ABB EHDB130ABB TA524 Digital Output Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us..

Product Overview

The ABB EHDB130 / TA524 is an industrial-grade digital output module designed for ABB DCS systems and automation control cabinets. This module provides reliable digital signal outputs to drive relays, actuators, or other external devices. It supports modular installation for fast system integration, ensuring high-precision and responsive control signals.

Technical Specifications (Typical)

• Model: EHDB130 / TA524

• Type: Digital Output Module

• Number of Outputs: 16 channels (standard configuration, system-dependent)

• Output Type: 24 V DC / 250 V AC (depending on version and configuration)

• Output Current: Max 0.5 A per channel

• Operating Voltage: 24 V DC

• Power Consumption: approx. 5 W

• Operating Temperature: 0 to +55°C

• Storage Temperature: -20 to +70°C

• Humidity: ≤95%, non-condensing

• Protection Class: IP20 (for use inside control cabinet)

• Mounting: DIN rail or module slot installation

• Dimensions (L × W × H): 160 × 90 × 40 mm

• Weight: approx. 0.8 kg

• Communication Interface: Bus interface or dedicated controller interface

Features and Advantages

1. High-reliability digital outputs ensure stable control signal transmission.

2. Modular design allows fast installation, expansion, and maintenance.

3. Multi-channel output supports driving multiple actuators and devices.

4. High compatibility with ABB DCS, SCADA systems, and controllers.

5. Industrial-grade reliability suitable for long-term operation.

6. Low power consumption and compact design save control cabinet space.

Application Areas

• Digital signal output control in ABB DCS systems

• Driving actuators in industrial automation control cabinets

• Industrial automation in power, petrochemical, metallurgy, water treatment, and manufacturing

• Signal driving and control expansion applications

Precautions

1. Disconnect power before installation to prevent module damage.

2. Verify load, voltage, and current specifications match module parameters.

3. Avoid installation in high temperature, high humidity, vibration, or corrosive environments.

4. Periodically check wiring and module status to ensure safe and reliable operation.

5. Installation and maintenance should be performed by personnel experienced in industrial control systems.

The structure and details of the product：







Please make an inquiry for more models
