ABB DSTC130 Circuit Board

1. Key Parameters

• Product Model: DSTC130
• Product Series: ABB AC500 Series Industrial Analog Circuit Boards (Signal Conditioning & I/O Expansion)
• Core Function: Provides 4-channel analog I/O (2 input + 2 output, configurable); supports low-level signal processing (thermocouple: J/K/T type, RTD: Pt100/Pt1000, 4-20mA/0-10V); integrates signal linearization, cold-junction compensation (CJC) for thermocouples; enables low-density analog I/O expansion for AC500 micro PLCs (e.g., DSPC110); supports DIN rail mounting via adapter or backplane integration; ensures high-precision signal transmission between industrial sensors and AC500 PLCs
• Electrical & Signal Specifications:

  Parameter	Details	Performance Metrics
  Signal Compatibility	- I/O Configuration: 4 channels (2 analog input + 2 analog output, software-configurable) - Supported Input Signals: Thermocouple (J/K/T type), RTD (Pt100/Pt1000, 2/3/4-wire), 4-20mA current loop, 0-10V voltage - Supported Output Signals: 4-20mA, 0-5V/0-10V - Input Resolution: 16-bit (for 4-20mA/0-10V); 18-bit (for thermocouple/RTD) - Linearization Error: ±0.05% (full-scale range, 25℃) - Cold-Junction Compensation (CJC): ±0.5℃ (for thermocouples, -20℃~+65℃)	4-channel analog I/O expands AC500 micro PLCs’ native analog capacity (e.g., DSPC110 with 2 analog inputs → 4 total inputs); 18-bit resolution for thermocouple/RTD ensures precision temperature measurement (±0.1℃ for Pt100), critical for process control (e.g., pharmaceutical batch heating)
  Signal Conditioning	- Noise Filtering: Active 2nd-order low-pass filter (cutoff: 0.1Hz/1Hz/10Hz, configurable) + 50Hz/60Hz notch filter - Common-Mode Rejection Ratio (CMRR): ≥85dB (50Hz/60Hz) - Signal Drift: ≤0.01% full-scale per year - Input Impedance: 10MΩ (voltage signals); 25Ω (4-20mA); 100Ω (RTD)	Active filtering reduces high-frequency noise from industrial sources (VFDs, motors) by 85%~95%; CJC compensates for thermocouple cold-junction errors, ensuring accurate temperature readings in variable environments; low signal drift maintains long-term measurement stability (e.g., substation temperature monitoring)

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 70mm (W) × 50mm (H) × 18mm (D) - Mounting Type: 2 options (1) DIN rail mount (via optional DSTC-MNT2 adapter); (2) Backplane mount (compatible with AC500 micro PLC racks) - Housing Material: Flame-retardant FR4 circuit board (UL 94 V0) + thick conformal coating (IPC-CC-830, Class 3) - Weight: Approximately 45g - Indicators: 4× channel LEDs (green = normal; red = fault); 1× power LED (green = 24V DC present); 1× CJC status LED (blue = CJC active)	Ultra-compact form factor fits in dense AC500 cabinets or small control boxes; Class 3 conformal coating resists harsh industrial contaminants (oil, dust, moisture); multi-color LEDs enable quick diagnostics (e.g., blue LED confirms CJC function for thermocouples)
  Environmental Ratings	- Operating Temperature Range: -25℃~+70℃ (-13℉~158℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing/condensing, up to 50℃) - Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6) - Shock Resistance: 20g (11ms half-sine, IEC 60068-2-27)	-25℃~+70℃ range suits extreme industrial environments (arctic substations, desert solar farms); condensing humidity tolerance eliminates dehumidifiers in damp areas (e.g., water treatment plants); vibration resistance prevents solder joint loosening in high-motion systems

• Protection & Compliance Specifications:

  Parameter	Details	Performance Metrics
  Protection Features	- Overcurrent Protection: 4× 30mA self-resetting PTC fuses (input channels) - Overvoltage Protection: 30V DC (input channels); 15V DC (output channels) (crowbar circuit) - ESD Protection: 8kV contact discharge / 15kV air discharge (IEC 61000-4-2) - Reverse Polarity Protection: Diode-based (power input and signal channels, ≤24V DC)	30mA PTC fuses protect low-level sensor signals (e.g., RTD) from overcurrent damage; overvoltage protection prevents harm from accidental 24V DC wiring to 0-10V channels; ESD protection safeguards against static discharge during sensor installation
  Compliance Standards: CE, UL 508, CSA C22.2 No.14, IEC 61131-2 (industrial control), IEC 61000-6-2 (EMC), RoHS 2.0, ISO 9001

