ABB NAMM03 Analog Master Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

 ABB NAMM03 Analog Master Module

Core Product Features

• Centralized Analog Control: Supports 8 independent analog control loops, each capable of PID (Proportional-Integral-Derivative) regulation. It can automatically adjust analog outputs (e.g., valve opening, motor speed) based on input signals (from sensors) to maintain process parameters at set values.
• Multi-Signal Compatibility: Integrates 16 analog input channels (supports 4-20mA/0-10V signals) and 8 analog output channels (4-20mA/0-10V), compatible with common industrial sensors (pressure transmitters, thermocouples via signal converters) and actuators (control valves, variable frequency drives).
• Synchronization & Diagnostics: Enables multi-loop synchronization (sampling rate ≤1ms difference between channels) for coordinated control (e.g., parallel reactor temperature regulation). Built-in loop fault diagnosis (sensor open/short, output overrange) with status feedback to the upper-level system via bus.

Key Parameters

• Input Channels: 16 analog inputs (4-20mA/0-10V, accuracy ±0.05% of full scale; channel-to-channel isolation 2.5kV AC).
• Output Channels: 8 analog outputs (4-20mA/0-10V, linearity error ≤0.1%; max load 500Ω for current output).
• Control Performance: PID loop update rate 100ms/loop (configurable up to 10ms); support for auto-tuning, cascade control, and feedforward control.
• Power & Environment: 24V DC input (18-30V DC), power consumption ≤10W; operating temperature -40°C to +70°C, humidity 5%-95% (non-condensing).
• Mechanical Specs: 110mm×85mm×25mm, DIN rail-mounted, compatible with ABB Symphony Plus I/O racks; communication via ABB module bus (supports hot-swap in redundant systems).

Core Advantages

• High-Precision Regulation: Advanced PID algorithm with anti-windup and derivative kick suppression ensures stable control of critical processes (e.g., pharmaceutical reactor temperature, ±0.1°C deviation from set value).
• System Integration Efficiency: Native compatibility with ABB DCS/SCADA systems; configurable via ABB Control Builder software, supporting online parameter adjustment without system shutdown.
• Redundancy Support: Optional dual-module redundancy (1+1) for mission-critical applications (e.g., nuclear power, oil refining); automatic failover (≤100ms) to avoid control loop interruption.

Typical Applications

• Process Industry Control: In chemical plants, regulates 8 parallel reactor pressure loops (via 4-20mA pressure sensors and control valves), ensuring uniform reaction conditions across all units.
• Power Plant Auxiliaries: Controls boiler feedwater flow (analog input from flowmeters, output to control valves) and deaerator level, maintaining stable boiler operation.
• Water Treatment: Manages 8 chemical dosing loops (e.g., pH adjustment, chlorine addition) in wastewater treatment plants, automatically adjusting dosing amounts based on real-time water quality sensor signals.

Usage Precautions

• Wiring: Use shielded twisted-pair cables for analog signals; ground shields at the module end (single-point grounding) to reduce EMI. For current inputs, ensure correct polarity to avoid measurement errors.
• PID Tuning: Perform auto-tuning after initial installation; for complex processes (e.g., delayed temperature loops), manually adjust proportional gain, integral time, and derivative time to optimize stability.
• Maintenance: Regularly calibrate input/output channels (annual calibration recommended); monitor loop status via LED indicators (normal/fault) and upper-level system alarms. Avoid hot-swapping in non-redundant systems to prevent process disturbance.
