ABB IMASI02 Analog Input Slave Module

1. Key Parameters

• Product Model: IMASI02
• Order Code Reference: Typically paired with ABB AC800M accessories (e.g., 3BSE008515R1 PROFIBUS DP cable, 3BSE003648R1 terminal block kit)
• Product Series: ABB AC800M Distributed I/O Slave Modules (PROFIBUS DP, 4-Channel Analog Input)
• Core Function: Acquires 4-channel analog signals (current/voltage) from field sensors; performs signal filtering and linearization; transmits data to AC800M master via PROFIBUS DP; provides diagnostic alerts (sensor open circuit, overrange); supports distributed process monitoring in space-constrained setups
• Electrical Specifications:

  Parameter	Details	Performance Metrics
  Input Channels	4 independent analog input channels (configurable per channel)	Ideal for small-scale distributed sensor arrays
  Input Signal Types	- Current: 4~20mA DC (compatible with 2-wire/4-wire transmitters) - Voltage: 0~10V DC, ±5V DC (configurable per channel)	Covers common industrial analog sensor outputs
  Measurement Accuracy	- Current: ±0.2% of full scale (FS) at 25℃ - Voltage: ±0.25% FS at 25℃ - Temperature Drift: ≤±0.003% FS/℃	Ensures reliable monitoring for non-critical process variables (e.g., ±0.04mA error for 4~20mA signals)
  Signal Conditioning	- Low-pass filter: 0.5Hz~500Hz (configurable via Control Builder M) - Overrange detection: 115% FS (triggers diagnostic alert) - Open-circuit detection: <3.0mA (for 4~20mA sensors)	Reduces grid noise; identifies sensor faults early
  Communication Protocol	PROFIBUS DP V1 (slave mode); Baud rate: 9.6kbps~12Mbps (auto-negotiates with master) - Cycle time: ≤0.8ms (for 4 channels)	Fast data transmission for near-real-time control
  Power Supply	24V DC ±10% (single input; redundant input optional via accessory) - Current consumption: ≤40mA (no load); ≤120mA (full load)	Compatible with standard industrial 24V DC power supplies
  Isolation Level	- Channel-to-channel: 500Vrms (1min dielectric test) - Input-to-bus/power: 1kVrms (1min dielectric test)	Prevents ground loops in moderate-noise environments

• Mechanical Specifications:
  • Housing Material: Flame-retardant thermoplastic (UL94 V-0); Impact resistance: IK04
  • Dimensions (W×H×D): 22mm × 100mm × 145mm (compact design for dense DIN rail installations)
  • Mounting: 35mm standard DIN rail (TS 35/7.5); Snap-on installation (no tools required)
  • Weight: Approximately 120g
  • Terminals: 1× 12-pin spring-cage terminal (for sensor wiring); 1× 9-pin D-sub connector (PROFIBUS DP)
  • LED Indicators:
    • Power (PWR): Green (24V DC active); Red (power fault)
    • Bus (BUS): Green (PROFIBUS DP normal); Flashing green (data transmission); Red (bus error)
    • Channel (CH1~CH4): Green (signal normal); Amber (overrange); Red (open circuit/fault)
• Environmental Ratings:
  • Operating Temperature Range: -25℃~+60℃ (-13℉~140℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: ≤95% RH (non-condensing, 40℃; suitable for damp skid-mounted systems)
  • Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6; no signal loss)
  • Shock Resistance: 15g acceleration (11ms duration, IEC 60068-2-27; maintains bus connection)
  • EMC Immunity: Complies with IEC 61000-4-2 (ESD: ±8kV contact); IEC 61000-4-4 (EFT: ±2kV) | Resists noise from small motors/VFDs |
• Compliance Standards: IEC 61131-2 (industrial control equipment), EN 61000-6-2 (EMC immunity), UL 508 (industrial safety), CE, RoHS, IEC 61508 (SIL 1 capable)

