ensuring high reliability and stable operation of the control system.

            ---

            2. Key Technical Specifications

            • Model: 3BSE006096R1 (SC540)

            • Type: Submodule Carrier / Backplane Board

            • System Compatibility: ABB Advant / MOD‑300 DCS

            • Internal Bus: Supports multiple submodule data communication

            • Power Supply: Dependent on system voltage

            • Module Slots: I/O, communication, and control modules

            • Dimensions (D × H × W): 291 × 300 × 30 mm

            • Weight: ~0.71 kg

            • Operating Temperature: –25 °C to +60 °C

            • Storage Temperature: –40 °C to +70 °C

            • Vibration Resistance: Industrial-grade

            • Mounting: Cabinet or panel installation

            ---

            3. Features & Advantages

            • Modular Design: Supports multiple submodules for flexible system expansion

            • Integrated Local CPU: Onboard data processing reduces central controller load

            • High Compatibility: Suitable for ABB Advant and MOD‑300 DCS systems

            • Compact & Lightweight: Space-efficient for cabinet layout

            • Industrial-grade Reliability: Resistant to heat and vibration for long-term operation

            • Easy Maintenance: Modular structure allows quick submodule replacement

            ---

            4. Typical Applications

            • Distributed Control Systems (DCS)

            • Industrial automation and process control

            • Power plants, chemical, petrochemical, and metallurgical industries

            • I/O expansion and management in control cabinets

            • Centralized field module management and data acquisition

            ---

            5. Notes & Precautions



            • Ensure proper grounding when installing in cabinets

            • Avoid installation in high humidity or corrosive environments

            • Power off before inserting or removing submodules

            • Regularly check module connections and communication signals

            • Keep spare submodules for quick replacement

            • Clean with dry compressed air or lint-free cloth to prevent dust ingress