2. Core Features

• 4-Channel Analog I/O Expansion (2 In + 2 Out): Adds low-density analog I/O to AC500 micro PLCs (e.g., DSPC110 with 2 native analog inputs → 4 total inputs)—eliminates the need for high-cost full-size analog modules (e.g., DSMB340) for small-scale measurement tasks, cutting hardware costs by 70% for applications like 2-temperature + 1-pressure monitoring.
• Multi-Sensor Signal Compatibility: Supports thermocouple (J/K/T), RTD (Pt100/Pt1000), 4-20mA, and 0-10V signals—adapts to diverse industrial sensors without separate signal converters; ideal for mixed-analog systems (e.g., temperature + pressure monitoring in chemical auxiliary tanks).
• High-Precision Signal Processing: 18-bit resolution for thermocouple/RTD + ±0.05% linearization error—delivers laboratory-grade measurement accuracy (±0.1℃ for Pt100) in industrial environments; cold-junction compensation (CJC) ensures thermocouple readings remain accurate even as ambient temperature varies (e.g., substation cabinets in summer/winter).
• Advanced Noise Suppression: Active 2nd-order filtering + 50Hz/60Hz notch filter—suppresses electrical noise from industrial sources (VFDs, high-voltage switchgear) and line-frequency interference; CMRR ≥85dB ensures clean signal transmission, avoiding measurement drift in low-level signals (e.g., 1mV thermocouple outputs).
• Dual Mounting & Industrial Durability: Supports DIN rail (via adapter) or backplane mount—fits diverse cabinet layouts; Class 3 conformal coating + -25℃~+70℃ operating range—withstands harsh conditions (moisture, dust, temperature extremes) that degrade standard circuit boards; 20g shock resistance survives maintenance impacts.
• Self-Healing Protection: 30mA PTC fuses + overvoltage/reverse polarity safeguards—covers common analog faults (shorted RTD wires, incorrect voltage, reversed power); self-resetting fuses reduce downtime, critical for 24/7 processes (e.g., food refrigeration temperature monitoring).
• Seamless AC500 Integration: Plug-and-play compatibility with AC500 micro PLCs—no custom calibration needed; pre-wired pinouts match AC500 backplane standards; works with ABB Automation Builder for signal configuration (e.g., sensor type selection, filter settings) and fault monitoring.

3. Application Fields

• Process Control: Temperature/Pressure Monitoring:
  • Pharmaceutical Batch Plants: Conditions thermocouple signals for reactor temperature control—2 input channels handle 2 K-type thermocouples (reactor wall + internal mixture); CJC compensates for ambient temperature changes, ensuring ±0.1℃ measurement accuracy (critical for FDA-compliant batch processes); 2 output channels send 4-20mA signals to AC500 PLCs for closed-loop heating control.
  • Food Processing Lines: Expands analog I/O for refrigeration monitoring—2 input channels handle 2 Pt100 RTDs (cold storage + conveyor belt); 2 output channels send 0-10V signals to cooling valve actuators; conformal coating resists moisture in cold storage environments, preventing signal drift.
• Energy & Utilities: Substation Environmental Controls:
  • EHV Substations (500kV+): Processes RTD signals for transformer cooling—2 input channels handle 2 Pt1000 RTDs (transformer oil + winding temperature); 2 output channels send 4-20mA signals to AC500 PLCs for fan control; -25℃~+70℃ range suits outdoor substation cabinets; noise filtering resists interference from high-voltage switchgear.
  • Solar PV Plants (100MW+): Conditions 4-20mA signals for inverter temperature monitoring—2 input channels handle 2 current sensors (inverter heatsink + DC bus); 2 output channels send 0-10V signals to cooling fan relays; compact design fits in inverter control boxes; low drift ensures long-term measurement stability.
• Manufacturing Automation: Precision Sensing:
  • Electronics SMT Factories: Processes RTD signals for reflow oven temperature—2 input channels handle 2 Pt100 RTDs (oven zone 1 + zone 2); 2 output channels send 4-20mA signals to AC500 PLCs for heater control; 18-bit resolution ensures ±0.1℃ accuracy, avoiding soldering defects (e.g., cold joints).
  • Automotive Component Testing: Conditions pressure sensor signals for gearbox testing—2 input channels handle 2 4-20mA pressure sensors (gearbox oil + hydraulic system); 2 output channels send 0-5V signals to test stand displays; noise filtering eliminates interference from test stand motors, ensuring reliable pressure readings.
• Building Automation: HVAC Zone Control:
  • Commercial Office Buildings: Expands analog I/O for multi-zone HVAC—2 input channels handle 2 0-10V temperature sensors (conference room + lobby); 2 output channels send 4-20mA signals to damper actuators; compact design fits in wall-mounted electrical panels; cost-effectiveness makes it ideal for retrofitting legacy HVAC systems.

The structure and details of the product：
