ABB DSQC539 3HAC14265-1 power supply module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB DSQC539 3HAC14265-1 Power Supply Module Product Data

Product Overview:

The ABB DSQC539 3HAC14265-1 Power Supply Module is an essential component in ABB robotic control systems such as the IRC5 controller. This power supply module provides stable power to the robotic control system, ensuring proper operation of all system components. With efficient power conversion, overload protection, overvoltage protection, and other safety features, the DSQC539 power supply module guarantees the reliability and stability of the robotic system under various working conditions.

Key Technical Specifications:

• Input Voltage Range: 3-phase 380V – 480V AC, 50/60Hz

• Output Voltage: 24V DC (standard output voltage)

• Output Current: Max 20A (depending on load requirements)

• Rated Power: Max 480W

• Protection Functions: Overvoltage protection, overcurrent protection, short-circuit protection, overheat protection

• Operating Temperature: -10°C to +50°C

• Storage Temperature: -20°C to +70°C

• Installation Type: Rack-mountable, suitable for control systems in various industrial environments

• Protection Class: IP20 (suitable for indoor use)

• Dimensions: Standard module size for easy installation in control cabinets or racks

• Weight: Approximately 1.5 kg

• Communication Interface: Compatible with ABB robot control systems (e.g., IRC5), supporting digital signal communication

Product Advantages and Features:

1. High Reliability: The DSQC539 power supply module offers efficient power management, providing stable DC power and ensuring the high-performance operation of ABB robotic control systems.

2. Safety Protection Functions: Equipped with multiple protection mechanisms (such as overload, overvoltage, overcurrent, short-circuit protection), preventing system damage due to power failures, and ensuring long-term system stability and safety.

3. Wide Voltage Range: Supports a wide input voltage range of 380V to 480V, adaptable to different power standards worldwide, reducing downtime risks caused by unstable power supply.

4. Compact Design: The modular design ensures easy installation and space efficiency, making it ideal for various industrial automation environments.

5. High Efficiency: The power supply module has high power conversion efficiency, minimizing energy loss and improving the overall system performance.

6. Environmental Adaptability: Designed to withstand a wide operating temperature range from -10°C to +50°C, ensuring stable performance in most industrial environments.

7. High Power Density: Provides up to 480W output power, meeting the high power demands of ABB robotic control systems and supporting high-load operation.

8. Strong Compatibility: Fully compatible with ABB's IRC5 robotic controller, ensuring seamless integration and stable operation.

9. Long Life and Low Maintenance Cost: Due to the use of high-quality components and reliable design, the DSQC539 power supply module offers a long service life, reducing maintenance frequency and lowering overall maintenance costs.

Application Areas:

1. Robotic Control Systems: As a key power supply module for ABB robotic control systems (e.g., IRC5 controller), it is widely used in industrial robotic automation lines, providing stable power support.

2. Automated Production Lines: Used to power robots and other automation equipment, ensuring efficient operation, particularly in precision manufacturing, welding, handling, and assembly.

3. Welding and Assembly Industry: Provides essential power support in industries requiring precise control and continuous operation, such as welding, assembly, and painting.

4. Machining Industry: Powers automated control systems for equipment such as CNC machines, laser cutting, and laser marking, ensuring efficient and accurate operations.

5. Material Handling and Transport Systems: Powers automated logistics systems, automated forklifts, and other material handling equipment, ensuring smooth and efficient operation.

6. Other Industrial Automation Applications: Used in systems such as warehouse management and automated assembly lines, providing reliable power support for stable system operation.

Precautions:

1. Input Voltage Matching: Ensure the input voltage is within the 380V to 480V range to avoid damage from overvoltage or undervoltage.

2. Cooling Requirements: The module generates heat during operation. Ensure sufficient ventilation around the module to prevent overheating. Avoid installing the module in high-temperature environments.

3. Power Wiring: Follow electrical installation standards and ensure secure wiring to avoid malfunctions due to poor connections.

4. Protection Requirements: The power supply module has an IP20 protection rating and is suitable for indoor use. Additional protective measures are required in humid or corrosive environments.

5. Regular Inspection: Periodically check the operational status of the power supply module, especially protection features such as overheat and overcurrent protection, to ensure smooth operation.

6. Troubleshooting: If the power supply module fails to start or encounters issues, check the input power, connection cables, and protection settings to identify any electrical faults.

7. Environmental Temperature: Ensure the installation environment temperature is within the operational range (-10°C to +50°C) to avoid performance issues caused by excessive temperatures.
