ABB DSTX180 Connector Unit

ABB DSTX180 Connector Unit

Product Overview

The ABB DSTX180 is a Connector Unit used in industrial automation systems to connect modules with control systems. It ensures stable signal transmission, provides reliable electrical connections, and supports modular installation and quick maintenance. The DSTX180 is compact, highly reliable, and serves as a critical interface component in industrial automation equipment.

Main Technical Specifications

• Model: DSTX180

• Product Type: Connector Unit

• Interface Type: Industrial control signal interface

• Input/Output Type: Digital / Analog interface, depending on system configuration

• Rated Voltage: 24 V DC

• Rated Current: According to module specifications

• Mounting: DIN rail or screw mounting

• Protection Rating: IP20 (for control cabinet installation)

• Operating Temperature: 0°C to +55°C

• Storage Temperature: -20°C to +70°C

• Status Indicators: LEDs for power and signal status

• Compatibility: Compatible with ABB PLC, DCS, and automation modules

Advantages & Key Features

• Reliable connections for stable electrical signal transmission.

• Modular design allows easy installation, removal, and system expansion.

• High durability with industrial-grade materials resistant to vibration and high temperature.

• Quick maintenance with easy module replacement and expansion.

• Visual status indicators with LEDs for power and signal monitoring.

• Strong compatibility with ABB PLC, DCS, and other industrial automation equipment.

Application Areas

• Signal and power connections between modules in industrial automation systems

• Module interfaces for PLC and DCS systems

• Communication interfaces for automated production line equipment

• Industrial robot and manipulator module connections

• Power, metallurgy, petrochemical, water treatment, and smart manufacturing industries

• Interface connections for fans, pumps, compressors, and other industrial equipment

Precautions

1. Ensure supply voltage and interface type match the system before installation.

2. Install the connector unit inside a control cabinet or protective enclosure to avoid moisture, dust, and corrosion.

3. Disconnect power before wiring or maintenance to prevent short circuits or accidental operation.

4. Regularly inspect interfaces, cables, and LED indicators to ensure normal operation.

5. Avoid prolonged overload operation to extend the unit's lifespan.

6. Input and output signals should remain within specifications to prevent damage.

7. Follow industrial safety standards during installation and operation to ensure personnel and equipment safety.
