ABB PCO012 PROFIBUS DP Connector

1. Key Parameters

• Product Model: PCO012
• Product Series: ABB PCO Series Industrial PROFIBUS DP Connectors (Universal Compatibility, Field & Cabinet Installation)
• Core Function: Enables secure PROFIBUS DP connections between ABB and third-party automation devices; provides selectable bus termination; blocks electromagnetic interference; supports daisy-chain and star network topologies
• Electrical & Protocol Specifications:

  Parameter	Details	Performance Metrics
  PROFIBUS DP Performance	- Supported Protocol: PROFIBUS DP V1/V2 (compliant with EN 50170-2) - Maximum Data Rate: 12Mbps (up to 100m, copper); 1.5Mbps (up to 400m); 9.6kbps (up to 1200m) - Bus Termination: Integrated 150Ω ±15% metal film resistor (selectable via slide switch) - Signal Reflection: ≤-20dB (at 12Mbps, measured at termination point)	Ensures error-free data transmission (≤1 error per 10⁹ bits) for real-time control signals (e.g., I/O commands, fault logs) in high-speed networks
  Electrical Protection	- ESD Protection: ±4kV (air discharge); ±2kV (contact discharge) per IEC 61000-4-2 - Surge Protection: 1kV (line-to-line, per IEC 61000-4-5) - Common-Mode Noise Rejection: ≥65dB (at 1MHz) - Insulation Resistance: ≥200MΩ (at 500V DC, 20℃)	Protects connected devices (e.g., S800 I/O, ACS drives) from electrical transients caused by motor start-ups, welding equipment, or static discharge
  Connector Configuration	- Pinout: 9-pin D-sub (male/female variants) with standard PROFIBUS assignment (Pin 3: B-line, Pin 5: A-line, Pin 8: Shield) - Contact Material: Phosphor bronze (gold-plated, 5μm thickness) - Wire Compatibility: 0.14mm²~0.5mm² (26~20 AWG) stranded or solid copper wire - Connection Type: Screw terminals (0.2~0.6Nm torque range)	Gold-plated contacts ensure low contact resistance (≤8mΩ) and corrosion resistance; screw terminals prevent loosening under vibration
  Safety & Compliance	- EMI/RFI Shielding: 360° tin-plated copper braid (95% coverage) with integrated grounding lug - Flame Class: UL 94 V0 (housing); IEC 60332-1-2 (cable compatibility) - Voltage Rating: 300V AC/DC (max) - Current Rating: 1A (per contact)	95% shielding coverage minimizes EMI ingress/egress; flame-retardant housing reduces fire risk in enclosed control cabinets

• Mechanical Specifications:
  • Dimensions: 48mm (W) × 32mm (H) × 65mm (L) (compact design for dense installations)
  • Mounting Options: DIN rail mount (EN 50022, 35mm rail) or panel mount (via pre-drilled tabs)
  • Housing Material: Glass-fiber reinforced polyamide (PA66+GF, impact-resistant, chemical-resistant)
  • Ingress Protection (IP): IP20 (base unit); IP44 (with optional dust/waterproof cover)
  • Weight: Approximately 55g (without cables)
• Environmental Ratings:
  • Operating Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Storage Temperature Range: -50℃~+90℃ (-58℉~194℉)
  • Humidity Tolerance: 5%~99% RH (non-condensing, 40℃)
  • Vibration Resistance: 10~500Hz, 15g acceleration (IEC 60068-2-6; no contact displacement)
  • Shock Resistance: 30g (11ms half-sine pulse, IEC 60068-2-27; no mechanical failure)
  • Chemical Resistance: Resistant to mineral oil, hydraulic fluids, dilute acids/bases, and industrial detergents (per IEC 60068-2-54)

