ABB 2TLA020051R0700 Non-contact safety sensor

ABB 2TLA020051R0700 Non-contact Safety Sensor Product Information

Technical Specifications:

• Model: 2TLA020051R0700

• Type: Non-contact Safety Sensor

• Operating Voltage: 24V DC

• Output Type: Digital output (Switching signal)

• Output Signal: PNP normally open or normally closed (optional)

• Installation Type: DIN rail mounting

• Operating Temperature Range: -25°C to +55°C

• Storage Temperature Range: -40°C to +70°C

• Protection Class: IP67

• Response Time: ≤10ms

• Detection Distance: 10mm – 20mm (depending on installation position)

• Material: Plastic housing, impact-resistant, vibration-resistant

• Dimensions: Width: 30mm; Height: 60mm; Depth: 20mm

• Weight: Approximately 0.05kg

• Certifications: IEC 60947-5-3, ISO 13849-1, CE

Advantages and Features:

• Non-contact Operation: The sensor uses non-contact sensing technology, providing reliable safety protection, avoiding mechanical wear and contact issues, thus extending the equipment's lifespan.

• Fast Response: With a response time of ≤10ms, it ensures rapid response and protects personnel and equipment safety.

• Versatile Output: Offers PNP normally open and normally closed output options, allowing flexibility to adapt to different control systems and application needs.

• Durable: With an IP67 protection rating, it is ideal for use in harsh environments such as wet, dusty, or polluted industrial conditions.

• Easy Installation: It can be easily installed on DIN rails, simplifying the installation process, saving time and labor costs.

• Wide Compatibility: Compatible with a variety of automation devices and control systems, it is widely used in industrial safety, equipment protection, and other applications.

Applications:

• Industrial Automation: Used in automated production lines, machinery, robots, and other equipment for safety protection, ensuring that personnel are not injured when operating in hazardous areas.

• Material Handling: In conveyor belts, cranes, and warehouse equipment, it acts as a safety sensor to monitor equipment operation and prevent personnel from entering danger zones.

• Production Facilities: Used in production environments to detect personnel or objects entering hazardous areas, triggering appropriate safety measures such as stopping machines or sounding alarms.

• Power Systems: Used in power equipment to monitor whether workers are safely entering equipment zones, preventing accidental startup and injury from electrical equipment.

Precautions:

• Ensure that the sensor’s detection distance and installation position are appropriate for reliable safety sensing during installation.

• Regularly inspect the sensor housing and connections for any damage to prevent external substances (such as dust or moisture) from affecting its performance.

• Ensure that the operating temperature is within the sensor’s working range to avoid damage or performance degradation due to excessive heat or cold.

• Choose the appropriate output mode based on the application environment to ensure compatibility with the control system.

• Avoid exposing the sensor to strong electromagnetic fields, excessive vibrations, or shocks, as these can affect its sensing performance.

•
