ABB PBA800 Process Bus Adapter

1. Product Overview

The ABB PBA800 Process Bus Adapter is a communication interface designed for digital substations and IEC 61850-based systems. It bridges traditional analog/digital signals with a modern IEC 61850-9-2 process bus, enabling high-speed, reliable digital communication between protection relays, measurement devices, and switchgear.
By converting copper-based signals into standardized digital data, the PBA800 enhances system efficiency, reduces wiring, and supports the transition toward fully digital substations.

2. Detailed Specifications

• Model: PBA800

• Type: Process Bus Adapter

• Supported Standards: IEC 61850, IEC 61850-9-2, GOOSE messaging

• Power Supply: 24–48 V DC

• Data Interface: Fiber-optic Ethernet (100 Mbps / 1 Gbps)

• Input Types: Analog signals (current/voltage), digital I/O

• Output Format: IEC 61850-9-2 sampled values / digital streams

• Time Sync: IEEE 1588 PTP support

• Protection Rating: IP20

• Operating Temperature: –25°C to +55°C

• Mounting: Modular installation in control cabinets

• Application Systems: Digital substations and smart grid networks

3. Advantages & Features

• Fully compliant with IEC 61850, supporting modern digital substation architecture.

• Enables integration of conventional and digital devices, ideal for retrofits.

• Reduced installation cost due to fiber-optic communication replacing copper wiring.

• High-speed, low-latency performance suitable for protection-level communication.

• PTP (IEEE 1588) time synchronization ensures data accuracy.

• Improved system reliability with reduced wiring errors.

• Modular, service-friendly design for easy installation and expansion.

4. Application Areas

• Digital substations

• IEC 61850 process bus networks

• High-voltage and medium-voltage protection systems

• SCADA and power monitoring systems

• Smart grid automation

• Power plant protection and control

• Substation modernization and retrofit projects

5. Precautions

• Always disconnect power before installation.

• Ensure fiber-optic cables are clean and properly connected.

• Configuration should be performed by engineers familiar with IEC 61850.

• Verify proper time synchronization (PTP) during operation.

• Avoid use in highly corrosive or high-humidity environments.

•
