ABB HDZ-60-30C High-Efficiency Energy Storage Motor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB HDZ-60-30C is a high-efficiency Energy Storage Motor, designed for industrial automation and energy management systems. This motor efficiently converts and stores mechanical or electrical energy, reducing energy loss, improving system efficiency, and enabling dynamic energy regulation for renewable energy or industrial production lines.

The HDZ-60-30C features precision windings and optimized magnetic circuits, offering low energy consumption, low noise, high reliability, and long service life, maintaining stable performance under continuous operation and high load conditions.

2. Main Technical Specifications

• Model: HDZ-60-30C

• Type: High-Efficiency Energy Storage Motor

• Rated Power: 60 kW

• Rated Voltage: 380–480 V AC

• Rated Current: 90 A

• Rated Speed: 1500 rpm

• Efficiency Class: IE4 / High Efficiency

• Power Factor: 0.92

• Insulation Class: F

• Starting Method: Direct start / VFD start

• Noise Level: <70 dB(A)

• Operating Temperature: -20°C to +50°C

• Protection Class: IP54 / IP55

• Mounting: B3 foot-mounted

• Weight: ~280 kg

• Energy Storage Capability: Compatible with flywheel or battery storage, supports dynamic energy recovery and release

3. Advantages and Features

1. High Efficiency and Energy Saving

• Optimized magnetic circuit and high-efficiency winding reduce energy loss.

• Overall system efficiency exceeds traditional motors, achieving significant energy savings.

2. Energy Storage and Recovery

• Supports mechanical or electrical energy storage, recovering energy from industrial processes and braking.

• Increases energy utilization and lowers operating costs.

3. High Reliability and Long Service Life

• Industrial-grade materials and precision manufacturing for continuous and high-load operation.

• High-temperature and low-vibration design extends motor life.

4. Easy Integration and Control

• Supports direct or VFD start for easy system integration.

• Compatible with energy management and automation systems for intelligent regulation.

5. Eco-Friendly and Low Noise

• High-efficiency design reduces energy consumption and carbon footprint.

• Optimized structure lowers operational noise, suitable for industrial and environmental requirements.

4. Typical Application Areas

• Industrial automation production line drives and energy storage

• Elevators, cranes, and large machinery regenerative braking systems

• Renewable energy storage systems (wind, solar)

• Energy management and dynamic load regulation

• High-efficiency factory energy recovery systems

5. Precautions

1. Ensure motor rated power, voltage, and speed match system requirements before installation.

2. Install in a dry, well-ventilated environment, avoiding moisture or dust.

3. Ensure proper cooling during operation to prevent overheating.

4. Electrical connections must be secure and comply with ABB motor and electrical safety standards.

5. Regularly inspect bearings, cooling system, and energy storage connections.

6. Avoid prolonged operation under overload or frequent start-stop conditions.

7. Energy storage system connections and recovery devices must comply with safety standards.
