ABB OTP25T3M Safety Switch

ABB OTP25T3M Safety Switch Product Information

Technical Specifications:

• Model: OTP25T3M

• Type: Safety Switch

• Rated Current: 25A

• Rated Voltage: 690V AC

• Frequency Range: 50/60Hz

• Protection Class: IP65

• Switch Type: Manual operation with locking feature

• Operation Mode: Rotary operation

• Electrical Durability: 10,000 operations

• Installation Type: Panel mounting

• Contact Material: Silver alloy

• Dimensions: Width: 120mm; Height: 200mm; Depth: 140mm

• Weight: Approximately 1.5kg

• Certifications: IEC 60947-3, CE

Advantages and Features:

• High Safety: The OTP25T3M safety switch is designed to meet high safety standards, with a robust housing and manual locking feature, ensuring safe and reliable operation in hazardous environments.

• High Reliability: Equipped with silver alloy contacts, the switch offers better conductivity and durability, ensuring stable performance over time.

• Strong Protection: With an IP65 protection rating, it effectively prevents dust and water ingress, making it suitable for harsh industrial environments.

• Easy Operation: The rotary operation is simple, allowing quick and safe switching of power, reducing the risk of operator error.

• Long Mechanical Life: With a durability of 10,000 operations, the switch reduces maintenance and replacement frequency, thus lowering costs.

• Locking Feature: The manual locking feature prevents accidental operation, ensuring operator safety.

Applications:

• Industrial Control Systems: Widely used in industrial automation control systems as the main power switch, ensuring electrical isolation and protection of equipment during operation.

• Power Systems: Used for power isolation and protection in power systems, ensuring the safe operation of electrical equipment.

• Building Facilities: Applied in electrical distribution systems within buildings, protecting equipment from power failures.

• Machinery Equipment: Provides power isolation and control for large machinery, ensuring the safe and reliable operation of equipment.

Precautions:

• Ensure that the power supply voltage and rated current of the switch match the system's requirements during installation to avoid overload or equipment damage.

• Regularly check the switch’s operation during use to ensure smooth rotary operation, and prevent jamming or faults.

• Maintain sufficient space around the switch during installation for proper heat dissipation to prevent overheating that may affect performance.

• Avoid exposing the device to damp or excessively high temperatures; ensure it operates in an environment suitable for its specifications.

• Periodically inspect the locking feature to ensure it works correctly and to prevent accidental operation.

The structure and details of the product：
