ABB DSQC540 3HAC14279-1/03 Computer Control Panel

ABB DSQC540 3HAC14279-1/03 Computer Control Panel Product Data

Product Overview:

The ABB DSQC540 3HAC14279-1/03 is a computer control panel used in ABB robotic control systems, such as the IRC5 series. It is designed for operation, monitoring, and maintenance of robotic systems, providing an intuitive graphical interface for operators to control and manage various robot functions. The control panel features a high-resolution display, touch-screen operation, powerful processing capability, and supports multiple input/output interfaces, offering an efficient solution for robotic control in industrial automation.

Key Technical Specifications:

• Display Type: 17-inch LCD touchscreen

• Resolution: 1280 × 1024 pixels

• Color Display: 16.7 million colors

• Operating System: Windows Embedded Standard OS

• Processor: Intel Pentium Processor (specific model may vary depending on version)

• Memory: 2 GB RAM

• Storage: 120 GB SSD (Solid State Drive, fast boot and data access)

• Communication Interfaces:

  • 2 x Ethernet Ports (10/100/1000 Mbps)

  • 1 x USB 2.0 Port

  • 1 x VGA Port

  • 1 x RS232 Port

  • 1 x RS485 Port

• Power Requirements: 24V DC input power, max power consumption 150W

• Installation Type: Panel-mountable, suitable for control stations or operator panels

• Operating Temperature Range: 0°C to 45°C

• Storage Temperature Range: -20°C to 70°C

• Protection Class: IP20 (suitable for indoor use)

• Dimensions: Approx. 405mm (W) x 335mm (H) x 75mm (D)

• Weight: Approx. 5.5 kg

Product Advantages and Features:

1. High-Resolution Display: The 17-inch high-resolution LCD screen provides clear and detailed graphical display, ensuring operators can view real-time robot status, operational parameters, and key information.

2. Touchscreen Operation: The high-sensitivity touchscreen allows operators to directly interact with the display, enhancing operational convenience and efficiency, and reducing reliance on traditional buttons.

3. Powerful Processing: Equipped with an Intel Pentium processor and large memory, the panel ensures high performance, handling complex data and tasks efficiently to meet high-performance requirements.

4. Efficient Storage: The built-in 120 GB SSD provides fast data reading and writing speeds, enabling quick system boot-up and responsive operation, reducing downtime.

5. Multiple Communication Interfaces: The panel offers various interfaces (Ethernet, USB, VGA, RS232, RS485) for connection to other control devices, external computers, or networks, ensuring broad compatibility and system integration.

6. Compact and Durable: Designed with a sturdy outer casing and high-quality components, the panel ensures reliable long-term operation in industrial environments. The IP20 protection rating makes it suitable for most indoor environments.

7. Multitasking: Supports multitasking operations, allowing multiple control programs and monitoring windows to run simultaneously, providing comprehensive real-time data and operational control.

8. Remote Access and Diagnostics: Supports remote connection via Ethernet, facilitating remote diagnostics, monitoring, and troubleshooting, improving maintenance convenience.

9. User-Friendly Interface: The graphical user interface provides an intuitive and easy-to-navigate environment for operators, ensuring quick understanding of the robot system's operational status and parameters.

Application Areas:

1. Robotic Control Systems: Used as the primary interface for operating and monitoring ABB robotic control systems (e.g., IRC5 controllers), facilitating real-time display and control of robotic operations.

2. Automated Production Lines: Employed in automated production lines to control and manage robot tasks such as welding, assembly, handling, and packaging, enhancing production efficiency and precision.

3. Welding and Coating Industries: Used in automated welding and painting applications, providing efficient and flexible operation in dynamic production environments.

4. Intelligent Warehousing and Logistics Systems: Powers robotic control in automated warehouse and logistics systems, offering real-time operation and monitoring, optimizing inventory and logistics management.

5. Manufacturing Robotics Integration: Used in manufacturing environments where robots interact with other automated equipment, providing centralized control and monitoring for efficient production line operation.

6. Testing and Experimental Environments: Provides advanced data monitoring and real-time control for research and experimental processes requiring precise operations.

7. Food and Pharmaceutical Industries: Used in food processing and pharmaceutical production lines, ensuring precision and consistency in manufacturing processes.

Precautions:

1. Power Stability: Ensure a stable 24V DC power input to avoid malfunctions. It's recommended to use an uninterruptible power supply (UPS) to prevent disruptions caused by power outages.

2. Environmental Temperature: Ensure the device operates within the temperature range of 0°C to 45°C to avoid performance issues in extreme temperatures.

3. Cooling Requirements: While the panel is designed for efficient heat dissipation, ensure proper ventilation around the unit to prevent overheating.

4. Protection Measures: The panel has an IP20 protection rating, suitable for indoor use. Additional protective measures are needed in environments with humidity, corrosive gases, or harsh conditions.

5. Regular Maintenance: Periodically inspect the touchscreen, display, and communication interfaces to ensure proper functioning and clean the screen to prevent dust buildup that may affect visibility.

6. Wiring and Installation: Ensure all connections are secure and follow grounding guidelines to prevent electrical faults.

7. Software Updates: Regularly update the operating system and control software to ensure compatibility and system performance.
