ABB IH580

Product Overview

The ABB IH580 is a high-performance industrial 3-Button Trackball designed for Human-Machine Interface (HMI) and control system operation. It replaces a mouse in industrial environments for cursor movement, menu selection, page scrolling, and command confirmation. The IH580 is rugged and durable, suitable for harsh control room and operator station environments, widely used in ABB automation and monitoring systems.

Detailed Specifications

• Model / Part Number: IH580

• Type: 3-Button Trackball

• Input Interface: Industrial connector (compatible with ABB HMI systems)

• Buttons: 3 (Left, Right, Middle)

• Trackball Function: Cursor movement, scrolling

• Power Supply: 24 VDC (typical industrial HMI supply)

• Response: High-speed, low latency

• Mounting: Panel or operator station

• Operating Temperature: –20°C to +60°C

• Storage Temperature: –40°C to +70°C

• Protection Class: IP20

• Applicable Systems: ABB DCS, SCADA, Advant OCS, MOD series monitoring systems

Key Advantages & Features

• Industrial-grade reliability — Resistant to dust, vibration, and harsh environments for long-term use

• High-precision control — Trackball allows accurate cursor movement and selection

• Multi-function buttons — Left, right, and middle buttons support versatile operations

• Easy integration — Compatible with ABB control systems and operator panels

• Ergonomic design — Comfortable for extended operation, reducing fatigue

• Fast response — Low latency ensures timely and accurate operation

Applications

• Industrial automation control systems

• Power plants, petrochemical, chemical, and metallurgical process monitoring

• DCS / SCADA operator stations

• Control room HMI terminals

• Industrial operator panels and consoles

• Automation system maintenance and upgrade projects

Precautions

1. Disconnect power before installation and ensure connector compatibility with the control system.

2. Avoid high temperature, high humidity, dust, and corrosive environments.

3. Regularly clean the trackball and buttons to maintain sensitivity.

4. Do not use beyond rated industrial applications.

5. Keep a spare IH580 for critical systems to ensure continuous operation.

6. Installation and maintenance should be performed by qualified electrical or automation personnel.
