ABB DSTA170 Termination Unit

1. Key Parameters

• Product Model: DSTA170
• Product Series: ABB AC500 Series Industrial High-Density Termination Units (Large-Scale Wiring Management)
• Core Function: Provides 32-channel terminal blocks for field sensor/actuator wiring termination (16 input + 16 output channels, configurable); integrates passive signal filtering for digital/analog signals; offers per-channel overcurrent protection (replaceable fuses); enables batch wiring diagnostics; supports DIN rail mounting for industrial cabinet integration; ensures stable signal transmission between high-volume field devices and AC500 I/O modules
• Terminal & Wiring Specifications:

  Parameter	Details	Performance Metrics
  Terminal Configuration	- Channel Count: 32 independent terminals (16 input + 16 output, configurable via jumper for mixed I/O) - Terminal Type: Push-in spring terminals (accepts 26AWG~14AWG copper wires, max 2.5mm²) - Wiring Capacity: 2 wires per terminal (parallel connections for shared power/signal) - Terminal Torque: Tool-less (push-in design, no screwdriver required) - Marking: Color-coded input/output channels (blue = input, red = output) + pre-printed labels (CH1~CH32) + blank customizable labels	32-channel high-density design consolidates wiring for large I/O clusters (e.g., 20 photoelectric sensors + 12 solenoid valves); push-in terminals reduce wiring time by 50% vs. screw-clamp types (critical for high-volume installations); color coding and labeling minimize cross-wiring errors (a leading cause of large-scale automation downtime)
  Signal Protection & Filtering	- Overcurrent Protection: 32× 500mA slow-blow fuses (replaceable, per channel, accessible via front panel) - Signal Filtering: Passive RC filters (2kHz cutoff for analog channels; 50Hz/60Hz line noise suppression for digital channels) - ESD Protection: 8kV contact discharge (IEC 61000-4-2) per channel - Reverse Polarity Protection: Diode-based (for DC input/output channels, ≤24V DC)	500mA fuses protect AC500 high-density I/O modules (e.g., DSMB178 32-channel digital I/O) from shorted field wires; passive filtering reduces noise from industrial sources (VFDs, motor drives) by 40%~60%; ESD protection safeguards against electrostatic discharge during high-volume wiring maintenance

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 160mm (W) × 100mm (H) × 65mm (D) - Mounting Type: DIN rail mount (EN 50022, 35mm, tool-less snap-on) - Housing Material: Flame-retardant thermoplastic (UL 94 V0) with reinforced side panels - Weight: Approximately 550g - Indicators: 32× channel status LEDs (green = normal signal; red = overcurrent/fuse blown); 1× global power LED (green = unit powered); 1× fault summary LED (yellow = 1+ channel fault)	High-density design saves 60% cabinet space vs. discrete terminal blocks (critical for large automation cabinets with 100+ I/O points); reinforced housing resists accidental impacts during high-volume wiring; summary LED enables quick identification of any faulty channel (no need to scan all 32 LEDs)
  Environmental Ratings	- Operating Temperature Range: -25℃~+70℃ (-13℉~158℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing, 40℃) - Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6) - Shock Resistance: 20g (11ms half-sine, IEC 60068-2-27) - EMC Compliance: EN 61000-6-2 (immunity: Level 3); EN 61000-6-3 (emission: Class B)	-25℃~+70℃ range suits unconditioned industrial spaces (e.g., factory floors, outdoor substation cabinets); vibration resistance prevents terminal loosening in high-motion environments (e.g., near heavy machinery); Level 3 EMC immunity withstands noise from large industrial equipment

• Compliance Specifications:

  Parameter	Details	Performance Metrics
  Safety & Compliance	- Safety Standards: CE, UL 508, CSA C22.2 No.14, IEC 61131-2 (industrial control) - Flame Retardancy: Housing (UL 94 V0); internal wiring (UL 1015, 105℃) - RoHS Compliance: EU RoHS 2.0 (Restriction of Hazardous Substances) - EMC Standards: IEC 61000-6-2 (immunity), IEC 61000-6-3 (emission)	UL 508/CSA certification ensures compliance with North American industrial safety requirements; flame-retardant design reduces fire risk in dense cabinet configurations (critical for large automation setups with multiple power devices); RoHS compliance meets global environmental regulations

