ABB EI812F (Order Code: 3BDH000021R1) Ethernet Module

1. Key Parameters

• Product Model: EI812F
• Order Code/Part Number: 3BDH000021R1 (unique identifier for procurement and PLC compatibility verification)
• Product Series: ABB AC 500-S/eCo Ethernet Communication Modules
• Core Function: Enables Ethernet-based data communication between AC 500 PLCs and industrial networks; supports standard protocols for HMI/SCADA integration and device interoperability
• Communication Specifications:
  • Protocols Supported: Modbus-TCP, Ethernet/IP (client/server), TCP/IP, UDP/IP, and ABB proprietary protocols for PLC-to-PLC communication
  • Network Interface: 2× 10/100Base-TX Ethernet ports (RJ45; supports copper cabling)
  • Data Transfer Rate: 10/100Mbps (auto-negotiation; full-duplex mode)
  • Redundancy Support: Built-in network redundancy (via dual ports); supports Media Redundancy Protocol (MRP) for <50ms failover
  • Maximum Connections: 64 concurrent TCP/IP connections (accommodates multiple HMI clients and network devices)
  • Latency: ≤2ms (for real-time data packets; ensures timely response in control applications)
• Electrical Specifications:
  • Power Supply (Backplane): 5V DC (from AC 500 PLC rack power supply; typical current: 0.25A; maximum current: 0.4A)
  • Power Consumption: ≤2W (total, including communication and processing)
  • Isolation: 1kVrms (between Ethernet ports and backplane; 500Vrms between individual Ethernet ports)
  • Surge Protection: IEC 61000-4-5 (±2kV contact discharge; ±4kV air discharge for Ethernet ports)
  • EMC Immunity: Compliant with IEC 61000-6-2 (industrial environment); resistant to electromagnetic interference from motors and drives
• Mechanical Specifications:
  • Housing Type: Reinforced flame-retardant plastic (UL94 V-0; for EMI shielding and mechanical durability)
  • Dimensions (W×H×D): 86.1mm × 102mm × 58.5mm (1-module width; fits AC 500 standard DIN rail racks)
  • Mounting: DIN rail-mounted (35mm standard DIN rail per EN 60715) + backplane connector (for PLC integration)
  • Weight: Approximately 180g
  • LED Indicators:
    • Power (PWR): Green (module powered on); Red (power fault)
    • Backplane Communication (BUS): Green (normal communication with PLC); Red (communication fault)
    • Ethernet Port 1 (ETH1): Green (link active); Blinking Green (data transmission); Red (link fault)
    • Ethernet Port 2 (ETH2): Green (link active); Blinking Green (data transmission); Red (link fault)
    • Redundancy (RED): Green (redundancy active); Amber (failover in progress); Red (redundancy fault)
• Environmental Ratings:
  • Operating Temperature Range: -40℃~+70℃ (-40℉~158℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: ≤95% RH (non-condensing, 40℃)
  • Vibration Resistance: 10~500Hz, 2g acceleration (IEC 60068-2-6; no communication loss)
  • Shock Resistance: 30g acceleration (11ms duration, IEC 60068-2-27; maintains port integrity)
  • Ingress Protection: IP20 (suitable for installation in control cabinets)
• Compliance Standards: IEEE 802.3 (Ethernet standards), IEC 61131-3 (industrial communication), UL 508 (industrial safety), CE, RoHS

