ABB PM595-4ETH-F Processor Module (Order Code: 1SAP155500R0279)

1. Product Overview

The ABB PM595-4ETH-F is a high-performance CPU module within the ABB AC500 PLC family. It provides superior processing power, multiple Ethernet interfaces, and flexible communication options for demanding automation and process control applications. Designed for scalability, reliability, and integration, the PM595-4ETH-F serves as a flagship controller for advanced industrial systems.

2. Technical Specifications

• Series: AC500 PLC Family

• Model: PM595-4ETH-F

• Order Code: 1SAP155500R0279

• Processor:

  • 64-bit multi-core processor

  • Execution time: 0.02 µs per Boolean instruction

  • Program memory: 4 MB

  • Data memory: 8 MB

  • Expandable memory: SD card up to 32 GB

• Communication Interfaces:

  • 4 × Ethernet ports (10/100 Mbps auto-negotiation)

  • 2 × Serial ports (RS-232/RS-485 selectable)

  • 1 × USB port for programming/debugging

  • Supports CANopen, Modbus TCP, EtherNet/IP, PROFINET, and OPC

• Expansion:

  • Supports up to 10 I/O modules and multiple communication modules

  • Compatible with S500 remote I/O

• Power Supply: 24 V DC (±20%)

• Power Consumption: Approx. 7 W

• Operating Environment:

  • Operating temperature: –25 °C to +70 °C

  • Storage temperature: –40 °C to +85 °C

  • Relative humidity: 5–95% non-condensing

• Protection Class: IP20

• Mounting: DIN-rail

• Dimensions / Weight: 142 × 110 × 75 mm / 0.45 kg

• Software: Automation Builder, Control Builder Plus

• Certifications: CE, UL, RoHS, ATEX (selected versions)

3. Advantages & Key Features

1. High-speed multi-core processor – Ideal for complex automation, motion, and logic control.

2. Four Ethernet ports – Enable network segmentation, redundancy, and efficient data routing.

3. Modular system design – Flexible expansion with AC500/S500 I/O and communication modules.

4. Industrial reliability – Designed to withstand vibration, temperature extremes, and EMI.

5. Multi-protocol support – Seamless integration with Modbus, PROFINET, and other networks.

6. Remote diagnostics – Enables online monitoring, data acquisition, and maintenance via Ethernet.

7. Advanced data security – Built-in memory backup, power-fail protection, and encrypted communication.

8. Unified software environment – Fully supported by ABB Automation Builder for simplified engineering.

4. Typical Application Areas

• Industrial automation and process control

• Power generation and energy management systems

• Oil, gas, and petrochemical control networks

• Water and wastewater treatment automation

• Smart manufacturing and robotic control

• Transportation and infrastructure automation (railway, port, airport systems)

• Building automation and facility management systems

5. Precautions

• Verify correct voltage polarity and ensure reliable grounding before powering up.

• Check all module and communication connections before operation.

• Avoid exposure to moisture, corrosive gases, or strong electromagnetic fields.

• Plan IP addressing and network topology carefully for multi-Ethernet configurations.

• Do not insert or remove modules during power-on operation.

• Regularly back up project data and configuration files.

• Use the latest compatible firmware and Automation Builder version for stability.

• For hazardous or explosive zones, use certified Ex-rated versions.
