ABB IMDSM-04 Analog Input Module
Product Description
A dedicated analog input module for ABB industrial systems (AC 800M, Symphony Plus), specializing in collecting analog signals (e.g., 4-20mA, 0-10V) from field transmitters (temp, pressure, flow). It converts weak analog signals into standardized digital data for controllers, ensuring accurate process monitoring in industrial automation.
Key Specifications
- Input Channels: 16 analog input channels (isolated between channels).
- Signal Types: 4-20mA (input impedance 250Ω), 0-10V (1MΩ); configurable per channel.
- Accuracy: ±0.1% full scale (FS) for 4-20mA; ±0.2% FS for 0-10V.
- Communication: PROFIbus DP port (12Mbps max) for data sync with controllers.
- Power: 24V DC (18-30V DC); ≤5W full load.
- Environment: -40°C to +70°C; 5%-95% humidity (non-condensing); IP20.
- Mechanical: 35mm DIN rail; 100×80×25mm; fits ABB I/O racks.
- Protection: 2.5kV AC isolation (channels-backplane); ±8kV ESD (IEC 61000-4-2); low-pass filtering (50Hz cutoff).
- Catalog Nos.: GJR5252000R0101, GJR5252000R0102 (regional variations).
Advantages & Features
- 16-channel high density: Meets multi-point analog monitoring needs, saving cabinet space.
- High accuracy: ±0.1% FS ensures reliable collection of precision process signals (e.g., reactor temp).
- Strong anti-interference: Isolation+filtering reduces EMI from motors/inverters, stable in harsh environments.
- Flexible signal support: 4-20mA/0-10V configurable per channel, compatible with most industrial transmitters.
- Easy integration: Native PROFIbus DP support; online config via ABB Control Builder M.
Application Fields
- Process Industry: Collect pressure/temp/flow signals from chemical reactor transmitters for DCS monitoring.
- Power Plants: Capture steam pressure/feedwater flow signals in boiler auxiliary systems.
- Water Treatment: Gather turbidity/PH/flow signals from water quality sensors for process regulation.
- Manufacturing: Monitor temperature signals of industrial ovens in automotive coating lines.
Precautions
- Use shielded twisted-pair cables for analog wiring; ground shield at module end (single-point).
- Confirm signal type (4-20mA/0-10V) per channel before wiring; avoid overvoltage (>60V) to prevent damage.
- Use regulated 24V DC power (overload protection); check polarity before power-on.
- Avoid direct sunlight/corrosive gas; keep away from heat sources (power modules) to prevent overheating.
- Calibrate analog channels annually with ABB tools; clean dust every 3-6 months.
English Translation
ABB IMDSM-04 Analog Input Module
Product Description
A dedicated analog input module for ABB industrial systems (AC 800M, Symphony Plus), specialized in collecting analog signals (e.g., 4-20mA, 0-10V) from field transmitters (temperature, pressure, flow). It converts weak analog signals into standardized digital data for controllers, ensuring accurate process monitoring in industrial automation.
Key Specifications
- Input Channels: 16 analog input channels (isolated between channels).
- Signal Types: 4-20mA (input impedance 250Ω), 0-10V (1MΩ); configurable per channel.
- Accuracy: ±0.1% full scale (FS) for 4-20mA; ±0.2% FS for 0-10V.
- Communication: PROFIbus DP port (12Mbps max) for data synchronization with controllers.
- Power: 24V DC (18-30V DC); ≤5W full load.
- Environment: -40°C to +70°C; 5%-95% humidity (non-condensing); IP20.
- Mechanical: 35mm DIN rail; 100×80×25mm; compatible with ABB I/O racks.
- Protection: 2.5kV AC isolation (channels-backplane); ±8kV ESD (IEC 61000-4-2); low-pass filtering (50Hz cutoff).
- Catalog Nos.: GJR5252000R0101, GJR5252000R0102 (regional variations).
Advantages & Features
- 16-channel high density: Meets multi-point analog monitoring requirements, saving cabinet space.
- High accuracy: ±0.1% FS ensures reliable collection of precision process signals (e.g., reactor temperature).
- Strong anti-interference: Isolation+filtering reduces EMI from motors/inverters, ensuring stability in harsh environments.
- Flexible signal support: 4-20mA/0-10V configurable per channel, compatible with most industrial transmitters.
- Easy integration: Native PROFIbus DP support; online configuration via ABB Control Builder M.
Application Fields
- Process Industry: Collect pressure/temperature/flow signals from chemical reactor transmitters for DCS monitoring.
- Power Plants: Capture steam pressure/feedwater flow signals in boiler auxiliary systems.
- Water Treatment: Gather turbidity/PH/flow signals from water quality sensors for process regulation.
- Manufacturing: Monitor temperature signals of industrial ovens in automotive coating lines.
Precautions
- Use shielded twisted-pair cables for analog wiring; ground the shield at the module end (single-point).
- Confirm the signal type (4-20mA/0-10V) per channel before wiring; avoid overvoltage (>60V) to prevent damage.
- Use a regulated 24V DC power supply (with overload protection); check polarity before power-on.
- Avoid direct sunlight/corrosive gas; keep away from heat sources (power modules) to prevent overheating.
- Calibrate analog channels annually with ABB tools; clean dust every 3-6 months.
-
