ABB RX835 (3BSE042247R1) Panel Touch Cover

1. Key Parameters

• Product Model: RX835
• Order Code: 3BSE042247R1
• Product Series: ABB RX Series Protective Covers (Touch Screen Guards, Industrial-Grade)
• Core Function: Provides physical and environmental protection for ABB PP835 touch screen panels; safeguards the display from impacts, scratches, chemical exposure, and particulate ingress; maintains uncompromised touch sensitivity and optical clarity; ensures compliance with industrial safety standards
• Material & Design Specifications:

  Parameter	Details	Performance Metrics
  Construction Materials	- Cover Panel: 3mm thick tempered soda-lime glass (chemically strengthened) - Frame: 316L stainless steel (corrosion-resistant) - Gasket: Food-grade silicone (temperature and chemical resistant) - Fasteners: 316 stainless steel (tamper-resistant)	Tempered glass resists impacts up to 10J (equivalent to 1kg object dropped from 1m); 316L steel withstands salt spray and chemical exposure
  Optical & Touch Properties	- Light Transmission: ≥92% (ensures display clarity) - Haze Factor: <1% (minimizes display distortion) - Touch Compatibility: Compatible with PCAP multi-touch (20 points) - Anti-Glare Coating: Matched to PP835 panel (reduces reflections)	Maintains original touch accuracy (±0.5mm) and gesture recognition; high light transmission preserves 4K display quality
  Protection Ratings	- Impact Resistance: IK10 (resists 20J impact, equivalent to 5kg object at 0.4m/s) - Ingress Protection: IP66 (when installed on PP835 panel) - Chemical Resistance: Resistant to oils, greases, dilute acids/bases (per ISO 2812-4)	Exceeds PP835's native protection; prevents water, dust, and chemical ingress in high-pressure washdown environments

• Mechanical Specifications:
  • Dimensions: 650mm (W) × 400mm (H) × 12mm (D) (custom-fit for PP835)
  • Weight: Approximately 1.8kg
  • Mounting Type: Direct bolt-on to PP835 panel (uses existing mounting points)
  • Clearance: 2mm gap between cover and screen (prevents touch interference)
  • Operating Temperature Range: -30℃~+80℃ (-22℉~176℉)
  • Storage Temperature Range: -40℃~+90℃ (-40℉~194℉)
• Compliance Standards: CE, RoHS, IEC 62262 (IK10 impact rating), IP66 (per IEC 60529), ISO 9227 (salt spray resistance), FDA 21 CFR 177.2600 (food-grade materials)

2. Key Features

• IK10 Impact Protection: Tempered glass panel withstands high-force impacts (up to 20J)—prevents damage from dropped tools, equipment collisions, or accidental impacts in busy industrial environments (e.g., manufacturing lines, maintenance areas).
• IP66 Ingress Protection: When installed properly, achieves dust-tight and high-pressure water resistance—protects the PP835 screen from water jets (100bar at 3m), dust, and particulate matter in washdown areas (e.g., food processing, pharmaceutical facilities).
• 316L Stainless Steel Frame: Superior corrosion resistance compared to 304 stainless steel—withstands saltwater, chemical vapors, and aggressive cleaning agents, making it ideal for offshore platforms, chemical plants, and marine environments.
• Uncompromised Touch Performance: Maintains full 20-point multi-touch functionality and ±0.5mm accuracy—does not interfere with gesture recognition (pinch, zoom, swipe) critical for PP835's collaborative operation.
• Optical Clarity: 92% light transmission and <1% haze—preserves the PP835's 4K UHD display quality, ensuring operators can read fine text, graphs, and process data without visual distortion.
• Food-Grade Silicone Gasket: FDA-compliant material resists degradation from cleaning agents—safe for use in food, beverage, and pharmaceutical applications where hygiene is critical.
• Tamper-Resistant Fasteners: Specialized screws prevent unauthorized removal—enhances security in public or restricted areas (e.g., utility control rooms, nuclear facilities).