2. Key Features

• Dual Ethernet Ports with Redundancy: Two 10/100Mbps ports support network redundancy via MRP, enabling automatic failover (<50ms) to ensure uninterrupted communication in mission-critical applications (e.g., manufacturing lines, water treatment plants).
• Multi-Protocol Support: Compatible with Modbus-TCP and Ethernet/IP, facilitating seamless integration with diverse industrial systems (e.g., Rockwell HMI, Siemens SCADA, third-party data loggers) without requiring protocol converters.
• High Connection Capacity: Supports 64 concurrent TCP/IP connections, allowing the PLC to communicate with multiple devices simultaneously—ideal for complex automation networks with distributed HMIs and monitoring systems.
• Seamless AC 500 Integration: Plug-and-play compatibility with AC 500-S and AC 500-eCo PLCs. Configuration via ABB Automation Builder software simplifies network setup, protocol selection, and connection management—no custom drivers required.
• Robust Isolation & Surge Protection: 1kVrms isolation between ports and backplane, combined with surge protection, minimizes interference from industrial noise (e.g., motor starters, variable-speed drives) and protects against voltage spikes.
• Industrial-Grade Durability: Wide operating temperature range (-40℃~+70℃), vibration/shock resistance, and UL94 V-0 flame-retardant housing ensure reliable performance in harsh environments (e.g., mining sites, chemical plants, outdoor installations).
• Efficient Power Consumption: Low power draw (≤2W) reduces heat generation, extending the lifespan of the module and surrounding components—no additional cooling required for standard rack configurations.

3. Application Fields

• AC 500 PLC Network Integration: Primary application—connects AC 500-S/eCo PLCs to Ethernet-based systems in:
  • Manufacturing Automation: Transmits production data (e.g., machine status, output rates) to HMIs and MES (Manufacturing Execution Systems) in automotive, electronics, and packaging lines.
  • Water & Wastewater Treatment: Enables communication between PLCs and SCADA systems for monitoring pump status, chemical dosing rates, and effluent quality.
  • Building Automation: Links AC 500-eCo PLCs to HVAC control systems, lighting panels, and security devices via Ethernet/IP.
• Industrial Data Acquisition: Collects and transmits real-time process data to historians and analytics platforms in:
  • Food & Beverage Processing: Sends batch records, temperature profiles, and equipment health data to compliance systems (e.g., FDA/GMP reporting).
  • Mining Operations: Transmits crusher performance metrics, conveyor speeds, and safety sensor data to central monitoring stations.
• Redundant Control Architectures: Supports fault-tolerant networks in critical applications:
  • Power Generation Auxiliaries: Ensures continuous communication between PLCs and turbine control systems, preventing data loss during network disruptions.
  • Pharmaceutical Production: Maintains connectivity with sterile processing equipment and recipe management systems to avoid batch interruptions.
• Remote Monitoring: Facilitates data transmission to remote operation centers (via secure VPN) in:
  • Renewable Energy Installations: Sends solar inverter output and wind turbine status data to centralized monitoring platforms.
  • Oil & Gas Pipelines: Transmits pressure, flow, and valve position data from remote pumping stations to control centers.

4. Precautions

• PLC Compatibility: Use exclusively with ABB AC 500-S and AC 500-eCo PLC systems. Installation in non-AC 500 racks (e.g., Siemens S7, Rockwell ControlLogix) will cause backplane communication failure and damage the module.
• Redundancy Configuration: Configure MRP via ABB Automation Builder to enable proper failover. Mismatched redundancy settings (e.g., incorrect ring topology) will prevent automatic switchover during network faults.
• Ethernet Cable Requirements: Use shielded Cat5e or higher Ethernet cables (24AWG) with properly grounded shields. Unshielded or low-grade cables increase EMI susceptibility and signal degradation, especially in noisy industrial environments.
• Network Security: Implement industrial firewalls and access controls to prevent unauthorized access to the module. Avoid direct connection to public networks—use VPNs for remote communication in critical infrastructure.
• Grounding Practices: Connect the module’s ground terminal to the AC 500 rack’s common ground (resistance ≤1Ω). Ensure Ethernet cable shields are grounded at both ends to maximize EMI protection.
• Firmware Updates: Keep firmware updated via Automation Builder to ensure protocol compatibility and security patches. Back up configurations before updating—mismatched firmware with the PLC causes communication errors.
• Maintenance Checks: Inspect quarterly:
  • Verify LED status (no red faults; redundancy indicator green; ports blinking for active data transfer).
  • Test redundancy by disconnecting the primary Ethernet cable—confirm failover to the secondary port within 50ms.
  • Clean Ethernet ports with compressed air to remove dust—dirty connectors cause intermittent link failures
