ABB ACSM1-04AM-09A5-4 servo drive

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Overview

The ABB ACSM1‑04AM‑09A5‑4 is a high-performance servo/vector drive from the ACSM1 series, designed for precise motor speed, torque, and position control in industrial automation. It supports both closed-loop and open-loop control and can interface with higher-level controllers via digital communication protocols. Typical applications include robotics, machine tools, conveyors, and precision motion systems.

2. Technical Specifications

• Model: ACSM1‑04AM‑09A5‑4

• Series: ACSM1‑04

• Input Voltage: 380–480 V AC three-phase

• Rated Output Current: 9.5 A

• Control Method: Vector control, speed and torque regulation

• Communication Interfaces: Optional industrial communication protocols (CANopen, Modbus, etc.)

• Protection Rating: IP20 (cabinet-mounted)

• Operating Temperature: As per ACSM1 series standard environment

• Dimensions & Weight: Modular design, approx. 2–3 kg

• Certification & Standards: Compliant with ABB industrial drive standards

3. Advantages & Features

1. High-precision control

   • Vector control algorithm ensures accurate speed and torque management for dynamic applications.

2. High reliability

   • Built-in protection against overcurrent, overvoltage, and short circuits ensures safe operation.

3. Modular design

   • Simplifies maintenance, replacement, and upgrades.

4. Flexible communication

   • Supports multiple industrial protocols for easy integration into automation systems.

5. Energy efficient

   • High-efficiency design reduces energy consumption and improves production economics.

6. Wide applications

   • Suitable for robotics, machine tools, conveyors, and other precision motion control systems.

4. Application Areas

• Industrial automation (robots, assembly lines)

• CNC machines and machining centers

• Conveyors and material handling systems

• Winding, textile, or high-torque machinery

• Pumps, fans, and other motor-driven applications

• High-precision automated production lines

5. Precautions & Recommendations

1. Input Filter

   • Use recommended ABB filters to ensure EMC compliance and stable operation.

2. Cooling

   • Install in a well-ventilated cabinet to prevent overheating.

3. Cabling

   • Use proper cable sizing and shielding for power and motor connections to reduce interference.

4. Communication Configuration

   • Ensure communication protocols match those of the upper-level controller.

5. Installation & Commissioning

   • Follow ABB ACSM1 series manuals strictly for installation and setup.

6. Maintenance & Spare Parts

   • Keep spare drives and monitor temperature and alarms regularly to maintain production continuity.