2. Key Features

• AC800M PROFIBUS DP Exclusivity: Tailored for ABB AC800M PLCs—seamlessly integrates with the AC800M distributed I/O network; Control Builder M software automatically detects the module and maps input registers, eliminating manual configuration and reducing setup time by 40%.
• Compact 4-Channel Design: 22mm-wide form factor with 4 independent channels maximizes space efficiency in dense DIN rail setups (e.g., skid-mounted control cabinets); ideal for small-scale sensor arrays (e.g., 4 pressure sensors on a single process skid) without wasting rack space.
• Balanced Measurement Accuracy: ±0.2% FS for current signals and ±0.25% FS for voltage signals meets the needs of non-critical but reliable process monitoring (e.g., HVAC temperature control, secondary water treatment sensors)—avoids overspecifying for low-risk applications.
• Distributed Architecture Benefits: Enables remote signal acquisition up to 1000m from the AC800M master via PROFIBUS DP—reduces costly analog cable runs in distributed facilities (e.g., multi-skid chemical plants), cutting wiring costs by 50% compared to centralized I/O.
• Simplified Diagnostics: LED indicators for power, bus, and individual channels provide instant visual status; diagnostic data (e.g., open circuit, overrange) is transmitted to the AC800M master—speeds up troubleshooting (e.g., identifying a broken sensor cable in minutes vs. hours).
• Cost-Effective Integration: Lower power consumption (≤120mA full load) and optional redundant power input balance reliability and cost—suitable for budget-constrained projects (e.g., small water treatment plants) without compromising performance.
• SIL 1 Safety Compliance: Meets IEC 61508 SIL 1 requirements, making it suitable for low-risk safety-related applications (e.g., non-critical pump status monitoring)—ensures basic fault mitigation for light industrial safety loops.

3. Application Fields

• AC800M Small-Scale Distributed Control: Primary application—analog signal acquisition for compact AC800M systems:
  • Chemical Process Skids: Acquires 4~20mA signals from pressure transmitters (reactor skids) and temperature transmitters (heat exchanger skids); compact design fits skid-mounted control cabinets, while PROFIBUS DP connects to a central AC800M master in the main control room.
  • Pharmaceutical Pilot Plants: Collects 0~10V signals from level sensors (small batch tanks) and 4~20mA signals from pH transmitters (mixing vessels); accuracy (±0.2% FS) meets pilot-scale process monitoring needs, and isolation prevents cross-contamination of electrical signals.
• HVAC & Building Automation: Controls heating, ventilation, and air conditioning systems:
  • Commercial Buildings: Acquires 0~10V signals from room temperature sensors and 4~20mA signals from air flow sensors (AHUs—Air Handling Units); distributed installation reduces cable runs between floors, while low power consumption integrates with building DC power systems.
  • Data Centers: Monitors 4~20mA signals from server rack temperature sensors and CRAC (Computer Room Air Conditioner) pressure sensors; fast cycle time (≤0.8ms) enables near-real-time HVAC adjustments, preventing server overheating.
• Water & Wastewater Treatment Skids: Supports small-scale treatment systems:
  • Mobile Wastewater Treatment: Acquires 4~20mA signals from turbidity sensors (filter outlets) and dissolved oxygen (DO) sensors (aeration tanks) on mobile skids; compact size and DIN rail mounting simplify skid integration, while humidity tolerance (≤95% RH) withstands damp conditions.
  • Well Water Filtration: Collects 0~10V signals from pressure sensors (well pumps) and 4~20mA signals from flow meters (filtered water output); PROFIBUS DP connects to a remote AC800M master, enabling off-site monitoring of rural filtration systems.
• Light Industrial Manufacturing: Powers small production lines:
  • Packaging Machinery: Acquires 4~20mA signals from temperature sensors (sealing units) and pressure sensors (filling heads) on small packaging lines; EMC immunity resists noise from conveyor motors, ensuring consistent sealing temperature.
  • Electronics Assembly: Monitors 0~10V signals from soldering iron temperature sensors and 4~20mA signals from PCB conveyor speed sensors; compact design fits tight control cabinets, while open-circuit detection alerts to faulty sensor wiring.

The structure and details of the product：
