ABB PP882 3BSE069275R1 Industrial HMI Panel

Product Overview

The ABB PP882 3BSE069275R1 Industrial HMI Panel is a high-performance human-machine interface designed for automation control systems. The panel provides intuitive touch operation and visual display capabilities, enabling real-time monitoring of production lines, factory equipment, and industrial process data. PP882 supports multiple communication protocols and integrates seamlessly with PLCs and DCS, ensuring efficient and reliable operation of industrial automation systems.

Technical Specifications

• Model: PP882 / 3BSE069275R1

• Type: Industrial HMI Panel

• Display Type: Color TFT LCD

• Screen Size: 8 inches

• Resolution: 800 × 600 pixels

• Touch Type: Resistive touchscreen

• Processor: High-performance embedded CPU

• Memory: 128 MB RAM / 256 MB Flash

• Operating System: Embedded real-time OS

• Communication Interfaces:

  • RS232 / RS485

  • Ethernet / Modbus TCP / Profibus DP

• Power Supply: 24 V DC

• Power Consumption: Approx. 12 W

• Operating Temperature: 0°C ~ 55°C

• Protection Class: IP65 (front panel)

• Mounting Method: Panel mount or cabinet embedded installation

Key Features & Advantages

• Intuitive touch operation: Color display and touchscreen improve operational efficiency

• High reliability: Industrial-grade design suitable for harsh environments

• Multi-protocol compatibility: Supports various industrial communication protocols for system integration

• Visual monitoring: Real-time display of production data, alarms, and trend graphs

• Modular design: Supports functional expansion modules for flexible system design

• Energy-efficient design: Low power consumption reduces energy usage

Application Areas

• Industrial automation production line monitoring

• PLC and DCS operation and data visualization

• Chemical, petrochemical, and pharmaceutical process monitoring

• Water treatment and environmental control systems

• Power and energy management systems

• Machinery automation and factory facility control

Precautions

• Ensure power supply is 24 V DC to prevent device damage

• Ensure proper ventilation during installation; avoid high temperature and humidity

• Avoid sharp objects touching the resistive touchscreen to prevent damage

• Avoid exposure to corrosive liquids or gases to protect the panel

• Regularly clean the front panel and screen to maintain touch sensitivity

• Disconnect power during installation and maintenance to prevent electric shock or damage

• Ensure communication interfaces are correctly connected to prevent data loss or communication errors
