ABB DSTX151 Connection Unit

1. Key Parameters

• Product Model: DSTX151
• Product Series: ABB AC500 Series Industrial Mid-Density Mixed-Signal Connection Units (Multi-Type I/O Management)
• Core Function: Provides 16-channel mixed I/O (8 digital inputs + 4 digital outputs + 4 analog channels); supports 24V DC digital signals (≤500mA per output) and analog signals (4-20mA/0-10V); integrates active signal filtering, per-channel overcurrent protection, and surge suppression; enables real-time status monitoring via LEDs; supports DIN rail mounting or AC500 backplane integration; ensures stable transmission of mixed signals between field devices and AC500 PLCs
• Electrical & Signal Specifications:

  Parameter	Details	Performance Metrics
  Signal Compatibility	- I/O Configuration: 16 channels (8 digital inputs + 4 digital outputs + 4 analog channels, fixed) - Digital Inputs: Dry contact/NPN/PNP (24V DC); input impedance 2kΩ; response time <1ms; voltage range 18V~30V DC - Digital Outputs: Sourcing (PNP); max 500mA continuous per channel, 1A peak (10ms); voltage 24V DC - Analog Channels: 4-20mA current / 0-10V voltage; input resolution 16-bit; linearity error ±0.05% FS; input impedance 10MΩ (voltage)/25Ω (current)	Mixed I/O design eliminates separate digital/analog connection units, reducing cabinet clutter by 50% for medium-scale systems (e.g., 6 proximity sensors + 3 solenoids + 4 pressure transducers); 16-bit analog resolution ensures precision measurement (±0.1℃ for temperature transducers); <1ms digital response supports fast-paced tasks (conveyor sorting)
  Signal Protection & Conditioning	- Overcurrent Protection: 4× 600mA slow-blow fuses (digital outputs) + 4× 300mA PTC fuses (analog channels) - Noise Filtering: Active 2nd-order low-pass filter (500Hz cutoff for analog) + 50Hz/60Hz notch filter (digital/analog) + EMI shielding (aluminum inner layer) - ESD/Surge Protection: 10kV contact discharge (IEC 61000-4-2) + 2.5kV surge protection (IEC 61000-4-5) per channel - Reverse Polarity Protection: Diode-based (all signal channels + power input, ≤24V DC)	Active filtering reduces industrial noise (VFDs, motors) by 70%~80%, avoiding analog measurement drift; surge protection withstands grid transients (substations); PTC fuses auto-recover from temporary overloads, minimizing downtime

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 120mm (W) × 90mm (H) × 65mm (D) - Mounting Type: 2 options (1) DIN rail mount (EN 50022, 35mm, tool-less snap-on with anti-slip latch); (2) AC500 backplane mount (compatible with DSPC/DSQC racks) - Housing Material: Flame-retardant thermoplastic (UL 94 V0) + thick conformal coating (IPC-CC-830, Class 3) - Weight: Approximately 420g - Indicators: 16× channel LEDs (green = active; red = fault); 1× power LED (green = 24V present); 1× filter status LED (blue = active filtering); 1× fault summary LED (yellow = 1+ channel fault)	Class 3 conformal coating resists oil, dust, and moisture; anti-slip DIN rail latch prevents dislodgment in high-vibration environments (near heavy machinery); multi-color LEDs enable precise diagnostics (blue = filtering active)
  Environmental Ratings	- Operating Temperature Range: -25℃~+75℃ (-13℉~167℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing/condensing, up to 55℃) - Vibration Resistance: 10~500Hz, 1.2g acceleration (IEC 60068-2-6) - Shock Resistance: 25g (11ms half-sine, IEC 60068-2-27) - EMC Compliance: EN 61000-6-2 (immunity: Level 4); EN 61000-6-3 (emission: Class B)	-25℃~+75℃ range suits extreme environments (arctic substations, desert manufacturing); condensing humidity tolerance eliminates dehumidifiers in damp areas (water treatment plants); Level 4 EMC immunity withstands severe industrial noise (welding, high-voltage switchgear)

• Protection & Compliance Specifications:

  Parameter	Details	Performance Metrics
  Protection Features	- Overvoltage Protection: 36V DC clamp (transient suppression diode) for all channels - Short-Circuit Protection: Current limiting (≤700mA digital outputs; ≤400mA analog channels) - Thermal Protection: 85℃ ±5℃ thermal shutdown (power rail, auto-recovery) - Analog Signal Isolation: 2.5kVrms galvanic isolation between analog and digital circuits	Galvanic isolation prevents analog signal interference from digital switching; thermal shutdown protects against cabinet heat buildup; overvoltage clamp prevents damage from faulty power supplies
  Compliance Standards: CE, UL 508, CSA C22.2 No.14, IEC 61131-2 (industrial control), IEC 61000-6-2 (EMC), RoHS 2.0, ISO 9001

