ABB 3BSE006096R1 Submodule Carrier

• • • • •

        • 1. Overview

          The ABB 3BSE006096R1 Submodule Carrier is an industrial-grade control system module designed for distributed control systems (DCS) and process control systems. It provides slots and bus connectivity for multiple submodules, such as I/O modules and communication modules. The carrier features an integrated local CPU to process and manage submodule data, supporting a modular and scalable control system architecture for stable industrial operation.

          ---

          2. Key Technical Specifications

          • Model: 3BSE006096R1

          • Type: Submodule Carrier

          • System Compatibility: ABB Advant / MOD‑300 DCS

          • Internal Bus: Supports data communication between multiple submodules

          • Power Supply: Depends on system voltage, typical control cabinet voltage

          • Dimensions (D × H × W): 291 × 300 × 30 mm

          • Weight: ~0.71 kg

          • Operating Temperature: –25 °C to +60 °C

          • Storage Temperature: –40 °C to +70 °C

          • Vibration Resistance: Industrial-grade

          • Module Slots: Supports I/O, communication, and control submodules

          • Mounting: Cabinet or panel installation

          ---

          3. Features & Advantages

          • Modular Design: Supports multiple submodules for flexible system expansion

          • Integrated Local CPU: Processes data onboard, reducing load on central controller

          • High Compatibility: Suitable for ABB Advant and MOD‑300 DCS systems

          • Compact & Lightweight: Space-efficient for cabinet layout

          • High Reliability: Industrial-grade, withstands high temperature and vibration

          • Easy Maintenance: Modular structure allows quick submodule replacement

          ---

          4. Typical Applications

          • Distributed Control Systems (DCS)

          • Industrial automation and process control

          • Power plants, chemical, petrochemical, and metallurgical industries

          • I/O expansion and management in control cabinets

          • Data acquisition and field module centralized management

          ---

          5. Notes & Precautions

          • Ensure proper grounding when installing in cabinets

          • Avoid installation in high humidity or corrosive environments

          • Power off before inserting or removing submodules

          • Regularly check module connections and communication signals

          • Keep spare submodules for quick replacement

          • Clean with dry compressed air or lint-free cloth to prevent dust ingress
