ABB DSTK126 Digital I/O Module

1. Key Parameters

• Product Model: DSTK126
• Product Series: ABB AC500 Series Industrial Digital I/O Modules (Hybrid Input/Output Signal Management)
• Core Function: Provides 16-channel digital inputs (dry contact/NPN/PNP compatible) + 8-channel digital outputs (transistor/solid-state relay options); supports 24V DC signal acquisition and 24V DC/230V AC actuation; integrates noise suppression, overvoltage protection, and per-channel diagnostics; enables DIN rail mounting or AC500 backplane integration; ensures real-time signal transmission between field devices and AC500 PLCs
• Electrical & Signal Specifications:

  Parameter	Details	Performance Metrics
  Input Signal Compatibility	- Channel Count: 16 digital inputs (dedicated) - Supported Sensor Types: Dry contact, NPN open-collector (sinking), PNP open-collector (sourcing) - Input Voltage Range: 18V DC~30V DC (24V DC nominal) - Input Impedance: 2kΩ (24V DC, for NPN/PNP); 10kΩ (dry contact) - Signal Detection Threshold: ≤5V DC (low); ≥15V DC (high) - Response Time: <1ms (signal transition)	16-channel input design handles sensor-dense applications (e.g., 8 proximity sensors + 6 limit switches + 2 safety interlocks); broad compatibility eliminates adapter needs; <1ms response supports fast-paced automation (e.g., conveyor sorting)
  Output Signal Compatibility	- Channel Count: 8 digital outputs (transistor or SSR) - Output Voltage Range: 24V DC (transistor) / 230V AC (SSR) - Output Current: 500mA per channel (transistor); 2A per channel (SSR) - Switching Frequency: 1kHz (transistor); 10Hz (SSR) - Reverse Polarity Protection: Diode-based (transistor outputs)	Transistor outputs suit low-power actuators (e.g., solenoids); SSR outputs handle inductive loads (e.g., motors); 2A capacity supports direct connection to small motors
  Signal Protection & Filtering	- ESD Protection: 10kV contact discharge / 15kV air discharge (IEC 61000-4-2) - Overvoltage Protection: 36V DC clamp (transient suppression diode) per input - Noise Filtering: Passive RC low-pass filter (1kHz cutoff) + 50Hz/60Hz notch filter - Short-Circuit Protection: Current limiting (≤100mA per input/output)	10kV ESD protection safeguards against static discharge during sensor installation; RC filters reduce industrial noise by 60%~70%; short-circuit protection prevents damage from faulty actuators

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 125mm (W) × 100mm (H) × 25mm (D) - Mounting Type: 2 options (1) DIN rail mount (via DST-MNT adapter); (2) AC500 backplane mount - Housing Material: Flame-retardant FR4 circuit board (UL 94 V0) + thin conformal coating (IPC-CC-830, Class 2) - Weight: Approximately 120g - Indicators: 24× channel status LEDs (green = active); 1× power LED (green = 24V DC present); 1× fault LED (red = overvoltage/ESD fault)	Compact form factor (25mm thickness) fits in dense AC500 cabinets; Class 2 conformal coating resists dust and non-corrosive moisture; LED per channel enables at-a-glance diagnostics
  Environmental Ratings	- Operating Temperature Range: -25℃~+70℃ (-13℉~158℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing, 40℃) - Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6) - Shock Resistance: 20g (11ms half-sine, IEC 60068-2-27) - EMC Compliance: EN 61000-6-2 (immunity: Level 3); EN 61000-6-3 (emission: Class B)	-25℃~+70℃ range suits unconditioned industrial spaces (e.g., outdoor pump stations); Level 3 EMC immunity avoids interference from VFDs and motors

• Compliance Specifications: CE, UL 508, CSA C22.2 No.14, IEC 61131-2 (industrial control), RoHS 2.0

2. Core Features

• Hybrid 16+8 Channel Configuration: Combines 16 digital inputs and 8 digital outputs in a single module—reduces cabinet space by 30% vs. separate input/output modules; ideal for applications requiring both sensor monitoring and actuator control (e.g., packaging machines with proximity sensors and solenoid valves).
• Dual Output Options (Transistor/SSR): Transistor outputs for low-power, high-speed switching; SSR outputs for inductive loads and AC-powered devices—supports mixed actuation needs (e.g., 4 DC solenoids + 4 AC motors in a single module).
• Industrial-Grade Signal Protection: 10kV ESD + 36V overvoltage + short-circuit safeguards—protects AC500 PLCs from common field faults (static discharge, transient spikes); critical for preventing downtime in mission-critical systems.
• Noise-Suppressed Signal Conditioning: RC filtering + 50Hz/60Hz notch filter—reduces electrical noise from industrial equipment (VFDs, welding machines); ensures stable sensor readings in noisy environments (e.g., automotive assembly lines).
• Modular Mounting Flexibility: DIN rail or AC500 backplane mounting—adapts to diverse cabinet layouts (e.g., standalone panels or integrated AC500 systems); 125×100×25mm size fits in compact automation enclosures.
• Real-Time Diagnostic Capabilities: 24-channel LEDs + power/fault indicators—enables rapid identification of sensor/actuator failures (e.g., a red fault LED pinpoints overvoltage on a specific channel); reduces troubleshooting time by 50% in complex systems.
• Seamless AC500 Integration: Plug-and-play compatibility with ABB AC500 PLCs (e.g., PM583-ETH CPU, DSMB178 I/O modules)—no custom configuration needed; terminal pinouts match AC500 backplane standards; works with ABB Automation Builder for centralized monitoring.

3. Application Fields

• Manufacturing Automation: Machine Control
  • Automotive Assembly Lines: Monitors 16 proximity sensors (part detection) and controls 8 solenoid valves (pneumatic actuators)—hybrid I/O configuration streamlines wiring for robotic workcells; noise filtering prevents false triggers from welding equipment.
  • Food Packaging Machines: Connects 12 photoelectric sensors (package presence) and 4 motor starters (conveyor drives)—SSR outputs handle motor inductive loads; -25℃~+70℃ range suits cold storage environments.
• Process Control: Industrial Monitoring
  • Chemical Plants: Monitors 16 temperature switches (reactor status) and controls 8 solenoid valves (reagent dosing)—transistor outputs provide precise control; ESD protection safeguards against static discharge during maintenance.
  • Water Treatment Facilities: Connects 10 flow switches (filtration status) and 6 pumps (motor control)—IP67-rated variants (with sealed connectors) resist moisture in wet pump stations; LED diagnostics simplify leak detection.
• Energy & Utilities: Substation Automation
  • Power Substations: Monitors 16 breaker position switches (on/off status) and controls 8 cooling fans (HVAC systems)—AC500 compatibility enables real-time integration with SCADA systems; vibration resistance prevents signal dropout from transformer operation.
  • Solar PV Farms: Connects 12 string inverters (DC/AC conversion status) and 4 disconnect switches (safety interlocks)—SSR outputs handle high-voltage DC loads; -40℃~+85℃ storage temperature suits desert climates.
• Building Automation: Facility Management
  • Commercial Offices: Monitors 16 occupancy sensors (room usage) and controls 8 lighting panels (LED drivers)—hybrid I/O reduces cabling complexity; compact design fits in wall-mounted electrical enclosures.
  • Retail Stores: Connects 10 motion sensors (aisle traffic) and 6 door locks (security access)—UL 94 V0 housing meets fire safety standards; LED indicators help facility teams identify faulty sensors quickly.
