ABB IMAOM01 Analog Output Module

1. Key Parameters

• Product Model: IMAOM01
• Order Code Reference: Typically paired with ABB AC800M system accessories (e.g., 3BSE008515R1 PROFIBUS DP cable, 3BSE003650R1 terminal block kit, 3BSE004121R1 power redundancy module)
• Product Series: ABB AC800M Distributed I/O Slave Modules (PROFIBUS DP, Analog Output)
• Core Function: Converts digital control signals from AC800M master to standardized analog outputs; drives field actuators (valves, VFDs); provides real-time diagnostic feedback (e.g., short circuit, overload); supports distributed process control in large-scale industrial systems
• Electrical Specifications:

  Parameter	Details	Performance Metrics
  Output Channels	4 independent analog output channels (configurable per channel)	Covers multi-actuator control needs
  Output Signal Types	- Current: 4~20mA DC (sinking/sourcing configurable; max load: 500Ω) - Voltage: 0~10V DC, ±5V DC (max load: 1kΩ)	Compatible with most industrial actuators
  Output Accuracy	- Current: ±0.2% of full scale (FS) at 25℃ - Voltage: ±0.25% FS at 25℃ - Temperature Drift: ≤±0.002% FS/℃	Ensures precise actuator control (e.g., ±0.04mA error for 4~20mA valve control)
  Response Time	≤100μs (step response, 10%~90% of FS); Update rate: 1kHz per channel	Enables fast actuator adjustment for dynamic processes (e.g., reactor pressure control)
  Protection Features	- Short-circuit protection: <100mA (auto-recovery after fault removal) - Overload protection: 120% of rated current/voltage - Reverse polarity protection: No damage from reversed load wiring	Prevents module/actuator damage from electrical faults
  Communication Protocol	PROFIBUS DP V1 (slave mode); Baud rate: 9.6kbps~12Mbps (auto-negotiation with master) - Cycle time: ≤1ms (for 4 channels)	Fast data transmission for real-time control
  Power Supply	24V DC ±10% (redundant input supported via accessory); Current consumption: ≤60mA (no load); ≤200mA (full load)	Compatible with standard industrial 24V DC power systems
  Isolation Level	- Channel-to-channel: 500Vrms (1min dielectric test) - Output-to-bus/power: 2kVrms (1min dielectric test)	Prevents ground loops and EMI coupling between channels/bus

• Mechanical Specifications:
  • Housing Material: Flame-retardant thermoplastic (UL94 V-0); Impact resistance: IK04
  • Dimensions (W×H×D): 22mm × 100mm × 160mm (fits AC800M distributed I/O racks; DIN rail-mountable)
  • Mounting: 35mm standard DIN rail (TS 35/7.5); Snap-on installation (no tools required)
  • Weight: Approximately 150g
  • Terminals: 2× 12-pin spring-cage terminals (for actuator wiring); 1× 9-pin D-sub connector (PROFIBUS DP)
  • LED Indicators:
    • Power (PWR): Green (24V DC active); Red (power fault)
    • Bus (BUS): Green (PROFIBUS DP communication normal); Flashing green (data transmission); Red (bus fault)
    • Channel (CH1~CH4): Green (output normal); Amber (overload/warning); Red (short circuit/fault)
• Environmental Ratings:
  • Operating Temperature Range: -25℃~+60℃ (-13℉~140℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: ≤95% RH (non-condensing, 40℃; suitable for damp process areas)
  • Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6; no output drift)
  • Shock Resistance: 15g acceleration (11ms duration, IEC 60068-2-27; maintains bus communication)
  • EMC Immunity: Complies with IEC 61000-4-2 (ESD: ±8kV contact); IEC 61000-4-4 (EFT: ±2kV); IEC 61000-4-6 (RS: 10V/m) | Resists noise from motors/VFDs |
• Compliance Standards: IEC 61131-2 (industrial control equipment), EN 61000-6-2 (EMC immunity), UL 508 (industrial safety), CE, RoHS, IEC 61508 (SIL 2 capable for safety-related applications)