2. Key Features

• Universal PROFIBUS Compatibility: Supports PROFIBUS DP V1/V2 and complies with EN 50170-2—seamlessly integrates with ABB devices (S800 I/O, AC500 PLCs, ACS drives) and third-party equipment (e.g., Siemens S7 PLCs, Rockwell drives), eliminating the need for adapter connectors.
• Selectable Integrated Termination: Built-in 150Ω metal film resistor (toggled via slide switch) eliminates external terminators—simplifies network setup (critical for daisy-chained topologies) and ensures proper signal termination at bus endpoints, reducing reflection-induced errors.
• High-Performance EMI Shielding: 360° tin-plated copper braid (95% coverage) with grounding lug blocks industrial EMI/RFI (e.g., from motor drives, high-voltage cables)—prevents data corruption in noisy environments (e.g., steel mills, welding shops) where standard connectors fail.
• Vibration-Resistant Connections: Screw terminals with 0.2~0.6Nm torque specification and phosphor bronze contacts withstand 15g vibration—ideal for high-motion applications (e.g., conveyor belts, pumps, robotic arms) where loose connections cause intermittent communication.
• Wide Environmental Tolerance: -40℃~+85℃ operating temperature range, IP44 protection (with cover), and chemical resistance—operates reliably in extreme conditions: cold storage facilities, outdoor enclosures, food processing washdown zones, and chemical plants.
• User-Friendly Installation: Clear pin labeling, tool-less DIN rail mounting, and color-coded termination switch—reduces installation time by 30% vs. complex connectors; accessible terminals enable easy wire replacement without disassembling the entire network.
• Long Service Life: PA66+GF housing (impact-resistant) and 5μm gold-plated contacts (corrosion-resistant)—ensures 10+ years of reliable operation in industrial environments, lowering maintenance costs and reducing network downtime.

3. Application Fields

• ABB PROFIBUS DP Network Backbones: Primary application—connecting ABB devices in distributed control systems:
  • Automotive Assembly Lines: Links S800 I/O modules (robot position encoders, weld gun sensors) to AC500 PLCs via 12Mbps PROFIBUS DP; vibration resistance withstands assembly line motion, while EMI shielding blocks interference from welding equipment, ensuring precise robot coordination (±0.05mm).
  • Oil Refinery Process Units: Connects ACS800 drives (pump/mixer motors) to AC500 PLCs; chemical resistance withstands hydrocarbon vapors, and IP44 cover protects against dust ingress, enabling reliable transmission of speed setpoints and fault data in explosive-risk zones (Zone 2).
• Third-Party Device Integration: Bridging ABB and non-ABB PROFIBUS equipment:
  • Pharmaceutical Batch Processing: Integrates Siemens S7 PLCs (batch controllers) with ABB S800 I/O modules (temperature/pressure sensors); selectable termination simplifies network expansion, while low contact resistance ensures accurate transmission of critical batch parameters (±0.1℃).
  • Water Treatment Plants: Connects Rockwell Allen-Bradley drives (aeration blowers) to ABB AC500 PLCs; wide temperature range (-40℃~+85℃) handles outdoor pump stations, and corrosion resistance prevents damage from chlorine-based cleaning fluids.
• Heavy Industry & Manufacturing: Rugged connectivity for harsh environments:
  • Steel Mill Hot Rolling Lines: Links S800 I/O modules (roll temperature sensors, tension monitors) to AC500 PLCs; EMI shielding blocks interference from large motors, and high-temperature tolerance (+85℃) withstands heat from rolling mills, ensuring consistent steel thickness (±0.1mm).
  • Mining Underground Operations: Connects S800 I/O modules (conveyor belt speed sensors, gas detectors) to surface AC500 PLCs; IP44 protection and vibration resistance (15g) withstand dust and crusher motion, enabling real-time monitoring of underground assets.
• Food & Beverage Processing: Hygienic and reliable connections:
  • Dairy Pasteurization Lines: Links S800 I/O modules (milk temperature sensors, valve actuators) to AC500 PLCs; IP44 cover resists washdowns (caustic cleaners), and corrosion-resistant contacts prevent contamination from dairy byproducts, ensuring compliance with FDA/USDA standards.
  • Beverage Bottling Plants: Connects ACS355 drives (conveyor motors) to AC500 PLCs; compact design fits in machinery control boxes, and fast 12Mbps data rate enables synchronized capping/filling operations, reducing bottle rejection rates by 15%.
• Building & Infrastructure Automation: PROFIBUS connectivity for facility systems:
  • HVAC for Commercial Buildings: Links S800 I/O modules (airflow sensors, damper actuators) to AC500 PLCs; DIN rail mounting simplifies panel installation, and low power consumption ensures compatibility with building automation power systems, maintaining consistent indoor air quality.
  • Solar Farm Inverter Control: Connects third-party solar inverters to ABB AC500 PLCs; wide temperature range (-40℃~+85℃) handles desert heat/cold, and EMI shielding blocks interference from power inverters, enabling efficient energy monitoring and grid synchronization.