2. Core Features

• 32-Channel High-Density Design: Consolidates 32 field wires (16 input + 16 output, configurable) into a single unit—reduces cabinet space usage by 60% vs. discrete terminal blocks, critical for large automation systems (e.g., 200+ I/O points in automotive plants); configurable I/O via jumpers adapts to dynamic wiring needs (e.g., 20 inputs + 12 outputs for mixed sensor/actuator clusters).
• Tool-Less Push-In Terminals: Push-in spring terminal design (26AWG~14AWG) eliminates screwdrivers—cuts wiring time by 50% for high-volume installations (e.g., 32 channels wired in <10 minutes vs. 20+ minutes for screw-clamp types); dual-wire capacity per terminal simplifies parallel connections (e.g., shared 24V DC power for 10+ sensors), reducing wire count and clutter.
• Per-Channel Protection & Noise Suppression: 500mA fuses + ESD/reverse polarity protection + passive filtering—covers all common wiring faults in large systems (shorted sensors, incorrect polarity, electrostatic discharge); passive RC filters reduce noise from industrial sources (VFDs, welding machines), ensuring stable signal transmission for both digital (limit switches) and low-precision analog (temperature transducers) devices.
• Efficient Fault Diagnostics: 32 individual LEDs + global fault summary LED—technicians can quickly locate faulty channels (red LED = blown fuse/overcurrent) and confirm system health via the summary LED (yellow = 1+ fault); no need to disconnect wiring or use multimeters, reducing troubleshooting time from hours to minutes in large I/O clusters.
• Industrial-Grade Durability: UL 94 V0 flame-retardant housing + -25℃~+70℃ operating range—withstands harsh industrial conditions (dust, moisture, temperature fluctuations) that damage low-grade termination blocks; 20g shock resistance survives accidental impacts during cabinet maintenance (common in high-volume wiring areas), extending service life to 8+ years.
• Scalable Integration: Supports parallel mounting of multiple units on a single DIN rail—enables seamless scaling for ultra-large I/O systems (e.g., 5 units = 160 channels); consistent labeling and color coding across units simplify cross-channel wiring (e.g., CH1~CH32 Unit 1, CH33~CH64 Unit 2), reducing setup complexity for system integrators.
• Seamless AC500 Compatibility: Designed for direct integration with AC500 high-density I/O modules (e.g., DSMB178 32-channel digital I/O, DSRF182 remote I/O frames)—connects directly between field devices and PLC modules via standard wiring; no configuration or calibration needed, ensuring plug-and-play deployment in large AC500 automation networks.

3. Application Fields

• Heavy Manufacturing: Large-Scale I/O Wiring:
  • Automotive Mega-Plants: Terminates wiring for robotic assembly lines—32 channels handle 20 photoelectric sensors (part presence) + 12 solenoid valves (robotic grippers); push-in terminals speed up line commissioning (critical for multi-line plants); fuses protect AC500 DSMB178 modules from shorted gripper wires, reducing line downtime.
  • Heavy Machinery Factories: Centralizes wiring for CNC machine auxiliaries—32 channels terminate 16 limit switches (machine travel limits) + 16 relay outputs (coolant pumps, spindle locks); passive filters reduce noise from CNC motor drives, avoiding false triggers of limit switches (which cause costly machine stops).
• Process Control: Complex Plant Wiring:
  • Chemical Complexes: Consolidates wiring for reactor auxiliary systems—32 channels handle 18 pressure switches (pipework) + 14 valve actuators (chemical flow); color-coded inputs/outputs simplify cross-reactor wiring (e.g., blue = sensor signals, red = actuator controls); ESD protection safeguards against static discharge during maintenance (common in chemical handling areas).
  • Oil Refineries: Terminates wiring for pipeline monitoring stations—32 channels handle 24 flow sensors (pipeline segments) + 8 valve actuators (flow control); -25℃~+70℃ range suits outdoor substation cabinets; summary LED enables remote fault checking via cabinet cameras, reducing site visits to remote pipeline locations.
• Energy & Utilities: Substation/Renewable Wiring:
  • EHV Substations (765kV+): Centralizes wiring for substation auxiliary equipment—32 channels handle 16 temperature sensors (transformer cooling) + 16 relay outputs (fan/pump controls); high-density design fits in space-constrained substation cabinets; vibration resistance prevents terminal loosening from transformer operation.
  • Solar PV Plants (2GW+): Terminates wiring for inverter cluster auxiliaries—32 channels handle 20 current sensors (PV string output) + 12 relay outputs (inverter cooling fans); push-in terminals speed up plant commissioning (critical for large-scale solar farms); passive filters reduce noise from inverters, ensuring stable sensor readings for power yield monitoring.
• Building Automation: Large Commercial/Industrial Facilities:
  • Airports/Stadiums: Consolidates wiring for HVAC and lighting controls—32 channels handle 18 temperature/humidity sensors (zones) + 14 damper/light actuators; high-density design fits in central electrical rooms (no need for multiple small termination panels); summary LED simplifies fault diagnosis for facility teams (no specialized automation expertise needed).
  • Data Centers: Terminates wiring for server room environmental controls—32 channels handle 24 temperature sensors (server racks) + 8 relay outputs (CRAC units); UL 94 V0 housing meets data center fire safety standards; reverse polarity protection prevents damage from incorrect sensor wiring (common during rack expansions).