2. Key Features

• AC800M PROFIBUS DP Exclusivity: Custom-engineered for ABB AC800M PLCs—seamlessly integrates with the AC800M distributed I/O architecture; Control Builder M software automatically detects the module and maps output registers, eliminating manual configuration and reducing setup time by 50%.
• 4-Channel Flexible Output: 4 independent channels support mixed current/voltage signals (configurable per channel)—adapts to diverse actuator types (e.g., 4~20mA control valves, 0~10V VFDs) in a single module, reducing the need for multiple discrete output modules.
• High Control Precision: ±0.2% FS accuracy for current outputs and ±0.25% FS for voltage outputs ensures precise actuator positioning (e.g., ±0.5% valve stroke control for chemical dosing), avoiding process deviations caused by output signal errors.
• Distributed Architecture Advantage: Enables remote actuator control up to 1000m from the AC800M master via PROFIBUS DP—reduces expensive analog signal cable runs in large plants (e.g., oil refineries, power stations), cutting wiring costs by 60% compared to centralized I/O.
• Comprehensive Fault Protection: Built-in short-circuit, overload, and reverse polarity protection safeguards the module and connected actuators (e.g., prevents VFD damage from shorted 4~20mA signals); auto-recovery after fault removal minimizes manual intervention.
• Robust Isolation & Anti-Interference: 2kVrms isolation between outputs and bus/power, plus EMI immunity compliance, suppresses noise from nearby motors, VFDs, or high-voltage cables—ensures stable output signals in electrically harsh environments (e.g., steel mills, chemical plants).
• SIL 2 Compliance: Meets IEC 61508 SIL 2 requirements, making it suitable for safety-related system segments (e.g., emergency shutdown valve control)—ensures low dangerous failure rates (<100 FIT) for risk mitigation.

3. Application Fields

• AC800M Distributed Process Control: Primary application—analog actuator control for AC800M-based systems:
  • Chemical Plants: Outputs 4~20mA signals to control valves (reactor feed/discharge) and pH adjustment pumps; 1000m PROFIBUS DP range covers large reactor zones, while isolation prevents ground loops from chemical dosing systems.
  • Oil Refineries: Sends 4~20mA signals to flow control valves (crude oil pipelines) and ±5V signals to level control actuators (storage tanks); anti-interference design resists EMI from refinery compressors, ensuring accurate flow control for custody transfer.
• Power Generation Auxiliary Systems: Controls auxiliary equipment in power plants:
  • Thermal Power Plants: Outputs 4~20mA signals to boiler feedwater control valves and turbine lubricating oil pressure regulators; distributed installation avoids high-temperature damage to centralized I/O, while fast response time (≤100μs) adapts to dynamic boiler conditions.
  • Hydropower Stations: Sends 0~10V signals to turbine guide vane actuators and 4~20mA signals to penstock control valves; humidity tolerance (≤95% RH) withstands damp powerhouse environments, ensuring reliable turbine speed control.
• Water & Wastewater Treatment: Drives process actuators in treatment facilities:
  • Municipal Water Treatment: Outputs 4~20mA signals to filter backwash valves and chemical dosing pumps; short-circuit protection prevents pump damage from wiring faults, while diagnostic data alerts operators to valve sticking.
  • Industrial Wastewater: Sends 4~20mA signals to aeration blower VFDs (dissolved oxygen control) and sludge valve actuators; distributed architecture reduces cable runs between treatment basins, lowering installation costs.
• Pharmaceutical & Food Manufacturing: Ensures compliant actuator control:
  • Pharmaceutical Production: Outputs 4~20mA signals to bioreactor agitator speed controllers and lyophilizer (freeze-dryer) temperature valves; precision (±0.2% FS) meets GMP requirements for batch consistency, while isolation prevents cross-contamination of electrical signals.
  • Food Processing: Sends 4~20mA signals to filling machine flow control valves and oven temperature regulators; fast update rate (1kHz) ensures consistent filling volumes and baking temperatures, complying with HACCP standards.