2. Core Features

• 16-Channel Mixed I/O (Digital + Analog): Combines 8 digital inputs, 4 digital outputs, and 4 analog channels in one unit—eliminates the need for separate digital and analog connection modules, cutting hardware costs by 40% and wiring time by 35% for medium-scale systems (e.g., process control with temperature/pressure monitoring + actuator control).
• High-Precision Analog Signal Handling: 16-bit analog resolution + ±0.05% linearity error—delivers laboratory-grade measurement accuracy for transducers (e.g., pressure, temperature, flow); 2.5kVrms galvanic isolation between analog/digital circuits prevents cross-talk, ensuring stable analog readings in noisy industrial environments.
• Enhanced Multi-Signal Protection: 10kV ESD + 2.5kV surge protection + thermal shutdown—comprehensive safeguards against industrial faults (static discharge, grid transients, overheating); PTC fuses for analog channels auto-recover from temporary overloads, avoiding manual replacements in 24/7 operations (e.g., chemical dosing lines).
• Active Noise Suppression: 2nd-order active filtering + notch filter—reduces high-frequency noise from VFDs, motors, and welding machines by 70%~80%; critical for analog signals (e.g., 4-20mA pressure readings) where noise causes process deviations, and digital signals (e.g., safety interlocks) where false triggers risk downtime.
• Industrial-Grade Durability: UL 94 V0 housing + Class 3 conformal coating + -25℃~+75℃ operating range—withstands harsh conditions (oil mist, dust, moisture, extreme temperatures) that degrade standard connection units; ideal for heavy manufacturing (automotive stamping) and outdoor applications (substation auxiliary controls).
• Intuitive Diagnostics & Maintenance: 16 individual channel LEDs + filter/fault summary indicators—technicians can quickly identify analog/digital faults (red LED = overcurrent), confirm filtering activation (blue LED), and locate issues without multimeters; front-access fuses enable fast replacements without removing the unit from the DIN rail.
• Seamless AC500 Integration: Optimized for ABB AC500 I/O modules (e.g., DSMB178 digital, DSMB340 analog)—connects via standard 22AWG~16AWG wires; terminal pinouts match AC500 backplane standards; works with ABB Automation Builder for centralized I/O monitoring and fault logging, ensuring plug-and-play deployment.

3. Application Fields

• Manufacturing Automation: Mixed-Signal Control Lines:
  • Automotive Component Assembly: Manages signals for engine part manufacturing—8 digital inputs handle 6 proximity sensors (part alignment) + 2 safety door switches; 4 digital outputs control 3 solenoid valves (clamping) + 1 conveyor relay; 4 analog channels monitor 2 pressure transducers (clamp force) + 2 temperature sensors (welding tips); active filtering prevents noise from assembly line motors, ensuring precise clamp force control.
  • Electronics SMT Factories: Consolidates signals for reflow oven auxiliaries—8 digital inputs handle 4 photoelectric sensors (PCB presence) + 4 limit switches (oven door); 4 digital outputs control 2 cooling fan relays + 2 alarm buzzers; 4 analog channels monitor 4 zone temperature transducers (oven heating); 16-bit analog resolution ensures ±0.5℃ temperature accuracy, avoiding soldering defects.
• Process Control: Multi-Parameter Monitoring:
  • Chemical Plants: Connects devices for reactor auxiliary systems—8 digital inputs handle 6 float switches (reagent tanks) + 2 pressure switches (pipework); 4 digital outputs control 3 dosing pump relays + 1 valve solenoid; 4 analog channels monitor 2 pH transducers (reaction mixture) + 2 flow transducers (reagent feed); galvanic isolation prevents analog signal corruption from digital pump switching, ensuring process safety.
  • Water Treatment Facilities: Manages mixed signals for filtration units—8 digital inputs handle 5 flow switches (filter inflow) + 3 door interlocks (filter access); 4 digital outputs control 2 backwash valve relays + 2 fan relays; 4 analog channels monitor 2 turbidity transducers (filter clarity) + 2 level transducers (waste tanks); condensing humidity tolerance suits damp pump station environments.
• Energy & Utilities: Substation Auxiliary Systems:
  • Power Substations (220kV+): Controls signals for transformer auxiliaries—8 digital inputs handle 4 breaker position switches + 4 fan status sensors; 4 digital outputs control 3 cooling fan relays + 1 alarm relay; 4 analog channels monitor 2 oil temperature transducers + 2 current transducers (auxiliary transformers); surge protection withstands grid transients; vibration resistance prevents terminal loosening from transformer operation.
  • Solar PV Plants (1GW+): Manages inverter mixed signals—8 digital inputs handle 6 string disconnect switches + 2 emergency stop buttons; 4 digital outputs control 2 inverter cooling fan relays + 2 status LEDs; 4 analog channels monitor 2 DC bus voltage transducers + 2 string current transducers; -25℃~+75℃ range suits desert solar farms; EMI shielding resists inverter switching noise.
• Heavy Machinery: Condition Monitoring:
  • Mining Equipment: Connects sensors for conveyor belt systems—8 digital inputs handle 4 pull-cord emergency stops + 4 alignment switches; 4 digital outputs control 2 brake relays + 2 lubrication pump relays; 4 analog channels monitor 2 vibration transducers (conveyor motors) + 2 temperature transducers (bearings); Class 3 conformal coating resists mine dust and moisture, extending service life underground.
  • Construction Machinery: Manages signals for crane auxiliaries—8 digital inputs handle 4 limit switches (crane height) + 4 load switches (weight); 4 digital outputs control 2 winch relays + 2 light relays; 4 analog channels monitor 2 load transducers (crane capacity) + 2 pressure transducers (hydraulic systems); shock resistance survives construction site impacts.

The structure and details of the product：

Please make an inquiry for more models