3. Application Fields

• PP835 Panel Protection in Heavy Industry: Primary use in harsh environments:
  • Automotive Manufacturing Plants: Shields PP835 panels on production lines—protects from weld spatter, lubricant splashes, and impacts from robotic arms or tools, extending panel life by 3+ years.
  • Steel Mills: Installed on PP835 HMIs near rolling mills—resists high ambient temperatures and protects against flying metal particles, ensuring reliable operation in extreme conditions.
• Hygienic & Washdown Environments: Ensuring cleanliness and durability:
  • Food & Beverage Processing: Protects PP835 panels in bottling and packaging areas—IP66 rating withstands daily high-pressure caustic washdowns, while food-grade materials prevent contamination risks.
  • Pharmaceutical Cleanrooms: Shields HMIs in sterile production zones—easy to sanitize with alcohol-based cleaners without damaging the cover, maintaining GMP compliance.
• Outdoor & Corrosive Environments: Withstanding extreme conditions:
  • Offshore Oil Platforms: Protects PP835 panels in control rooms—316L stainless steel resists saltwater corrosion, while IP66 rating prevents water ingress during storm conditions.
  • Chemical Processing Plants: Shields HMIs near reactor control stations—resists exposure to corrosive vapors and accidental chemical spills, preserving touch functionality.
• Public & High-Traffic Areas: Preventing accidental damage:
  • Utility Control Centers: Protects PP835 panels in public-accessible areas—IK10 impact resistance prevents damage from unauthorized personnel or equipment movement.
  • Transportation Hubs: Shields HMIs controlling baggage handling or logistics systems—withstands heavy foot traffic and potential impacts from carts or equipment.

4. Precautions

• PP835 Exclusivity (Critical): Designed exclusively for ABB PP835 (3BSE042234R2) touch panels—will not fit other PP series models (e.g., PP836, PP846) or non-ABB panels; using on incompatible panels compromises protection and touch functionality.
• Installation & Maintenance Safety:
  • Proper Sealing: Torque fasteners to 2.5Nm in a crisscross pattern—insufficient torque compromises IP66 rating; overtightening may crack the glass or deform the frame.
  • Gasket Inspection: Check silicone gasket for damage before installation—cuts or tears reduce ingress protection; replace gasket (part no. 3BSE042248R1) if damaged.
  • Static Electricity: Handle glass panel by edges only—avoid touching the surface with bare hands; use anti-static gloves to prevent oil transfer that could reduce light transmission.
• Cleaning & Care:
  • Cleaning Protocol: Use a soft microfiber cloth with mild detergent or isopropyl alcohol—abrasive cleaners or tools (scrapers, steel wool) scratch the glass, reducing clarity; avoid high-pressure direct sprays on edges.
  • Chemical Exposure: While resistant to dilute chemicals, avoid prolonged contact with concentrated acids/bases—rinse immediately with clean water if exposed to harsh substances.
  • 定期检查: Perform monthly inspections for:
    • Loose fasteners (vibration-induced)
    • Glass cracks or scratches (replace cover if impact damage is visible)
    • Gasket degradation (hardening or cracking)
    • Reduced touch sensitivity (may indicate gasket compression issues)
• Environmental Limitations:
  • Temperature Extremes: Avoid continuous operation above +80℃—may cause silicone gasket to degrade; use forced-air cooling in high-temperature areas (e.g., near furnaces).
  • UV Exposure: Extended direct sunlight may cause gasket discoloration—use UV-blocking enclosures in outdoor applications to prevent premature aging.
• Replacement & Spare Parts:
  • Genuine ABB Components: Use only genuine RX835 (3BSE042247R1) covers—non-genuine alternatives may have inferior glass strength or incorrect dimensions, compromising protection and touch performance.
  • Spare Inventory: Maintain 1 spare cover per 5 PP835 installations—critical for minimizing downtime if damage occurs; store spares in protective packaging to prevent glass scratches
•
