ABB PP220 3BSC690099R2 process panel

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Overview

The ABB PP220 (part number 3BSC690099R2) is an industrial Process Panel / Operator Panel from ABB's PP220 series. It features a 240 × 128‐pixel LCD for graphical and textual display, providing a reliable HMI (Human-Machine Interface) for process control systems.

2. Technical Specifications

• Model: PP220

• Part Number: 3BSC690099R2 quad-industry.com+1

• Display: LCD, 240 × 128 pixels (graphics + text) quad-industry.com

• Weight: ~1 kg quad-industry.com

• Input Voltage: 100–240 V AC, 50/60 Hz Vogi International Trading Co., Ltd.

• Output Power (version dependent): Provides 24 V DC for internal or external circuits Vogi International Trading Co., Ltd.

• Operating Temperature (membrane keypad version): –10 °C to +60 °C www.vicpas.com

• Storage Temperature: –20 °C to +70 °C (membrane keypad) www.vicpas.com

• Relative Humidity: 5%–85% non-condensing (membrane version) www.vicpas.com

• Backlight Life (membrane): ~50,000 hours (CCFL / LED) www.vicpas.com

• Mounting: Panel mount / Operator Panel installation colletplc.com

3. Advantages & Features

1. Clear Graphical Display

   • High-resolution LCD supports clear visualization of data, alarms, and graphics.

2. High Reliability

   • Robust design suited for demanding industrial environments.

3. Wide Power Range

   • Accepts 100–240 V AC power, making it flexible for multiple power configurations.

4. Modular Design

   • Standalone panel unit simplifies maintenance and replacement.

5. Good Environmental Tolerance

   • Membrane keypad version supports a broad temperature and humidity range.

6. System Compatibility

   • Integrates well with ABB control architectures (e.g., 800xA) colletplc.com.

4. Application Areas

• Human-Machine Interface in industrial automation

• Process control in industries like chemical, pharmaceutical, food, etc.

• Power plant and utility operation panels

• Production line control and monitoring systems

• SCADA / DCS operator stations

• Upgrade and maintenance projects of legacy systems

5. Precautions & Recommendations

1. Power Wiring

   • Confirm correct AC supply during installation and ensure wiring meets safety standards.

2. Operating Environment

   • Install in a dry, ventilated, and stable-temperature control cabinet for optimal performance.

3. Careful Operation

   • For the membrane keypad version, avoid using sharp tools and keep the panel clean.

4. Heat Management

   • Make sure there’s sufficient airflow in the panel enclosure to prevent overheating.

5. Spare Module Strategy

   • Keep a spare PP220 panel because of its critical role and possible obsolescence.

6. Compatibility Verification

   • Validate compatibility with your control system (PLC / DCS) and HMI configuration tool (e.g., Panel Builder).
