ABB DSTX001 Connection Unit

1. Key Parameters

• Product Model: DSTX001
• Product Series: ABB AC500 Series Industrial Compact Connection Units (Mini-Scale I/O Wiring Management)
• Core Function: Provides 8-channel mixed digital I/O (6 inputs + 2 outputs, fixed configuration); supports 24V DC signal transmission for low-power devices (≤200mA per output); integrates passive noise filtering and per-channel overcurrent protection; enables visual fault diagnostics via LEDs; supports DIN rail mounting (via adapter) or direct panel mounting; ensures stable signal transmission between small field device clusters and AC500 digital I/O modules
• Electrical & Signal Specifications:

  Parameter	Details	Performance Metrics
  Signal Compatibility	- I/O Configuration: 8 channels (6 digital inputs + 2 digital outputs, fixed) - Supported Signals: Digital dry contact, NPN/PNP open-collector (24V DC) - Input Impedance: 3kΩ (24V DC input) - Output Current: Max 200mA per channel (continuous); 400mA peak per channel (10ms, for micro-solenoid inrush) - Switching Speed: <1.5ms (digital signal transition) - Input Voltage Range: 18V DC~30V DC	8-channel mixed design consolidates wiring for tiny I/O clusters (e.g., 4 photoelectric sensors + 2 limit switches + 1 small relay + 1 indicator light); <1.5ms switching speed supports basic responsive tasks (e.g., part counting, position detection); 200mA output capacity covers ultra-low-power actuators (micro-relays, LED indicators)
  Signal Protection & Filtering	- Overcurrent Protection: 2× 250mA slow-blow fuses (output channels, replaceable via front access) - Noise Filtering: Passive RC low-pass filter (1.5kHz cutoff) for digital inputs; 50Hz/60Hz line noise suppression - ESD Protection: 6kV contact discharge / 12kV air discharge (IEC 61000-4-2) per channel - Reverse Polarity Protection: Diode-based (input channels and power supply, ≤24V DC)	Slow-blow fuses protect AC500 digital I/O modules (e.g., DSMB178) from shorted micro-actuator wires; RC filters reduce electrical noise from nearby small motors or fans by 40%~55%; ESD protection safeguards against static discharge during installation/maintenance of compact devices

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 60mm (W) × 40mm (H) × 12mm (D) - Mounting Type: 2 options (1) DIN rail mount (via optional DST-MNT01 mini adapter); (2) Direct panel mount (2x M3 screws) - Housing Material: Flame-retardant FR4 circuit board (UL 94 V0) + ultra-thin conformal coating (IPC-CC-830, Class 2) - Weight: Approximately 22g - Indicators: 8× channel status LEDs (green = active; red = overcurrent/fault); 1× power LED (green = 24V DC present)	Ultra-miniature form factor (60×40×12mm) fits in ultra-dense AC500 cabinets or tiny enclosures (e.g., 19-inch 0.5U panels); lightweight design avoids DIN rail sagging even with multiple units; Class 2 conformal coating resists dust and non-corrosive moisture in confined spaces
  Environmental Ratings	- Operating Temperature Range: -20℃~+60℃ (-4℉~140℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing, 40℃) - Vibration Resistance: 10~500Hz, 0.6g acceleration (IEC 60068-2-6) - Shock Resistance: 12g (11ms half-sine, IEC 60068-2-27) - EMC Compliance: EN 61000-6-2 (immunity: Level 2); EN 61000-6-3 (emission: Class B)	-20℃~+60℃ range suits temperature-controlled industrial spaces and commercial buildings; vibration resistance prevents solder joint loosening in lightweight, space-constrained cabinets; Level 2 EMC immunity resists interference from small office/industrial equipment (e.g., printers, mini-pumps)

• Protection & Compliance Specifications:

  Parameter	Details	Performance Metrics
  Protection Features	- Short-Circuit Protection: Current limiting (≤300mA per output channel) - Overvoltage Protection: 30V DC clamp (transient suppression diode) for input/output channels - Power Supply Protection: Reverse polarity diode + 500mA slow-blow fuse (main power input)	Current limiting prevents damage from shorted output wires (e.g., frayed indicator light cables); transient suppression diodes withstand voltage spikes from faulty 24V DC power supplies; main power fuse protects the unit from catastrophic damage
  Compliance Standards: CE, UL 508, CSA C22.2 No.14, IEC 61131-2 (industrial control), IEC 61000-6-2 (EMC), RoHS 2.0, ISO 9001