4. Precautions

• Termination Configuration (Critical): Activate the 150Ω resistor only at the first and last connectors in a PROFIBUS segment—terminating all connectors causes signal reflection, leading to "frame check errors" or complete network failure. Use the slide switch (labeled "Term On/Off") to toggle termination; verify with a PROFIBUS tester after setup.
• Installation & Wiring Safety:
  • Shield Grounding: Connect the integrated grounding lug to the facility’s industrial ground (resistance ≤1Ω)—ungrounded shields act as antennas, increasing EMI susceptibility and causing data dropouts. Use 2.5mm² copper ground wire for reliable grounding.
  • Polarity & Pinout: Strictly follow PROFIBUS pinout (Pin 3: B-line, Pin 5: A-line)—reversed polarity prevents communication, while incorrect wiring (e.g., connecting shield to signal pins) damages device ports. Use a multimeter to verify continuity before powering on the network.
  • Torque Control: Tighten wire terminals to 0.2~0.6Nm with a torque screwdriver—under-tightening causes high resistance (signal loss), while over-tightening strips threads or severs conductors. Avoid using pliers or excessive force.
• Operation & Maintenance:
  • Regular Inspection: Check connectors quarterly for:
    • Loose terminals (common after vibration events)
    • Corroded contacts (visible green/white deposits, typical in humid environments)
    • Damaged shielding (torn braid, loose grounding lug)
      Replace connectors immediately if any issues are found to prevent network downtime.
  • Signal Quality Testing: Use a PROFIBUS tester (e.g., ABB PROFIBUS Analyzer) monthly to monitor:
    • Signal attenuation (should be ≤6dB/km at 1.5Mbps)
    • Bit error rate (BER ≤10⁻⁹)
    • Noise level (common-mode noise ≤1Vpp)
      Address anomalies (e.g., high noise) by repositioning cables or adding EMI filters.
  • Environmental Protection: Install the optional IP44 cover in:
    • Wet environments (washdown zones, outdoor enclosures)
    • Dusty areas (mining, cement plants)
    • Corrosive zones (chemical plants, offshore platforms)
      The cover prevents moisture/dust ingress, which degrades insulation and causes contact corrosion.
• Environmental Limitations:
  • Temperature Extremes: Do not operate above +85℃ or below -40℃—high temperatures soften PA66 housing, while extreme cold makes it brittle; use heat tracing (for cold) or heat shields (for heat) in extreme zones.
  • Chemical Exposure: Avoid prolonged contact with concentrated solvents (e.g., acetone, methylene chloride) and strong acids (pH <2)—these dissolve the PA66+GF housing and damage gold plating; use chemical-resistant conduit in high-risk areas.
• Replacement & Spare Parts:
  • Genuine ABB Connectors: Use only genuine ABB PCO012 connectors—non-genuine alternatives have substandard shielding (＜80% coverage) and thin gold plating (＜2μm), leading to frequent failures and voiding ABB device warranties.
  • Spare Inventory: Maintain 10~15 spare connectors per 100-node network—PROFIBUS connectors are a common failure point; spares reduce downtime from days (delivery lead time) to 10 minutes during critical repairs (e.g., production line outages)

The structure and details of the product：
