ABB HIEE200072R2 USB030AE02 power module

• Input Voltage Range: 85-264 V AC (single-phase) / 120-370 V DC (wide compatibility with global power grids)​

• Input Frequency: 47-63 Hz (AC input; frequency tolerance ±5%)​

• Output Voltage: Regulated 24 V DC (±1% accuracy at full load; ±2% over entire load range)​

• Output Current: 30 A (continuous); 36 A (peak, 10 seconds max for load surges)​

• Output Power: 720 W (max continuous power; 864 W peak)​

• Efficiency: Up to 92% (at 50-100% load; meets EN 61000-3-2 energy efficiency standards)​

• Overcurrent Protection (OCP): Auto-recovery after fault removal (trip current: 33-36 A)​

• Overvoltage Protection (OVP): Latching shutdown (trip voltage: 28-30 V DC; resets via power cycle)​

• Over-temperature Protection (OTP): Thermal shutdown at 85°C (auto-recovery when temperature drops to 75°C)​

• Short-Circuit Protection (SCP): Current-limited mode (prevents damage from output short circuits)​

• Input Surge Protection: EN 61000-4-5 compliant (6 kV contact, 10 kV air discharge for AC input)​

• Redundancy Support: Parallelable design (up to 6 modules) for N+1 redundancy (requires external redundancy module)​

• Monitoring Interface: 1×RS485 port (supports Modbus RTU protocol for remote voltage/current/temperature monitoring)​

• Status Indicators: 3 LED indicators (green: normal operation; yellow: reduced load; red: fault)​

• Fault Logging: Stores up to 50 historical fault records (timestamped; accessible via RS485)​

• Operating Temperature: -25°C ~ +70°C (derates 2% per °C above 55°C)​

• Storage Temperature: -40°C ~ +85°C​

• Relative Humidity: 5% ~ 95% (non-condensing; no derating required)​

• Vibration Resistance: 10-500 Hz, 2 g acceleration (IEC 60068-2-6; compliant with industrial machinery standards)​

• Shock Resistance: 30 g acceleration, 11 ms duration (IEC 60068-2-27)​

• EMC Compliance: EN 61000-6-2 (industrial immunity), EN 61000-6-4 (industrial emissions)​

• Dimensions: 150×100×40 mm (Length×Width×Height)​

• Mounting Type: DIN rail mounting (compatible with EN 50022 standard) / Panel mounting (via optional brackets)​

• Weight: Approximately 800 g​

• Cooling: Convection cooling (no fans; reduces dust ingress and maintenance needs)​

• Terminals: Screw terminals (accepts 1.5-4 mm² cables; torque rating: 0.8-1.2 N·m)​

• System Compatibility: Designed for ABB AC 800M, AC 500, and Freelance control systems; compatible with third-party 24 V DC industrial equipment​

• Certifications: CE (EN 61010-1), UL 508, CSA C22.2 No. 14-19, IEC 61010-1 (safety standards for industrial control equipment)​

• Industrial Automation: Powers ABB AC 800M/AC 500 controllers, I/O modules (e.g., digital/analog input/output modules), and field sensors in manufacturing lines.​

• Process Control: Provides stable power for chemical, oil & gas, and pharmaceutical process control systems (e.g., DCS modules, valve controllers).​

• Power Generation: Supplies power to turbine control systems, SCADA modules, and monitoring devices in thermal, hydro, and renewable energy plants.​

• Transportation Infrastructure: Powers signaling systems, traffic control modules, and surveillance equipment in railways and smart highways.​

• Marine & Offshore: Suitable for offshore oil platforms and marine vessels (wide temperature range and vibration resistance meet maritime standards).​

• Mount on a clean, flat DIN rail or panel; ensure 50 mm clearance on all sides for convection cooling (do not block airflow).​

• Avoid installation near heat sources (e.g., motors, inverters) or areas with direct sunlight, oil, or corrosive gas.​

• Use copper cables with 1.5-4 mm² cross-section for input/output; tighten terminals to 0.8-1.2 N·m to prevent loose connections and overheating.​

• Separate AC input cables from DC output cables (reduces electromagnetic interference); ground the module via the dedicated ground terminal.​

• When paralleling modules for redundancy, use only ABB-approved redundancy modules (e.g., HIEE200073R1) to ensure load balancing and fault isolation.​

• Set unique Modbus addresses for each module in a redundant system to avoid communication conflicts.​

• Do not exceed the 30 A continuous output current (derate at temperatures above 55°C per specifications).​

• For short-circuit faults, reset the module by cycling input power (do not attempt to bypass protection mechanisms).​

• Inspect terminals quarterly for corrosion or loose connections; clean the module housing with a dry, soft brush (no liquids).​

• Replace the module if the red fault LED remains lit after power cycling (indicates a permanent internal fault).​

• Do not disassemble the module (voids warranty and risks electrical shock—internal capacitors retain charge after power-off).