2. Core Features

• Ultra-Miniature 8-Channel Mixed I/O (6 In + 2 Out): Consolidates 8 digital signals into a 60×40×12mm unit—saves 80% cabinet space vs. discrete terminal blocks; ideal for ultra-dense automation systems (e.g., 3-sensor + 1-actuator test fixtures) or tiny enclosures (e.g., wall-mounted building automation sub-panels).
• Ultra-Low-Power Output Capacity (200mA/Channel): Handles ultra-low-power industrial devices (e.g., 24V DC micro-relays, 50mA LED indicators, 150mA micro-solenoids)—eliminates the need for external relays, reducing wiring complexity and component count for minimal-control tasks.
• Basic Fault Protection: Overcurrent fuses + ESD/reverse polarity/overvoltage safeguards—covers common digital wiring faults in small systems (shorted sensors, incorrect polarity, electrostatic discharge); front-access fuses enable quick replacements without removing the unit from the enclosure.
• Dual Compact Mounting Options: DIN rail (via mini adapter) or direct panel mount—adapts to diverse space-constrained layouts (e.g., stacked DIN rail units in 1U cabinets, direct-mounted in tiny control boxes); installs in <2 minutes with minimal tools.
• Industrial-Grade Miniature Durability: UL 94 V0 flame-retardant board + ultra-thin conformal coating—withstands general industrial conditions (dust, non-corrosive moisture) in confined spaces; -20℃~+60℃ operating range suits most indoor industrial and commercial environments, avoiding performance issues in temperature-fluctuating areas.
• Seamless AC500 Integration: Optimized for ABB AC500 digital I/O modules (e.g., DSMB178 32-channel digital I/O)—connects via standard 24AWG~20AWG wires; no configuration or calibration needed; terminal labels align with AC500 I/O numbering, ensuring plug-and-play deployment in small AC500-based systems.
• Cost-Effective Tiny-Scale Wiring: Delivers essential I/O consolidation at a lower cost than compact connection units (e.g., DSTV110)—ideal for budget-conscious projects (e.g., startup workshop test benches, residential building automation) that require minimal I/O capacity.

3. Application Fields

• Light Manufacturing: Miniature Automation Setups:
  • Electronics Bench-Top Test Fixtures: Connects sensors/actuators for PCB testing—6 input channels handle 4 photoelectric sensors (PCB edge detection) + 2 limit switches (fixture closure); 2 output channels control 1 test relay + 1 LED indicator; ultra-small design fits in handheld or bench-mounted test enclosures, reducing workspace clutter.
  • Small Toy/Component Assembly Lines: Centralizes wiring for manual assembly stations—6 input channels handle 3 proximity sensors (part presence) + 3 light sensors (ambient brightness); 2 output channels control 1 small conveyor relay + 1 warning LED; noise filtering prevents false triggers from nearby small motors.
• Process Control: Auxiliary Micro-Monitoring:
  • Chemical Plant Sample Analysis Stations: Connects sensors for manual sampling—6 input channels handle 4 temperature switches (sample bath) + 2 level switches (sample vials); 2 output channels control 1 pump relay + 1 status LED; reverse polarity protection prevents damage from incorrect sensor wiring (common during frequent sample changes).
  • Water Treatment Lab Testing Rigs: Manages wiring for small-scale filtration tests—6 input channels handle 3 flow switches (test flow) + 3 pressure switches (filter resistance); 2 output channels control 1 valve relay + 1 data logger trigger; non-condensing humidity tolerance suits lab environments with variable moisture.
• Building Automation: Tiny-Scale Zone Controls:
  • Residential/Small Office HVAC: Connects sensors for room-level control—6 input channels handle 4 occupancy sensors + 2 temperature switches (room comfort); 2 output channels control 1 damper relay + 1 fan relay; direct panel mount fits in electrical junction boxes, avoiding the need for dedicated control cabinets.
  • Retail Display Case Monitoring: Manages wiring for small refrigerated displays—6 input channels handle 3 temperature switches (case interior) + 3 door contact switches (display access); 2 output channels control 1 alarm LED + 1 small heater relay; compact design fits in display case electrical compartments.
• Utility Substations: Secondary Micro-Sensors:
  • Small Power Distribution Box Monitoring: Connects status sensors for auxiliary power—6 input channels handle 4 breaker position switches + 2 voltage switches (output level); 2 output channels control 1 indicator LED + 1 communication relay; -20℃~+60℃ range suits indoor distribution rooms; vibration resistance prevents signal dropout from minor cabinet movement.
  • Solar PV Micro-Inverter (1kW~5kW) Auxiliaries: Connects sensors for inverter monitoring—6 input channels handle 3 current switches (PV string) + 3 temperature switches (inverter heatsink); 2 output channels control 1 cooling fan relay + 1 status LED; EMC immunity resists interference from inverter switching, ensuring stable signal transmission.
