ABB PM864K01 3BSE018150R1 Processor Unit Kit

Product Overview

The ABB PM864K01 3BSE018150R1 Processor Unit Kit is the core module of the ABB AC500 series PLC, designed for complex industrial automation applications. It features high-performance processing and flexible communication interfaces, enabling high-speed data processing, real-time control, and multitasking. The PM864K01 is suitable for distributed control systems and large-scale industrial automation projects, ensuring system reliability and stability.

Technical Specifications

• Model: PM864K01 / 3BSE018150R1

• Type: Processor Unit Kit

• PLC Series: ABB AC500

• Processor: High-performance CPU with multitasking support

• Program Memory: Up to 2 MB

• Data Memory: Up to 1 MB

• Communication Interfaces:

  • Built-in RS232/RS485

  • Supports CAN, Ethernet/IP, Modbus TCP via expansion modules

• Power Supply: 24 V DC

• Power Consumption: Approx. 7 W

• Operating Temperature: 0°C ~ 60°C

• Protection Class: IP20

• Mounting Method: DIN rail or modular control cabinet installation

• Compatible Modules: Expandable I/O, function, and communication modules

Key Features & Advantages

• High-performance processing: Supports complex logic operations and real-time multitasking

• Modular design: Easy to expand I/O and communication functions for distributed control systems

• Multiple communication interfaces: Supports industrial standard protocols for integration and remote control

• High reliability: Industrial-grade design for harsh environments and continuous operation

• Strong compatibility: Seamless integration with other AC500 series modules

• Easy maintenance: Quick module replacement reduces system downtime

Application Areas

• Industrial automation production lines

• Power and energy management systems

• Chemical, petrochemical, and pharmaceutical process control

• Machinery automation and monitoring systems

• Water treatment and environmental control systems

• Factory facilities and distributed control systems

Precautions

• Ensure power supply is 24 V DC before installation to avoid module damage

• Maintain proper ventilation; avoid high temperature, high humidity, or dust accumulation

• Do not disassemble the module while powered to prevent damage or injury

• Ensure communication interface wiring is correct to prevent signal interference or damage

• Regularly back up programs and data to prevent data loss

• Avoid exposure to corrosive gases or liquids to protect module performance

• Only use AC500-compatible modules and accessories for expansion
